992031 (PM 250Z) - Gravely Pro-Master 50" Zero-Turn Mower, 20hp Briggs & Stratton (SN: 000101 - 029999) Belts, Idlers, And Blades Parts Diagram

Pro-Master 50" Zero-Turn Mower, 20hp Briggs & Stratton

Belts, Idlers, And Blades Parts Diagram

  • Title

1

Gravely 087779200

Blade, 50" Mower

$

$

Not available

2

Gravely 06435200

Washer, Flat .64 x 1.81 x .25
(Superseded to 06400829)

$3.99

$

In Stock, only 2 left!

0

3

Gravely 06445700

Washer-Bellville .63 x 1.625 x .14

$4.99

$

In Stock, only 3 left!

0

4

Gravely 07053400

Bolt, Blade

$46.99

$

In Stock, Qty 7

0

5

Gravely 06602200

Key-Square .25 x 1.00 x .25

$3.99

$

In Stock, only 2 left!

0

6

Gravely 04904300

Weldment, Pulley-V 4.75 x 1.004 with Key

$

$

Not available

7

Gravely 04904200

Weldment Pulley-Double V 4.75,3.50X1.004 with Ke

$85.99

$

In Stock, only 1 left!

0

8

Gravely 04903900

Weldment, Pulley-V 3.50 x 1.004 with Key
(Superseded to 07333467)

$67.99

$

In Stock, only 1 left!

0

9

Gravely 00597000

Washer, Cupped, Serrated .375
(Superseded to 06401110)

$3.99

$

In Stock, Qty 20+

0

10

Gravely 05974500

Bolt-Hex .38-16 x 1.00 Grade 8 with Epoxy Patch
(Superseded to 05901721)

$1.99

$

In Stock, Qty 20+

0

11

Gravely 07230600

Belt-V, A-Section 59.40 x .531

$96.99

$

In Stock, only 1 left!

0

12

Gravely 034944

Belt-V, A-Section 18.05 x .495
(Superseded to 07220000)

$28.99

$

In Stock, only 1 left!

0

13

Gravely 06225000

Bolt-Round Head Square Neck .50-13 x 3.50 Grade 5
(Superseded to 06200317)

$5.99

$

In Stock, Qty 20+

0

14

Gravely 415543

Washer-Flat-Steel .531 x 1.250 x .100
(Superseded to 06441000)

$2.99

$

In Stock, Qty 6

0

15

Gravely 010174

Bushing-Flange Nylon .762 x 1.00 x .58 x 1.48
(Superseded to 05518400)

$4.99

$

In Stock, Qty 20+

0

16

Gravely 034120

Arm, Idler Pivot
(Superseded to 08905900)

$82.99

$

Usually ships in 4-12 days

0

17

Gravely 034119

Spacer, Steel .56 x .75 x 2.44
(Superseded to 08820500)

$17.99

$

In Stock, only 1 left!

0

18

Gravely 020444

Spring-Compression .085 x .80 x 1.00
(Superseded to 08329100)

$13.99

$

In Stock, only 1 left!

0

19

Gravely 06536300

Nut-Locking-Center .50-13
(Superseded to 06500827)

$3.99

$

In Stock, only 2 left!

0

20

Gravely 05963300

Bolt-Hex .38-16 x 2.00 Grade 5
(Superseded to 05901718)

$2.99

$

In Stock, Qty 6

0

21

Gravely 446470

Washer-Flat-Steel .375 x 1.125 x .065
(Superseded to 06401139)

$2.49

$

In Stock, only 2 left!

0

22

Gravely 07309200

Idler-V 3 x .38

$37.99

$

In Stock, only 2 left!

0

23

Gravely 014672

Bushing .406 x .750 x .188
(Superseded to 03488200)

$5.99

$

In Stock, Qty 6

0

24

Gravely 06535800

Nut-Locking-Nylon .38-16
(Superseded to 06500831)

$2.49

$

In Stock, only 3 left!

0

25

Gravely 038713

Bracket, Belt Tensioner
(Superseded to 08928800)

$

$

Not available

26

Gravely 05958900

Bolt-Hex .50-13 x 1.25 Grade 5
(Superseded to 05901637)

$3.49

$

In Stock, only 1 left!

0

27

Gravely 06536300

Nut-Locking-Center .50-13
(Superseded to 06500827)

$3.99

$

In Stock, only 2 left!

0

28

Gravely 038714

Rod, Idler
(Superseded to 08876000)

$

$

Not available

29

Gravely 06706900

Pin-Center .09 x .75

$0.99

$

In Stock, Qty 8

0

30

Gravely 011779

Spring-Compression .125 x .78 x 1.00
(Superseded to 08327000)

$15.99

$

In Stock, only 2 left!

0

31

Gravely 06436200

Washer-Flat-Steel .406 x .812 x .065
(Superseded to 06401013)

$0.99

$

In Stock, Qty 20+

0

32

Gravely 06535900

Nut-Hex-Jam .38-16
(Superseded to 06500910)

$0.99

$

In Stock, Qty 20+

0

33

Gravely 09213500

Weldment, Idler Pivot

$

$

Not available

34

Gravely 09248400

Assembly, Idler Pivot Arm
(Superseded to 09286500)

$164.99

$

In Stock, only 1 left!

0

35

Gravely 05434800

Bearing 1.000 x 1.125 x .75
(Superseded to 05435800)

$9.49

$

In Stock, Qty 6

0

36

Gravely 09248400

Assembly, Idler Pivot Arm
(Superseded to 09286500)

$164.99

$

In Stock, only 1 left!

0

37

Gravely 06443400

Washer-Flat-Steel .380 x 1.50 x .125
(Superseded to 06401106)

$3.49

$

In Stock, Qty 9

0

38

Gravely 06308800

Washer-Locking .38 x .094 Regular
(Superseded to 06300116)

$0.99

$

In Stock, Qty 20+

0

39

Gravely 05958000

Bolt-Hex .38-16 x 1.25 Grade 5
(Superseded to 05901724)

$1.49

$

In Stock, Qty 20+

0

40

Gravely 411027

Fitting-Lube .25-28 x .256
(Superseded to 07012600)

$

$

Not available

41

Gravely 05961400

Bolt-Hex .38-16 x 2.75 Grade 5
(Superseded to 05901611)

$3.99

$

In Stock, only 4 left!

0

42

Gravely 014672

Bushing .406 x .750 x .188
(Superseded to 03488200)

$5.99

$

In Stock, Qty 6

0

43

Gravely 034286

Idler-Flat 4.00 x .38 (2.00 Wide)
(Superseded to 07327800)

Note: (2.00 Wide)

$87.99

$

In Stock, only 2 left!

0

44

Gravely 446470

Washer-Flat-Steel .375 x 1.125 x .065
(Superseded to 06401139)

$2.49

$

In Stock, only 2 left!

0

45

Gravely 06529600

Nut-Locking-Center .38-16
(Superseded to 06500825)

$1.49

$

In Stock, Qty 20+

0

46

Gravely 08335100

Spring, External .09 x 1.00 x 6.00
(Superseded to 08300513)

$34.99

$

Usually ships in 4-12 days

0

47

Gravely 09213900

Bracket, Idler Spring

$

$

Not available

48

Gravely 06441000

Washer-Flat-Steel .50 x 1.25 x .083
(Superseded to 06401202)

$2.99

$

In Stock, Qty 6

0
