991802 (1948 S) - Ariens Pro-Zoom 48" Zero-Turn Mower, 19hp Kawasaki (SN: 000101 & Above) Brake Linkage Parts Diagram

Pro-Zoom 48" Zero-Turn Mower, 19hp Kawasaki

Brake Linkage Parts Diagram

  • Title

1

Ariens 00967393

BOLT, 1/4-20X2.75 SOC 8 Y

$3.49

$

Usually ships in 4-12 days

0

2

Ariens 00150109

CHAIN, 1/4 X 3 LINKS Y

$

$

Not available

3

Ariens 00180922

E-RING, 1.00 X .050 Y
(Superseded to 05700170)

$

$

Not available

4

Ariens 00180956

YOKE, 1/4-20 RH ADJUSTABLE

$

$

Not available

5

Ariens 00180957

SPRING, COM .784X.092X1.50

$3.49

$

Usually ships in 4-12 days

0

6

Ariens 00180982

BALL JOINT, 5/16 FMAL W/STD

$

$

Not available

7

Ariens 00181017

U-BOLT, RD 1.00X2.50X3/8-16 Y

$17.99

$

Usually ships in 4-12 days

0

8

Ariens 00967353

RING, RUE .375 X .054 X 1.254

$2.49

$

Usually ships in 4-12 days

0

9

Ariens 00191080

ROD, PUMP CONTROL HORNET

$82.99

$

Usually ships in 4-12 days

0

10

Ariens 00255500

PLATE, PUMP CONTROL ARM

$

$

Not available

11

Ariens 00967350

RING, RUE .250 X .041 X .844

$

$

Not available

12

Ariens 00967342

LOCKNUT, 7/16-14 WHIZ Y
(Superseded to 06530004)

$2.49

$

Usually ships in 4-12 days

0

13

Ariens 00967338

NUT, 5/16-24 HEX GR5 LH Y
(Superseded to 06547200)

$3.99

$

Usually ships in 4-12 days

0

14

Ariens 06543900

NUT-SPIRALOCK-FLG .50-13 PLN

$6.99

$

In Stock, Qty 6

0

15

Ariens 06529500

NUT-HEX .312-24 YWZC
(Superseded to 06500939)

$1.99

$

Usually ships in 4-12 days

0

16

Ariens 06216100

@BLT-RDHDSQNK .31-18X1.00 G5YZ
(Superseded to 06200231)

$1.49

$

In Stock, Qty 20+

0

17

Ariens 00191129

CHAIN, 2 LINKS 1/4" Y

$

$

Not available

18

Ariens 00967054

NUT, 3/8-24 STD HEX Y
(Superseded to 06522900)

$2.49

$

In Stock, only 2 left!

0

19

Ariens 00191175

ROD, BRAKE GEN 1

$

$

Not available

20

Ariens 00191176

PIN, BRAKE LINKAGE

$

$

Not available

21

Ariens 00191177

SPRING, COM .710X.142X2.50

$20.99

$

Usually ships in 4-12 days

0

22

Ariens 00964066

LOCKNUT, 3/8-24 CROWN Y
(Superseded to 06512300)

$3.99

$

Usually ships in 4-12 days

0

23

Ariens 00964061

LOCKNUT, 7/16-14 CENTER Y
(Superseded to 06536400)

$2.99

$

In Stock, Qty 12

0

24

Ariens 06531000

@NUT-LK-NYL .250-20 YWZC
(Superseded to 06500832)

$4.99

$

Usually ships in 4-12 days

0

25

Ariens 00191227

CABLE, BATTERY - 35" GROUND

$

$

Not available

26

Ariens 00191509

WLDT, WHEEL MOTOR PLATE

$

$

Not available

27

Ariens 03890159

WLDT, LH REAR DECK PIVOT

$

$

Not available

28

Ariens 03891259

WLDT, RH REAR DECK PIVOT

$

$

Not available

29

Ariens 03785759

WLDT, BATTERY/TANK (ARIENS)

$

$

Not available

30

Ariens 00964025

LOCKNUT, 7/16-14 CROWN Y
(Superseded to 06508200)

$3.99

$

Usually ships in 4-12 days

0

31

Ariens 00964022

LOCKNUT, 3/8-16 CROWN Y

$

$

Not available

32

Ariens 00964021

LOCKNUT, 5/16-18 CROWN Y
(Superseded to 06530800)

$5.99

$

Usually ships in 4-12 days

0

33

Ariens 00964019

LOCKNUT, 5/16-18 WHIZ Y
(Superseded to 06530400)

$1.49

$

In Stock, Qty 20+

0

34

Ariens 00473450

BOLT, 1/2-13X2.75 HEX 2 FLTD Y

$

$

Not available

35

Ariens 05952400

@BLT-HEX .31-18X1.50 GR5 YWZC
(Superseded to 05901710)

$1.49

$

In Stock, Qty 13

0

36

Ariens 05957400

@BLT-HEX .31-18X1.75 GR5 YWZC
(Superseded to 05901804)

$2.99

$

In Stock, Qty 8

0

37

Ariens 00960047

BOLT, 3/8-16X1.25 HEX 5 Y
(Superseded to 05958000)

$1.49

$

In Stock, Qty 20+

0

38

Ariens 00960081

BOLT, 7/16-14X1.50 HEX 5 Y
(Superseded to 05962800)

$3.49

$

In Stock, Qty 11

0

39

Ariens 00960504

NUT, 1/2-13 STD HEX GR5 Y
(Superseded to 06537300)

$3.99

$

In Stock, only 1 left!

0

40

Ariens AA960601

WASHER, .313 MED SPRG LOCK Y
(Superseded to 06308600)

$0.99

$

In Stock, Qty 20+

0

41

Ariens AA960700

WASHER, .250 REG FLAT Y
(Superseded to 06435800)

$0.99

$

In Stock, Qty 20+

0

42

Ariens 06435700

@WSHR-FL-STL.38X.875X.083 YWZC
(Superseded to 06401023)

$1.49

$

In Stock, Qty 20+

0

43

Ariens 06435900

@WSHR-FL-STL.438X1.00X.083 YWZ
(Superseded to 06401008)

$1.49

$

In Stock, Qty 20+

0

44

Ariens AA962200

PIN, CVS .250X1.00X.859 Y
(Superseded to 06818500)

$3.99

$

Usually ships in 4-12 days

0

45

Ariens 00961284

BOLT, M8X1.25X20 HEX 8.8 Y

$1.49

$

Usually ships in 4-12 days

0
