991400 (EZKW2352S) - EverRide Hornet 52" Zero-Turn Mower, 23hp Kawasaki (SN: 000101 - 009999) Brake Linkage Parts Diagram

Hornet 52" Zero-Turn Mower, 23hp Kawasaki

Brake Linkage Parts Diagram

  • Title
1

Gravely 00967393

Bolt, 1/4-20 x 2.75 SOC 8

$3.49

$

Usually ships in 4-12 days

0

2

Gravely 00150109

Chain - 3 Links

$

$

Not available

3

Gravely 00180922

E-Ring, 1.00 x .050
(Superseded to 05700170)

$

$

Not available

4

Gravely 00180956

Yoke, 1/4-20 RH Adjustable

$

$

Not available

5

Gravely 00180957

Spring, Compression .784 x .092 x 1.50

$3.49

$

Usually ships in 4-12 days

0

6

Gravely 00180982

Ball Joint, LH 5/16 FMAL W/STD

$

$

Not available

7

Gravely 00181017

U-Bolt, RD 1.00 x 2.50 x 3/8-16

$17.99

$

Usually ships in 4-12 days

0

8

Gravely 00967353

Ring, Rue .375 x .054 x 1.254

$2.49

$

Usually ships in 4-12 days

0

9

Gravely 00191080

Rod, Pump Control

$82.99

$

Usually ships in 4-12 days

0

10

Gravely 00255500

Plate, Pump Control Arm

$

$

Not available

11

Gravely 00967350

Ring, Rue .250 x .041 x .844

$

$

Not available

12

Gravely 00967342

Locknut, 7/16-14 Whiz
(Superseded to 06530004)

$2.49

$

Usually ships in 4-12 days

0

13

Gravely 00967338

Nut, 5/16-24 Hex Grade 5 LH
(Superseded to 06547200)

$3.99

$

Usually ships in 4-12 days

0

14

Gravely 00964016

Locknut, 3/8-16 Whiz
(Superseded to 06534900)

$1.49

$

In Stock, Qty 20+

0

15

Gravely 00964003

Nut, 5/16-24 STD Hex Grade 5

$

$

Not available

16

Gravely 00963074

Bolt, 5/16-18 x 1.00 CRG 2

$

$

Not available

17

Gravely 00191129

Chain, 2 Links 1/4"

$

$

Not available

18

Gravely 00967054

Nut, 3/8-24 STD Hex Grade 5
(Superseded to 06522900)

$2.49

$

In Stock, only 2 left!

0

19

Gravely 00191175

Rod, Brake

$

$

Not available

20

Gravely 00191176

Pin, Brake Linkage

$

$

Not available

21

Gravely 00191177

Spring, Compression .710 x .142 x 2.50

$20.99

$

Usually ships in 4-12 days

0

22

Gravely 00964066

Locknut, 3/8-24 Crown
(Superseded to 06512300)

$3.99

$

Usually ships in 4-12 days

0

23

Gravely 00964061

Locknut, 7/16-14 Center
(Superseded to 06536400)

$2.99

$

In Stock, Qty 12

0

24

Gravely 00964048

Locknut, 1/4-20 Nyloc

$

$

Not available

25

Gravely 00191227

Cable, Battery - 35" Ground

$

$

Not available

26

Gravely 00191509

Weldment, Wheel Motor Plate

$

$

Not available

27

Gravely 03890161

Weldment, LH Front Deck Lift

$

$

Not available

28

Gravely 03891261

Weldment, RH Front Deck Lift

$

$

Not available

29

Gravely 03785761

Weldment, Battery/Tank Plate

$

$

Not available

30

Gravely 00964025

Locknut, 7/16-14 Crown
(Superseded to 06508200)

$3.99

$

Usually ships in 4-12 days

0

31

Gravely 00964022

Locknut, 3/8-16 Crown

$

$

Not available

32

Gravely 00964021

Locknut, 5/16-18 Crown
(Superseded to 06530800)

$5.99

$

Usually ships in 4-12 days

0

33

Gravely 00964019

Locknut, 5/16-18 Whiz
(Superseded to 06530400)

$1.49

$

In Stock, Qty 20+

0

34

Gravely 00473450

Bolt, 1/2-13 x 2 3/4 Grade 2

$

$

Not available

35

Gravely 00960025

Bolt, 5/16-18 x 1.50 Hex Grade 5

$

$

Not available

36

Gravely 00960026

Bolt, 5/16-18 x 1.75 Hex Grade 5
(Superseded to 05901804)

$2.99

$

In Stock, Qty 8

0

37

Gravely 00960047

Bolt, 3/8-16 x 1.25 Hex Grade 5
(Superseded to 05958000)

$1.49

$

In Stock, Qty 20+

0

38

Gravely 00960081

Bolt, 7/16-14 x 1.50 Hex Grade 5
(Superseded to 05962800)

$3.49

$

In Stock, Qty 11

0

39

Gravely 00960504

Nut, 1/2-13 STD Hex Grade 5
(Superseded to 06537300)

$3.99

$

Usually ships in 4-12 days

0

40

Gravely AA960601

Washer, .313 Med Spring Lock
(Superseded to 06308600)

$0.99

$

In Stock, Qty 20+

0

41

Gravely AA960700

Washer, .250 Reg Flat
(Superseded to 06435800)

$0.99

$

In Stock, Qty 20+

0

42

Gravely 00960701

Washer, .313 Reg Flat
(Superseded to 06401023)

$1.49

$

In Stock, Qty 20+

0

43

Gravely 00960702

Washer, .375 Reg Flat
(Superseded to 06435900)

$1.49

$

In Stock, Qty 20+

0

44

Gravely AA962200

Pin, CVS .250 x 1.00 x .859
(Superseded to 06818500)

$3.99

$

Usually ships in 4-12 days

0

45

Gravely 00961284

Bolt, M8 x 1.25 x 20 He 8.8"

$1.49

$

Usually ships in 4-12 days

0
