991208 (Pro-Turn 52) - Gravely Pro-Turn 52" Zero-Turn Mower (SN: 040000 & Above) Tire Assembly Parts Diagram

Pro-Turn 52" Zero-Turn Mower

Tire Assembly Parts Diagram

  • Title

1

Gravely 04539353

WLDMT, CASTER FORK-RED

$150.99

$

Usually ships in 4-12 days

0

2

Gravely 07101032

TIRE/WHEEL, ASM 22X10-10
(Superseded to 07101115)

$

$

Not available

2

Gravely 07101033

TIRE, 22 X 10-10

$239.99

$

In Stock, only 2 left!

0

3

Gravely 00675300

SPACER, FRONT WHEEL

$7.99

$

In Stock, Qty 20+

0

4

Gravely 05600432

SEAL, OIL 1.75 X 2.332 X .312

$11.99

$

In Stock, Qty 13

0

5

Gravely 03925900

CAP, DUST

$11.99

$

In Stock, only 2 left!

0

6

Gravely 04718600

SPCR, FRONT CASTER FORK
(Superseded to 04861500)

$14.99

$

In Stock, Qty 6

0

7

Gravely 05600515

O-RING, .139 W X 1.234 ID

$2.49

$

In Stock, Qty 8

0

8

Gravely 06517600

NUT, LUG .500-13
(Superseded to 06500926)

$1.49

$

In Stock, Qty 20+

0

9

Gravely 07100835

TIRE/WHEEL, ASM , 13X5-6
(Superseded to 07101111)

$119.99

$

In Stock, Qty 20+

0

9

Gravely 07100219

TIRE, 13 X 5.0-6
(Superseded to 07101609)

$62.99

$

Usually ships in 4-12 days

0

9

Gravely 05435700

BEARING

$22.99

$

In Stock, Qty 19

0

10

Gravely 05978200

BLT-HEX .50-13X7.50 GR5 YWZC
(Superseded to 05902023)

$7.99

$

In Stock, only 2 left!

0

11

Gravely 06536900

@NUT-LK-CTR-JAM .75-16 YWZC

$5.99

$

In Stock, only 3 left!

0

12

Gravely 06500010

NUT-LK-NYL-FLG .50-13 YWZC
(Superseded to 06500810)

$1.49

$

In Stock, Qty 20+

0

13

Gravely 06439800

WSHR-FL-STL.812X2.00X.148YWZC
(Superseded to 06401201)

$3.99

$

In Stock, only 3 left!

0

14

Gravely 07001727

FITTING, .250-28 FLUSH MOUNT GREASE

$3.99

$

In Stock, only 1 left!

0

15

Gravely 05404700

BRG, CONE 1.250 X .660

$20.99

$

In Stock, Qty 20+

0

16

Gravely 05404600

BRG, CUP 2.328 X .465

$13.99

$

In Stock, only 2 left!

0
