991079 (Pro-Turn 148) - Gravely Pro-Turn 48" Zero-Turn Mower, Kawasaki (SN: 020000 - 020999) Hydraulic Drive Parts Diagram

Pro-Turn 48" Zero-Turn Mower, Kawasaki

Hydraulic Drive Parts Diagram

  • Title

1

Gravely 06500010

Nut, Nyloc Flange .50-13
(Superseded to 06500810)

$1.49

$

In Stock, Qty 20+

0

2

Gravely 06436400

Washer, Flat Steel .511 x 1.441 x .125
(Superseded to 06401022)

$2.99

$

In Stock, Qty 20+

0

3

Gravely 02988651

Weldment, Hydro Drive Idler Arm

$91.99

$

Usually ships in 4-12 days

0

4

Gravely 05500123

Bushing, 1.00 x 1.125 x 1.936
(Superseded to 05501234)

$10.99

$

In Stock, Qty 20+

0

5

Gravely 01581700

Bushing, Spacer .505/.500 x .999/.996 x 2.05/2.03 Promaster

$5.99

$

In Stock, Qty 20+

0

6

Gravely 05958400

Bolt, Hex .38-16 x 2.50
(Superseded to 05901812)

$2.49

$

In Stock, Qty 20+

0

7

Gravely 08300507

Spring, Extension
(Superseded to 08300728)

$26.99

$

In Stock, Qty 20+

0

8

Gravely 07000034

Bolt, Shoulder EP .38-16 x .30 Hex

$3.99

$

In Stock, only 1 left!

0

9

Gravely 06529400

Nut, Hex .38-16
(Superseded to 06500917)

$0.99

$

In Stock, Qty 20+

0

10

Gravely 06545500

Nut, Nyloc Flange .38-16
(Superseded to 06500726)

$1.49

$

In Stock, Qty 20+

0

11

Gravely 05960000

Bolt, Hex .50-13 x 3.25
(Superseded to 05901634)

$3.99

$

Usually ships in 4-12 days

0

12

Gravely 05525700

Bushing, Sleeve .407 x .625 x .750

$7.49

$

In Stock, only 1 left!

0

13

Gravely 07226400

Belt, A 69.26 Raw Cogged

$52.99

$

In Stock, Qty 9

0

14

Gravely 07312500

Idler, Flat 4.00 x .38
(Superseded to 07300101)

$62.99

$

In Stock, Qty 20+

0

15

Gravely 06436200

Washer, Flat Steel .406 x .812 x .065
(Superseded to 06401013)

$0.99

$

In Stock, Qty 20+

0
