988640 (GHWKA1536S) - Great Dane Scamper 36" Walk-Behind Mower, 15hp Kawasaki, Hydro (SN: 000101 & Above) Traction Control Parts Diagram

Scamper 36" Walk-Behind Mower, 15hp Kawasaki, Hydro

Traction Control Parts Diagram

  • Title

1

Ariens 00200531

ASSY, WHEEL & TIRE - 16X6.5-8

$114.99

$

Usually ships in 4-12 days

0

2

Ariens 00960526

NUT, 1/2-20 LUG C
(Superseded to 06517600)

$1.49

$

In Stock, Qty 20+

0

3

Ariens 00962019

PIN, COT .125X1.50 EXTP Y
(Superseded to 06714300)

$1.99

$

Usually ships in 4-12 days

0

4

Ariens D18311

MOTOR, HYDRAULIC WHEEL

$840.99

$

Usually ships in 4-12 days

0

5

Ariens 00150052

BUSHING, MACH .750X1.25X.048 Y

$

$

Not available

6

Ariens 00203842

ASSY, WHEEL HUB

$

$

Not available

7

Ariens 05963800

BLT-HEX .44-14X1.25 GR5 YWZC

$2.99

$

Usually ships in 4-12 days

0

8

Ariens 00960603

WASHER, .438 MED SPRG LOCK Y
(Superseded to 06309300)

$2.99

$

In Stock, Qty 11

0

9

Ariens D14280

BOLT, 3/8-16 X 1 GR8 BLACK

$

$

Not available

10

Ariens 00960602

WASHER, .375 MED SPRG LOCK Y

$

$

Not available

11

Ariens D12062

BRACKET, MOTOR MOUNT S/O

Note: (988640)

$

$

Not available

11

Ariens 03396863

BRACKET, MOTOR MOUNT WIDETRAC

Note: (988641)

$

$

Not available

12

Ariens 00960712

WASHER, .468X1.00X.125 FLAT Y
(Superseded to 06400914)

$3.99

$

Usually ships in 4-12 days

0

13

Ariens 00964040

LOCKNUT, 1/4-20 WHIZ Y

$

$

Not available

14

Ariens 03908351

WLDT, BRAKE SYS 36" FLWLK

Note: (988640)

$78.99

$

Usually ships in 4-12 days

0

14

Ariens 03990751

WLDT, BRAKE SYSTEM 48/52 FXWLK

Note: (988641)

$

$

Not available

15

Ariens 05946900

BLT-HEX .31-18X1.00 GR5 YWZC
(Superseded to 05901701)

$1.49

$

In Stock, Qty 20+

0

16

Ariens 03885763

SHOE, BRAKE SYSTEM SCAMPER

$

$

Not available

17

Ariens 00967115

LOCKNUT, 5/16-18 NYLOC Y
(Superseded to 06500820)

$0.99

$

In Stock, Qty 20+

0

18

Ariens 00135292

SPRING, EXT .375X.055X2.25 Y

$20.99

$

Usually ships in 4-12 days

0

19

Ariens 05947400

BLT-HEX .25-20X1.25 GR5 YWZC
(Superseded to 05901738)

$1.99

$

In Stock, Qty 5

0

20

Ariens 04083463

WLDT, 18" ENG BED FX SCAMPER

$

$

Not available
