988325 (52 HE) - Gravely Pro-Hydro 52" Walk-Behind Mower, Pistol Grip, Electric (SN: 000101 & Above) Console And Deck Mounting Parts Diagram

Pro-Hydro 52" Walk-Behind Mower, Pistol Grip, Electric

Console And Deck Mounting Parts Diagram

  • Title

1

Gravely 06540600

LOCKNUT, 1/2-13 NYLOC Y
(Superseded to 06500830)

$2.49

$

In Stock, only 3 left!

0

2

Gravely 03925453

PLATE, ENGINE BED FRONT (988324, 988325)

Note: (988324, 988325)

$25.99

$

Usually ships in 4-12 days

0

2

Gravely 03932453

PLATE ,ENGINE BED FRONT (988323)

Note: (988323)

$27.99

$

Usually ships in 4-12 days

0

3

Gravely 05958900

BOLT, 1/2-13 X 1.25 HEX 5 Y
(Superseded to 05901637)

$3.49

$

In Stock, only 1 left!

0

4

Gravely 05962000

BOLT, 1/2-13 X 1.50 HEX 5 Y
(Superseded to 05901631)

$3.99

$

In Stock, only 1 left!

0

5

Gravely 00959995

FTG, 1/4-28 STRGT GREASE ZERK

$3.49

$

Usually ships in 4-12 days

0

6

Gravely 05500934

BSHG, FLG 1.00 X 1.25 X 1.50 X 1.50 EP REV

$6.99

$

In Stock, Qty 20+

0

7

Gravely 07100931

9X3.5-4 CAREFREE BLT TOGETHER

$136.99

$

In Stock, only 2 left!

0

8

Gravely D13003

TUBE, CASTER AXLE

$20.99

$

Usually ships in 4-12 days

0

9

Gravely 05964100

BOLT, .50-13 X 5.50 HEX 5 Y
(Superseded to 05901632)

$6.99

$

Usually ships in 4-12 days

0

10

Gravely 03855153

WLDT, FRONT WHEEL FLOAT WALK

$122.99

$

Usually ships in 4-12 days

0

11

Gravely 04366100

BRG, FLG 1.00X1.25X1.00

$17.99

$

Usually ships in 4-12 days

0

12

Gravely 06443400

WSH-FL-ST .38 X 1.50 X .125 REV
(Superseded to 06401106)

$3.49

$

In Stock, Qty 8

0

13

Gravely 05946800

BOLT, HEX .25-20 x .75 GR5
(Superseded to 05901716)

$0.99

$

In Stock, Qty 20+

0

14

Gravely 05958000

BOLT, .38-16 X 1.25 HEX 5 Y
(Superseded to 05901724)

$1.49

$

In Stock, Qty 20+

0

15

Gravely 03841053

WLDT, DECK FRAME 52 FLWLK (988325)

Note: (988325)

$681.99

$

Usually ships in 4-12 days

0

15

Gravely 03858953

WLDT, DECK FRAME 48 FLWLK (988324)

Note: (988324)

$774.99

$

Usually ships in 4-12 days

0

15

Gravely 03902653

WLDT, DECK FRAME 36 FLWLK (988323)

Note: (988323)

$752.99

$

Usually ships in 4-12 days

0

16

Gravely 07503100

BUMPER GROMMET .125 X .25 REV

$3.49

$

In Stock, only 3 left!

0

17

Gravely 03841023

WASHER, .905 X 1.750X.250

$

$

Not available

18

Gravely 06400913

WASHER, FLAT .630 x 1.50 x .25
(Superseded to 06401033)

$6.99

$

In Stock, only 1 left!

0

19

Gravely 06442900

WASHER, FLAT-STEEL .688 X 1.75 X.134 REV
(Superseded to 06401032)

$1.49

$

In Stock, Qty 5

0

20

Gravely 06713300

PIN, HAIR-INTERNAL .17 X .68 X 3.50 REV B
(Superseded to 06700228)

$2.99

$

In Stock, only 1 left!

0

21

Gravely 05901321

BOLT, 5/8-11 X 1.50 HEX 8 Y
(Superseded to 05901723)

$3.99

$

Usually ships in 4-12 days

0

22

Gravely 04354853

SHIELD, BELT 52" HYDRO WALK (988325)

Note: (988325)

$

$

Not available

22

Gravely 04354753

SHIELD, BELT 48" MAIN (988324)

Note: (988324)

$

$

Not available

22

Gravely 04354653

SHIELD, BELT 36 MAIN (988323)

Note: (988323)

$

$

Not available

23

Gravely 00111910

CABLE TIE, .15 X 8.50

$

$

Not available

24

Gravely D33002

SWIVEL, 3/8-24

$10.99

$

Usually ships in 4-12 days

0

25

Gravely 06436200

WASHER, .406 X .813 X .065 FLAT Y
(Superseded to 06401013)

$0.99

$

In Stock, Qty 20+

0

26

Gravely 06531000

NUT, LOCK NYLON .250-20
(Superseded to 06500832)

$4.99

$

Usually ships in 4-12 days

0

27

Gravely 03932053

PLATE, ENGINE BED REAR (988324, 988325)

Note: (988324, 988325)

$27.99

$

Usually ships in 4-12 days

0

27

Gravely 03932553

PLATE, ENGINE BED REAR (988323)

Note: (988323)

$22.99

$

Usually ships in 4-12 days

0

28

Gravely 06444700

WASHER, FL-STL REV
(Superseded to 06401207)

$3.99

$

In Stock, Qty 20+

0

29

Gravely 04355453

SHIELD, BELT 36" (988323)

Note: (988323)

$

$

Not available

29

Gravely 04353553

SHIELD, BELT 48" (988324)

Note: (988324)

$

$

Not available

29

Gravely 04359453

SHIELD, BELT 52 PROWALK (988325)

Note: (988325)

$

$

Not available

30

Gravely 06308800

WSHR-LK .38X.094 REG YWZC
(Superseded to 06300116)

$0.99

$

In Stock, Qty 20+

0

31

Gravely 06500010

NUT-LK-NYL-FLG .50-13 YWZC
(Superseded to 06500810)

$1.49

$

In Stock, Qty 20+

0

32

Gravely 04352851

GUARD, EXHAUST

$74.99

$

Usually ships in 4-12 days

0

33

Gravely 04352951

GUARD, UPPER EXHAUST

$

$

Not available

34

Gravely 04354051

GUARD, EXHAUST

$51.99

$

Usually ships in 4-12 days

0

35

Gravely 07400034

SCR-TAP .25-20X.50 HWH YWZ
(Superseded to 07400122)

$0.99

$

In Stock, Qty 20+

0

36

Gravely 05946800

BLT-HEX .25-20X.75 GR5 YWZC
(Superseded to 05901716)

$0.99

$

In Stock, Qty 20+

0

37

Gravely 06531000

NUT-LK NYL .25-20 YWZC
(Superseded to 06500832)

$4.99

$

Usually ships in 4-12 days

0

38

Gravely 07533600

BUMPER, RUBBER

$11.99

$

In Stock, only 1 left!

0

39

Gravely 06530400

NUT-SPNLK-FLG .312-18 YWZC
(Superseded to 06500815)

$1.49

$

In Stock, Qty 20+

0

40

Gravely 07001625

BLT, HEX 0.38-16 X 1.25 GR5 CAPTIVE

$14.99

$

Usually ships in 4-12 days

0

41

Gravely 06308700

LOCK, WSHR-EXT 0.391 X 0.628 X 0.036 YWZC

$1.99

$

Usually ships in 4-12 days

0

42

Gravely 06800028

RVT-POP .187x.250 (#64) YWZC
(Superseded to 06800140)

Note: (#64) YWZC

$0.99

$

In Stock, Qty 14

0

43

Gravely 04183000

KEEPER, BOLT

$6.49

$

Usually ships in 4-12 days

0

44

Gravely 04354551

BRKT, REAR BUMPER

$

$

Not available

45

Gravely 05948700

BLT, HEX .38-16X1.00 GR5 YWZC
(Superseded to 05901711)

$1.49

$

In Stock, Qty 20+

0

46

Gravely 06534900

NUT, SPNLK-FLG .375-16 YWZC
(Superseded to 06500735)

$1.49

$

In Stock, Qty 20+

0
