985092 - Gravely Walk-Behind 2-Wheel Tractor, 16hp, Electric Start (SN: 000101 & Above) WHEELS Parts Diagram

Walk-Behind 2-Wheel Tractor, 16hp, Electric Start

WHEELS Parts Diagram

  • Title

1

Gravely 012674

WHL 7.71 X 1.25
(Superseded to 07133000)

$58.99

$

In Stock, only 2 left!

0

2

Gravely 018762

TIRE 16 X 5W X 3
(Superseded to 07127100)

$387.99

$

Usually ships in 4-12 days

0

3

Gravely 012673

WHL-DISC 6.75 X 9.129
(Superseded to 07132900)

$68.99

$

In Stock, only 2 left!

0

4

Gravely 124829

NUT-JAM .375-16 PL
(Superseded to 06500910)

$0.99

$

In Stock, Qty 20+

0

5

Gravely 120382

WSHR-LOCK .375 X .094 MED PL
(Superseded to 06300116)

$0.99

$

In Stock, Qty 20+

0

6

Gravely 428638

BLT-HEX .38-16 X .625
(Superseded to 05940100)

$

$

Not available

6

Gravely 180120

BLT-HEX .38-16 X .75 PL GR 5
(Superseded to 05901702)

$1.49

$

In Stock, Qty 20+

0

7

Gravely 046987

T/WHL ASSY 8.50-8 X 18
(Superseded to 07130200)

$170.99

$

Usually ships in 4-12 days

0

7

Gravely 052679

T/WHL ASSY 16 X 6.50-8(TURF CHIEF)
(Superseded to 07132000)

Note: (TURF CHIEF)

$

$

Not available

7

Gravely 071377

T/WHL ASSY 4.80/4.00-8 STUD
(Superseded to 07137700)

$

$

Not available

7

Gravely 071378

T/WHL 4.80/4.00-8 TRAC R.H.
(Superseded to 07137800)

$

$

Not available

7

Gravely 071387

T/WHL 4.80/4.00-8 TRAC L.H.
(Superseded to 07138700)

$

$

Not available

8

Gravely 180177

BLT-HEX .50-13 X 1.50 PL GR 5
(Superseded to 05901631)

$3.99

$

In Stock, only 1 left!

0

9

Gravely 435507

NUT-LK-NYL .50-13 PL
(Superseded to 06500830)

$2.49

$

In Stock, only 3 left!

0

10

Gravely 022551

HUB, 7" WHEEL
(Superseded to 08526400)

$391.99

$

Usually ships in 4-12 days

0

11

Gravely 022507

HUB, WHEEL
(Superseded to 58501600)

$541.99

$

Usually ships in 4-12 days

0

12

Gravely 022512

BUSH., S1.02 X 1.37 X 1.13 ST
(Superseded to 08525200)

$25.99

$

Usually ships in 4-12 days

0
