982 (2050595U) - Cub Cadet Super Garden Tractor Rear Axle Carrier-2-SN 720000 & Up Parts Diagram

Super Garden Tractor

Rear Axle Carrier-2-SN 720000 & Up Parts Diagram

  • Title

1

Cub Cadet 703-0906

Carrier Assy, Rear Axle

Note: (Includes Ref No. 2 and 3)

$

$

Not available

Cub Cadet 736-0213

Washer, 3/8 ID Belleville

$6.99

$

In Stock, only 3 left!

0

Cub Cadet 736-0169

Washer, 3/8 Lock

$3.99

$

In Stock, Qty 20+

0

Cub Cadet 710-3116

Bolt, 3/8 X 2-1/2 Type 5

Note: (Replaces IH-107064-C1)

$

$

Not available

Cub Cadet 710-3115

Bolt, 3/8 X 3 Type 8

Note: (Replaces IH-107065-C1)

$37.99

$

Usually ships in 3-6 days

0

Cub Cadet 710-3011

Bolt, 3/8 X 2-1/4 Type 5

Note: (Replaces IH-107063-C1)

$6.99

$

In Stock, Qty 20+

0

2

Cub Cadet 741-0363

Bearing, Needle
(Superseded to 941-0363)

$25.99

$

In Stock, Qty 11

0

3

Cub Cadet 721-0187

Seal, Oil
(Superseded to 921-0187)

$

$

Not available

4

Cub Cadet 721-3014

Gasket, Carrier
(Superseded to 721P3014)

$13.99

$

In Stock, Qty 12

0

5

Cub Cadet 703-0907

Axle, Rear

Note: (Includes Ref No. 6 & 7)

$

$

Currently unavailable

6

Cub Cadet 703-0908B

Disc, Brake

$

$

Not available

7

Cub Cadet 710-0852

Bolt, Lug

$6.49

$

In Stock, only 4 left!

0

8

Cub Cadet 716-0136

E-Ring, .668 Ext Ret

$8.99

$

In Stock, Qty 20+

0
