966529101 - Husqvarna 42" Grass Catcher (2009-12) Repair Parts Parts Diagram

42" Grass Catcher

Repair Parts Parts Diagram

  • Title

1

Husqvarna 539130344

HOUSING W/DECALS

$

$

Not available

2

Husqvarna 539101977

TRACTION SPRING

$17.99

$

In Stock, Qty 10

0

3

Husqvarna 575467901

COVER, BELT
(Superseded to 539130309)

$44.99

$

Usually ships in 3-10 days

0

4

Husqvarna 539130295

HUB, BEARING

$93.99

$

Usually ships in 3-10 days

0

5

Husqvarna 539130316

SHAFT, IMPELLER

$74.99

$

Usually ships in 3-10 days

0

6

Husqvarna 539130293

COVER, BELT

$80.99

$

Usually ships in 3-10 days

0

7

Husqvarna 539130292

IMPELLER

$120.99

$

In Stock, only 1 left!

0

8

Husqvarna 539132122

PLATE, BACKING

$17.99

$

Usually ships in 3-10 days

0

9

Husqvarna 539132124

PLATE, BACKING

$11.99

$

Usually ships in 3-10 days

0

10

Husqvarna 539130349

DECAL, BELT ROUTING

$8.99

$

Usually ships in 3-10 days

0

11

Husqvarna 539105785

DECAL, WARNING

$10.99

$

Usually ships in 3-10 days

0

12

Husqvarna 539106741

DECAL, SEVERING

$6.99

$

Usually ships in 3-10 days

0

13

Husqvarna 539131085

KEEPER, BELT, OUTER

$12.99

$

Usually ships in 3-10 days

0

14

Husqvarna 539131087

KEEPER, BELT, REAR

$34.99

$

Usually ships in 3-10 days

0

15

Husqvarna 539130323

SPACER

$48.99

$

Usually ships in 3-10 days

0

16

Husqvarna 539130324

PULLEY

$53.99

$

In Stock, only 3 left!

0

17

Husqvarna 539919078

PULLEY, IDLER

$37.99

$

In Stock, only 3 left!

0

18

Husqvarna 539130335

MOUNT, IDLER, UPPER

$24.99

$

Usually ships in 3-10 days

0

19

Husqvarna 539130336

MOUNT, IDLER, LOWER

$43.99

$

Usually ships in 3-10 days

0

20

Husqvarna 539130337

ARM, IDLER

$30.99

$

Usually ships in 3-10 days

0

21

Husqvarna 539130338

ARM, TENSION

$31.99

$

Usually ships in 3-10 days

0

22

Husqvarna 539130339

BRACKET, MOUNT, FRONT

$45.99

$

Usually ships in 3-10 days

0

23

Husqvarna 539130340

BRACKET, MOUNT, REAR

$34.99

$

Usually ships in 3-10 days

0

24

Husqvarna 539113683

V-IDLER

$66.99

$

Usually ships in 3-10 days

0

25

Husqvarna 539130296

BEARING

$9.99

$

In Stock, only 2 left!

0

26

Husqvarna 539130301

BUSHING

$9.99

$

Usually ships in 3-10 days

0

27

Husqvarna 539108088

LATCH, HOOD
(Superseded to 532109808)

$6.99

$

In Stock, Qty 13

0

28

Husqvarna 539104411

KNOB w/ STUD
(Superseded to 597783101)

$4.99

$

In Stock, Qty 20+

0

29

Husqvarna 539130341

PLATE, OUTER

$74.99

$

In Stock, only 1 left!

0

30

Husqvarna 539130346

KEEPER

$

$

Not available

31

Husqvarna 539132347

BELT

$40.99

$

Usually ships in 3-10 days

0

32

Husqvarna 575596802

BRACKET, BELT COVER
(Superseded to 576014201)

$28.99

$

Usually ships in 3-10 days

0

33

Husqvarna 539108120

NUT 1/4-20 HEX NYLOC
(Superseded to 582478602)

$2.49

$

In Stock, Qty 20+

0

34

Husqvarna 539990717

NUT 5/16-18 HEX NYLOC
(Superseded to 596583702)

$3.99

$

In Stock, Qty 20+

0

35

Husqvarna 539108735

NUT 1/4-20 HEX FLANGE

$4.99

$

In Stock, only 2 left!

0

36

Husqvarna 539130313

NUT 5/16-18 TEE

$4.99

$

In Stock, Qty 8

0

37

Husqvarna 539130314

NUT 1/4-20 TEE

$4.99

$

In Stock, Qty 18

0

38

Husqvarna 539200282

NUT 3/8-16 HEX JAM NYLOC
(Superseded to 596230801)

$3.99

$

In Stock, Qty 15

0

39

Husqvarna 539110321

BOLT, HEX 3/8-24 x 1 1/4 GR 8
(Superseded to 532850857)

$4.99

$

In Stock, only 1 left!

0

40

Husqvarna 539115667

KEY 3/16 x 1/2

$4.99

$

In Stock, only 2 left!

0

41

Husqvarna 539125229

KEY 3/16 x 1 1/2

$4.99

$

In Stock, only 3 left!

0

42

Husqvarna 539130315

HCS 5/16-18 x 1/2

$3.99

$

Usually ships in 3-10 days

0

43

Husqvarna 539130317

PIN

$20.99

$

Usually ships in 3-10 days

0

44

Husqvarna 539976988

HAIRPIN COTTER

$3.99

$

Usually ships in 3-10 days

0

45

Husqvarna 539990055

WASHER 1/4 FLAT SAE

$3.99

$

In Stock, Qty 19

0

46

Husqvarna 539108084

WASHER, 3/16 x 3/4 x 16 GA

$4.99

$

In Stock, Qty 15

0

47

Husqvarna 539910935

WASHER

$4.99

$

In Stock, only 3 left!

0

48

Husqvarna 539990118

WASHER 3/8 SPLT LOCK
(Superseded to 596238701)

$4.99

$

In Stock, Qty 15

0

49

Husqvarna 539990122

WASHER 3/8 SAE FLT
(Superseded to 596565301)

$3.99

$

In Stock, Qty 20+

0

50

Husqvarna 539109552

WASHER 3/16 LOCK

$4.99

$

Usually ships in 3-10 days

0

51

Husqvarna 539110323

WASHER, HARDENED
(Superseded to 532140296)

$6.99

$

In Stock, only 2 left!

0

52

Husqvarna 539990316

RHSNB 5/16-18 x 3/4
(Superseded to 595901601)

$3.99

$

In Stock, Qty 20+

0

53

Husqvarna 539990208

RHSNB 5/16-18 x 1

$3.99

$

Usually ships in 3-10 days

0

54

Husqvarna 539990645

RHSNB 3/8-16 x 1

$

$

Not available

55

Husqvarna 539990643

HCS 1/4-20 x 7/8

$3.99

$

Usually ships in 3-10 days

0

56

Husqvarna 539990655

HCS 3/8-16 x 1 1/2

$4.99

$

In Stock, only 2 left!

0

57

Husqvarna 539108461

HCS 1/4-20 x 1/2

$4.99

$

In Stock, Qty 5

0

58

Husqvarna 539990209

HCS 5/16-18 x 1

$1.99

$

Usually ships in 3-10 days

0

59

Husqvarna 539976949

HCS 3/8-16 x 1 3/4

$3.99

$

Usually ships in 3-10 days

0

60

Husqvarna 539976952

SCREW 10-24 x .625 RD
(Superseded to 596039001)

$3.99

$

In Stock, Qty 17

0

61

Husqvarna 539990302

SCREW 1/4 x 3/8 THRD FRM

$

$

Not available

62

Husqvarna 539104763

RETAINER, U TYPE

$6.49

$

In Stock, Qty 12

0

63

Husqvarna 539108089

WELD NUT, PLATED
(Superseded to 596987401)

$3.99

$

In Stock, Qty 20+

0
