961120115-06 - Poulan Walk-Behind Mower (2015-01) FRAME ENGINE Parts Diagram

Walk-Behind Mower

FRAME ENGINE Parts Diagram

  • Title
1

Poulan 532196025

BAIL.CONT.D.STRAIGHT.PUSH.BLK

$

$

Not available

2

Poulan 581902101

Rope Guide, Blk Zinc Chrom

$

$

Not available

3

Poulan 532125078

WASHER.ENGINE.BZP

$5.99

$

Usually ships in 3-10 days

0

4

Poulan 532196026

HANDLE.UPPER.FGD/PUSH.BLACK

$28.99

$

Usually ships in 3-10 days

0

5

Poulan 532155044

LOWER HANDLE
(Superseded to 532151590)

$22.99

$

In Stock, only 1 left!

0

6

Poulan 581912601

T-KNOB.NEW ROPE GUIDE

$4.99

$

In Stock, only 2 left!

0

7

Poulan 532191574

BOLT, HANDLE 5/16-18X1.75

$6.99

$

In Stock, only 2 left!

0

8

Poulan 532430034

BRACKET.UPSTOP.RT

$6.99

$

In Stock, only 3 left!

0

9

Poulan 532189241

SCREW.HEX.WASH.HD.TAPPING

$6.49

$

Usually ships in 3-10 days

0

10

Poulan 532440934

CABLE.MZR.RATO.22"LOW.

$17.99

$

In Stock, only 4 left!

0

11

$7.49

$

In Stock, Qty 20+

0

12

Poulan 532066426

TIE GUIDE
(Superseded to 532124756)

$9.49

$

Usually ships in 3-10 days

0

13

Poulan 532051793

HAIRPIN COTTER

$7.49

$

Usually ships in 3-10 days

0

14

Poulan 532191938

(Superseded to 532189713)

$9.49

$

In Stock, Qty 13

0

15

Poulan 532432040

GUARD.DISCHARGE.ECON.BLK.US/CE
(Superseded to 596215201)

$11.99

$

In Stock, only 1 left!

0

16

Poulan 532850263

(Superseded to 810040600)

$1.99

$

Usually ships in 3-10 days

0

18

Poulan 532851074

WASHER,HARDEN

$4.99

$

In Stock, only 2 left!

0

19

Poulan 532411832

SPRING.SIDE.DISCHARGE

$5.99

$

In Stock, only 4 left!

0

20

Poulan 532145106

Mower Blade, 20" Mulching

$20.99

$

In Stock, only 1 left!

0

21

Poulan 532088602

HINGE DEFLECTOR

$4.99

$

Usually ships in 3-10 days

0

22

Poulan 532150215

HINGE ROD

$6.49

$

Usually ships in 3-10 days

0

23

Poulan 532189240

SKIRT.ECON.20.SD.WHL.ADJ
(Superseded to 583181001)

$

$

Not available

24

Poulan 532410594

WHEEL ADJ BRACKET FRONT
(Superseded to 532407494)

$4.99

$

In Stock, only 2 left!

0

25

Poulan 581547901

ADAPTOR.BLADE.7/8

$17.99

$

In Stock, Qty 20+

0

26

Poulan 532170975

HANDLE BRACKET ASM. RH
(Superseded to 532170345)

Note: RH

$7.49

$

In Stock, only 1 left!

0

27

Poulan 532170977

HANDLE BRACKET ASM. LH
(Superseded to 532170346)

Note: LH

$7.49

$

In Stock, only 1 left!

0

28

Poulan 532061537

WASHER
(Superseded to 819132012)

$1.99

$

Usually ships in 3-10 days

0

29

Poulan 532401629

SPACER.HEIGHT.ADJUSTER

$6.49

$

In Stock, only 4 left!

0

30

Poulan 000000000

Note: B S 9L602-0009-F1 FOR SERVICE PARTS 1-800-233-3723

$

$

Not available

31

Poulan 532406428

SELECTOR SPRING, FRONT
(Superseded to 532401621)

$5.99

$

In Stock, only 2 left!

0

32

$6.49

$

In Stock, only 1 left!

0

33

Poulan 532407871

AXLE ARM ASSY.
(Superseded to 532401179)

$7.49

$

In Stock, only 1 left!

0

34

Poulan 532401630

WASHER.CURVED.CYLINDRICAL

$4.99

$

In Stock, only 3 left!

0

35

Poulan 532401638

SHOULDER BOLT 5/16-18
(Superseded to 596203801)

$4.99

$

In Stock, Qty 8

0

36

Poulan 532440356

WHEEL.7X1.5.DMD.3SPK.BLACK.
(Superseded to 532436482)

$13.99

$

Usually ships in 3-10 days

0

37

Poulan 532409148

NUT.HEX.FLANGE.3/8-16.LOCKNUT
(Superseded to 532409149)

$4.99

$

In Stock, Qty 20+

0

38

Poulan 532150406

BOLT 3/8-16X1-1/8

$7.49

$

Usually ships in 3-10 days

0

39

Poulan 581708364

KIT.HSG.20SD.PUSH.MS665.TRI

$87.99

$

Usually ships in 3-10 days

0

40

Poulan 532851084

SCREW, HEX HD 3/8-24 X 1-3/8
(Superseded to 532435345)

$4.99

$

In Stock, Qty 20+

0

41

Poulan 532149741

SCREW.5/16-18X3/4
(Superseded to 532171877)

$7.49

$

In Stock, Qty 6

0

42

Poulan 532404763

No Step Decal
(Superseded to 532182166)

$4.99

$

In Stock, only 3 left!

0

43

Poulan 873800500

NUT.71038.31-18.HEX.NYLOCK
(Superseded to 596040501)

$3.99

$

In Stock, Qty 20+

0

44

Poulan 532197991

CLIP.CABLE.BLK

$7.49

$

In Stock, Qty 6

0

56

Poulan 873800400

LOCKNUT.NYLOC.1/4-20
(Superseded to 595086601)

$3.99

$

Usually ships in 3-10 days

0

60

Poulan 532410594

WHEEL ADJ BRACKET FRONT
(Superseded to 532407494)

$4.99

$

In Stock, only 2 left!

0

Poulan 532404764

Warning Decal

$8.99

$

Usually ships in 3-10 days

0
