895409 (MP-3132) - Gravely Tow-Behind Mulching Mower Attachment (SN: 000101 & Above) Wing Driveshaft Parts Diagram

Tow-Behind Mulching Mower Attachment

Wing Driveshaft Parts Diagram

  • Title

1

Gravely 02862300

Yoke, Complete Collar

$

$

Not available

2

Gravely 02838800

Kit, Cross and Bearing

$

$

Not available

3

Gravely 07001406

Fitting, Grease 45 Degree 8 mm x 1 mm x .88

$

$

Not available

4

Gravely 02868400

Yoke, Outer Tube

$

$

Not available

5

Gravely 05800120

Roll Pin, Inner Yoke

$

$

Not available

6

Gravely 02862400

Tube Assembly (includes items 4, 5 &17)

Note: (includes items 4, 5 &17)

$

$

Not available

7

Gravely 07100639

Tube, Inner

$

$

Not available

8

Gravely 05800121

Roll Pin, Inner Yoke

$

$

Not available

9

Gravely 02868300

Yoke, Inner Tube

$

$

Not available

10

Gravely 02859100

Guard, Outer Collar Retaining

$

$

Not available

11

Gravely 02885000

Fastener, Shield

$

$

Not available

12

Gravely 02859000

Guard, Inner Collar Retaining

$

$

Not available

13

Gravely 02839000

Chain, Safety

$

$

Not available

14

Gravely 02862500

Shield, Complete With Instructions

$

$

Not available

15

Gravely 02862600

Shaft, Female Half With Shields

$

$

Not available

16

Gravely 02862700

Shaft, Male Half With Shields

$

$

Not available

17

Gravely 02868800

Decal, Danger

$

$

Not available

18

Gravely 02868600

Decal, Danger Driveline

$

$

Not available

19

Gravely 02241400

Kit, Ball Collar 1.38

$

$

Not available

20

Gravely 04260600

Male Tube & Yoke w/Roll Pin

$

$

Not available

21

Gravely 04260700

Push Pin Yoke Assembly

$

$

Not available

N/A

Gravely 02862000

Driveline Assembly, Left or Right Complete (Includes Items 1 – 19)

Note: (Includes Items 1 – 19)

$

$

Not available
