85-48MS01 - Toro 48" Side-Discharge Mower Deck (1978) REAR AND SIDE DISCHARGE MOWERS-36 IN. (92 CM) VEHICLE IDENTIFICATION NUMBERS 85-36MR01,95-36MR00,85 Parts Diagram

48" Side-Discharge Mower Deck

REAR AND SIDE DISCHARGE MOWERS-36 IN. (92 CM) VEHICLE IDENTIFICATION NUMBERS 85-36MR01,95-36MR00,85 Parts Diagram

  • Title

1

Toro 106632

Mower Deck-Rear Discharge

$

$

Not available

1

Toro 106633

Mower Deck-Side Discharge
(Superseded to 107993)

$

$

Not available

2

Toro 5240

Roller
(Superseded to 94-1599)

$13.99

$

In Stock, Qty 16

0

3

Toro 102773

SPRING ROLLER STOP

$

$

Not available

4

Toro 102770

Roller Shaft
(Superseded to 110847)

$28.99

$

In Stock, Qty 5

0

5

Toro 908002

H H C S
(Superseded to 321-3)

$1.49

$

In Stock, Qty 20+

0

6

Toro 915111

Nut
(Superseded to 3217-5)

$0.99

$

In Stock, Qty 8

0

7

Toro 106479

Belt Cover L.H.

$

$

Not available

8

Toro 926671

Bolt
(Superseded to 9266714)

$1.49

$

In Stock, Qty 20+

0

9

Toro 103585

Extension-Chute
(Superseded to 106480-01)

$102.99

$

Usually ships in 3-6 days

0

10

Toro 101722

Gage Wheel Support Assy.

$

$

Not available

11

Toro 101714

Bracket-R.H. Upper

$

$

Not available

12

Toro 101716

Bracket-Lower R.H.

$

$

Not available

13

Toro 101723

Quadrant

$

$

Not available

14

Toro 908032

Bolt
(Superseded to 323-4)

$3.99

$

In Stock, Qty 20+

0

15

Toro 915113

Nut
(Superseded to 32153-2)

$0.99

$

In Stock, Qty 13

0

16

Toro 900065

Bolt
(Superseded to 323-14)

$3.99

$

In Stock, Qty 20+

0

17

Toro 915113

Nut
(Superseded to 32153-2)

$0.99

$

In Stock, Qty 13

0

18

Toro 920009

Washer
(Superseded to 3256-24)

$0.99

$

In Stock, Qty 20+

0

19

Toro 101715

Bracket-L.H. Upper

$

$

Not available

20

Toro 101717

Bracket-L.H. Lower

$

$

Not available

21

Toro 900064

Bolt
(Superseded to 3231-25)

$1.99

$

In Stock, Qty 20+

0

22

Toro 915113

Nut
(Superseded to 32153-2)

$0.99

$

In Stock, Qty 13

0

23

Toro 102431

Lever
(Superseded to 102431-01)

$

$

Not available

24

Toro 101853

SPRING-COMPRESSION

$1.49

$

In Stock, only 3 left!

0

25

Toro 102597

GRIP

$2.49

$

Usually ships in 3-6 days

0

26

Toro 101719

SUPPORT LINK R

$

$

Not available

27

Toro 101713

WHEEL SUPPORT LINK

$

$

Not available

28

Toro 102704

SPACER

$2.99

$

In Stock, Qty 8

0

29

Toro 900063

Bolt
(Superseded to 323-12)

$2.99

$

In Stock, Qty 20+

0

30

Toro 102809

LOCKNUT-FLANGE
(Superseded to 32128-19)

$1.49

$

In Stock, Qty 20+

0

31

Toro 106588

Wheel 6 x 1.75
(Superseded to 110506)

$42.99

$

In Stock, Qty 10

0

32

Toro 920211

WASHER

$

$

Not available

33

Toro 5188

BOLT-SHOULDER

$6.49

$

In Stock, Qty 14

0

34

Toro 915113

Nut
(Superseded to 32153-2)

$0.99

$

In Stock, Qty 13

0

35

Toro 105206

Caution Decal
(Superseded to 93-1122)

$9.99

$

In Stock, Qty 12

0

36

Toro 106746

Decal-Caution
(Superseded to 66-1340)

$10.99

$

In Stock, only 3 left!

0

37

Toro 920242

WASHER

$6.49

$

Usually ships in 3-6 days

0

38

Toro 106748

DECAL-HEIGHT & BELT

$11.99

$

In Stock, only 2 left!

0

39

Toro 106478

Belt Cover R.H.

$

$

Not available

40

Toro 810012R1

Operating and Maintenance Instructions

$

$

Currently unavailable
