81180 (LT 12 G) - Lawn-Boy Lawn Tractor (SN: 004900001 - 004999999) (1994) BRAKE ASSEMBLY (38" CUTTING UNIT)(MODEL NO. 81180 & 81191 ONLY) Parts Diagram

Lawn Tractor

BRAKE ASSEMBLY (38" CUTTING UNIT)(MODEL NO. 81180 & 81191 ONLY) Parts Diagram

  • Title
1

Lawn-Boy 323-12

Screw-Hex Hd. Cap

$2.49

$

In Stock, Qty 10

0

2

Lawn-Boy 7-0030

Bolt-Shoulder

$9.49

$

In Stock, only 2 left!

0

3

Lawn-Boy 88-4590

Bolt-Shoulder

$11.99

$

In Stock, only 1 left!

0

4

Lawn-Boy 88-6100

Brake-Deck (Incl. Ref. #26 & 27)

$64.99

$

In Stock, only 3 left!

0

5

Lawn-Boy 88-5550

Rod-Deck Brake L.H.

$19.99

$

Usually ships in 3-6 days

0

6

Lawn-Boy 3296-42

Nut-Lock

$0.99

$

In Stock, Qty 9

0

7

Lawn-Boy 88-5910

Spring-Torsion

$33.99

$

Usually ships in 3-6 days

0

8

Lawn-Boy 88-6130

Spring-Deck Engage

$13.99

$

In Stock, only 1 left!

0

9

Lawn-Boy 92-8934

Spring-Extension

$12.99

$

In Stock, only 1 left!

0

10

Lawn-Boy 88-5390

Bellcrank
(Superseded to 88-5390-03)

$138.99

$

Usually ships in 3-6 days

0

11

Lawn-Boy 3256-68

Washer-Fender

$2.99

$

In Stock, only 4 left!

0

12

Lawn-Boy 88-5970

Hook-Spring Return
(Superseded to 138-7267)

$2.99

$

In Stock, Qty 8

0

13

Lawn-Boy 3296-29

Nut-Lock

$2.49

$

In Stock, Qty 20+

0

14

Lawn-Boy 3256-23

Washer-Flat

$2.49

$

In Stock, Qty 20+

0

15

Lawn-Boy 322-5

Screw-Hex Hd. Cap

$0.99

$

In Stock, Qty 20+

0

16

Lawn-Boy 88-4980

Bushing-Idler Arm

$16.99

$

In Stock, only 4 left!

0

17

Lawn-Boy 88-6250

V-Belt-Deck

$51.99

$

In Stock, only 4 left!

0

18

Lawn-Boy 88-5330

Pulley-Deck

$122.99

$

In Stock, only 2 left!

0

19

Lawn-Boy 3219-6

Nut-Lock

$3.99

$

In Stock, Qty 20+

0

20

Lawn-Boy 3296-39

Nut-Lock

$2.99

$

In Stock, Qty 8

0

21

Lawn-Boy 88-4870

Arm-Idler
(Superseded to 88-4870-03)

$58.99

$

Usually ships in 3-6 days

0

22

Lawn-Boy 88-5540

Rod-Deck Brake R.H.

$19.99

$

Usually ships in 3-6 days

0

23

Lawn-Boy 88-5630

Pulley-Idler
(Superseded to 132-4717)

$22.99

$

In Stock, only 1 left!

0

24

Lawn-Boy 88-5070

Guide-Idler Belt
(Superseded to 138-7270)

$2.99

$

In Stock, Qty 5

0

25

Lawn-Boy 3256-24

Washer-Flat

$0.99

$

In Stock, Qty 14

0

26

Lawn-Boy 3290-282

Rivet-Pop

$0.99

$

In Stock, Qty 8

0

27

Lawn-Boy 56-9830

Pad-Brake

$33.99

$

Usually ships in 3-6 days

0

28

Lawn-Boy 67-0710

Ball-Swivel

$4.49

$

In Stock, only 2 left!

0
