810 EPT - Poulan Pole Saw Shaft Parts Diagram

Pole Saw

Shaft Parts Diagram

  • Title

1

Poulan 530071788

Kit - Lower Shaft Assy.

Note: (Incl. flex shaft)

$66.99

$

In Stock, only 2 left!

0

2

Poulan 530071964

Kit - Shield Assy.

Note: (Incl. 3,4)

$

$

Not available

3

Poulan 530052286

Limiter - Line

$

$

Not available

4

Poulan 530015814

Screw

$6.49

$

In Stock, Qty 16

0

5

Poulan 530015820

Bolt

$4.99

$

In Stock, only 1 left!

0

6

Poulan 530016152

Wingnut
(Superseded to 530401992)

$2.49

$

In Stock, only 1 left!

0

7

Poulan 530095776

Assy - Hub w/arbor
(Superseded to 530071306)

Note: (Incl. 8,9)

$

$

Not available

8

Poulan 530053241

Spring - Return

$

$

Not available

9

Poulan 530401957

Retainer - Spool

$4.99

$

In Stock, only 4 left!

0

10

Poulan 952711616

Accy. - Wound Spool

$

$

Not available

11

Poulan 952711621

Accy. - Cutting Head Assembly

$

$

Not available

11

Poulan 530056220

Decal - Shaft Warning
(Superseded to 545209101)

Note: Not Shown

$

$

Not available

11

Poulan 530150358

Decal - Shield Warning

Note: Not Shown

$

$

Not available
