78449 - Toro 48" Side-Discharge Mower Deck for 5xi Tractors (SN: 240000001 - 240999999) (2004) REINFORCEMENT PLATE ASSEMBLY Parts Diagram

48" Side-Discharge Mower Deck for 5xi Tractors

REINFORCEMENT PLATE ASSEMBLY Parts Diagram

  • Title

1

Toro 3230-1

BOLT-CARR

$1.99

$

In Stock, Qty 20+

0

2

Toro 113603

ROLLER-SHAFT

$46.99

$

Usually ships in 3-6 days

0

3

Toro 113349

ROLLER-ANTI SCALP

$78.99

$

In Stock, only 2 left!

0

4

Toro 3296-29

NUT-LOCK, NI

$2.49

$

In Stock, Qty 20+

0

5

Toro 95-3879-01

PLATE-REINFORCE

$338.99

$

Usually ships in 3-6 days

0

6

Toro 95-3949-01

COVER-BELT, RH

$197.99

$

Usually ships in 3-6 days

0

7

Toro 46-8560

SCREW-HHFTF

$1.99

$

In Stock, Qty 20+

0

8

Toro 95-3950-01

COVER-BELT, LH

$

$

Not available

9

Toro 3296-39

NUT-LOCK, NI

$2.99

$

In Stock, Qty 20+

0

10

Toro 94-7642-01

BRACKET-GUIDE

$

$

Not available

11

Toro 3256-41

WASHER

$1.99

$

In Stock, Qty 6

0

12

Toro 95-3953

GUIDE-BELT

$

$

Not available

13

Toro 9335054

PIN-HAIR

$1.99

$

In Stock, Qty 20+

0

14

Toro 283-2

PIN-CLEVIS

$13.99

$

In Stock, only 2 left!

0

15

Toro 3256-24

WASHER-FLAT

$0.99

$

In Stock, Qty 20+

0

16

Toro 68-2730

WHEEL-GAGE
(Superseded to 1-603299)

$23.99

$

In Stock, Qty 20+

0

17

Toro 68-2350

GAGE-WHEEL

$135.99

$

Usually ships in 3-6 days

0

18

Toro 3272-21

PIN-COTTER

$3.49

$

In Stock, only 3 left!

0

19

Toro 29-4820

ROLLER

$18.99

$

In Stock, Qty 8

0

20

Toro 3231-25

BOLT-CARR
(Superseded to 119-4162)

$1.99

$

In Stock, Qty 20+

0

21

Toro 118960-03

Shaft-Roller

$43.99

$

In Stock, only 3 left!

0

22

Toro 105-1528

48" DECK/DECAL ASM-5XI,EU

$

$

Not available

22:2

Toro 93-7317

DECAL-DANGER

$

$

Not available

23

Toro 9152366

NUT-HJ

$3.49

$

In Stock, only 1 left!

0

24

Toro 93-1633

WASHER

$2.99

$

In Stock, Qty 14

0

25

Toro 99-3707

CHUTE ASM

$

$

Not available

25:2

Toro 93-7316

DECAL-DANGER

$10.99

$

In Stock, Qty 20+

0

26

Toro 116080

BUSHING-PIVOT

$19.99

$

Usually ships in 3-6 days

0

27

Toro 93-1630

SPRING-DEFLECTOR

$19.99

$

Usually ships in 3-6 days

0

28

Toro 3256-26

WASHER-FLAT

$0.99

$

In Stock, Qty 20+

0

29

Toro 3272-10

PIN-COTTER

$1.49

$

In Stock, Qty 11

0

30

Toro 3296-16

NUT-LOCK, NI

$1.49

$

In Stock, only 3 left!

0

31

Toro 3256-1

WASHER-FLAT

$0.99

$

In Stock, Qty 20+

0

32

Toro 95-2747

FITTING-WASHOUT
(Superseded to 133-9289)

$6.49

$

In Stock, Qty 20+

0

33

Toro 46-6290

O-RING

$2.99

$

In Stock, Qty 14

0

34

Toro 3229-1

BOLT-CARR

$3.99

$

In Stock, Qty 20+

0

35

Toro 321-4

SCREW-HH

$1.49

$

In Stock, Qty 20+

0

36

Toro 3296-42

NUT-LOCK, NI

$0.99

$

In Stock, Qty 20+

0

37

Toro 46-8560

SCREW-HHFTF

$1.99

$

In Stock, Qty 20+

0

38

Toro 98-5032

SPRING-GAGE WHEEL, LH

$

$

Not available

39

Toro 98-5033

SPRING-GAGE WHEEL, RH

$

$

Not available

40

Toro 3231-22

SCREW-CARR

$3.49

$

In Stock, Qty 20+

0
