76 (0350001U) - Cub Cadet Lawn Tractor Engine Controls & Pedestal Parts Diagram

Lawn Tractor

Engine Controls & Pedestal Parts Diagram

  • Title
1

Cub Cadet 746-3007

Control Assy, Throttle
(Superseded to 946-3007)

$54.99

$

In Stock, only 1 left!

0

Screw, No. 6-32 X 3/8 C-Z Str Pan Hd Mach

Note: (Common Hardware, Purchase Locally)

$

$

Not available

Washer, .156 X .075 X .036 Znd

Note: (Common Hardware, Purchase Locally)

$

$

Not available

2

Cub Cadet 731-0108

Knob, Throttle Control

$9.49

$

In Stock, only 2 left!

0

3

Cub Cadet 703-0370

Pedestal Assy

$

$

Currently unavailable

Cub Cadet 710-3053

Screw, 5/16-18 X 5/8 Bevel Washer Hd Cap

$

$

Not available

Screw, 5/16-18 X 1 Washer Hd Cap

Note: (Common Hardware, Purchase Locally)

$

$

Not available
