74206 - Toro 52" Side-Discharge Mower Deck (SN: 089000001 - 089999999) (1998) ROLLERS, BELT AND COVERS Parts Diagram

52" Side-Discharge Mower Deck

ROLLERS, BELT AND COVERS Parts Diagram

  • Title
1

Toro 98-3770

Deck/Decal ASM
(Superseded to 106-5879)

$

$

Not available

2

Toro 40-0340

SHAFT-ROLLER, REAR

$30.99

$

In Stock, only 1 left!

0

3

Toro 36-1740

ROLLER-DECK

$45.99

$

In Stock, only 3 left!

0

4

Toro 3272-11

PIN-COTTER

$1.49

$

In Stock, Qty 20+

0

7

Toro 323-28

SCREW-HH

$8.49

$

In Stock, Qty 20+

0

8

Toro 98-5967

SPACER-WHEEL

$15.99

$

In Stock, Qty 20+

0

9

Toro 68-2730

WHEEL-GAGE
(Superseded to 1-603299)

$23.99

$

In Stock, Qty 20+

0

10

Toro 3256-24

WASHER-FLAT

$0.99

$

In Stock, Qty 20+

0

11

Toro 3296-39

NUT-LOCK, NI

$2.99

$

In Stock, Qty 20+

0

12

Toro 98-3777

SPACER-WHEEL

$56.99

$

Usually ships in 3-6 days

0

13

Toro 98-5961

SCREW-HH

$5.49

$

In Stock, Qty 20+

0

14

Toro 29-5590-03

BRACKET-PIVOT

$

$

Not available

15

Toro 3230-18

SCREW-CARR

$5.49

$

In Stock, Qty 20+

0

16

Toro 32152-1

NUT-LOCK, CONE

$1.99

$

In Stock, Qty 8

0

17

Toro 40-6230

SPRING

$39.99

$

Usually ships in 3-6 days

0

18

Toro 98-5984

DEFLECTOR ASM, 52" W/DECAL

$192.99

$

Usually ships in 3-6 days

0

19

Toro 3211-15

SCREW-HH

$9.49

$

Usually ships in 3-6 days

0

20

Toro 3296-5

NUT-HEX

$3.49

$

In Stock, Qty 20+

0

21

Toro 98-5963

COVER ASM-RH

$

$

Not available

22

Toro 98-5965

LH COVER ASM

$

$

Not available

23

Toro 98-5975

WASHER-BELLEVILLE

$3.49

$

In Stock, Qty 20+

0

24

Toro 32128-17

NUT-LOCK, FLANGE

$0.99

$

In Stock, Qty 17

0

25

Toro 249-21

CLAMP-SLOTTED

$20.99

$

Usually ships in 3-6 days

0

26

Toro 3290-321

SCREW-HWH

$4.49

$

Usually ships in 3-6 days

0

27

Toro 54-9220

DECAL-DANGER
(Superseded to 93-1122)

$9.99

$

In Stock, Qty 12

0

29

Toro 66-6380

DECAL-DANGER

$8.99

$

Usually ships in 3-6 days

0

30

Toro 98-5954

DECAL-COVER, MISSING

$9.49

$

In Stock, Qty 7

0

31

Toro 94-6281

DECAL BELT INSTALLATION

$

$

Not available

32

Toro 67-5360

DECAL-DANGER

$15.99

$

In Stock, only 1 left!

0

33

Toro 43-8480

DECAL-DANGER

$6.99

$

In Stock, Qty 6

0

34

Toro 93-7818

DECAL-TORQUE, BLADE BOLT

$12.99

$

In Stock, only 2 left!

0

35

Toro 98-3798

DECAL-WHEEL, GAGE

$18.99

$

Usually ships in 3-6 days

0

36

Toro 98-5953

DECAL

$68.99

$

Usually ships in 3-6 days

0

37

Toro 94-6225

DECAL - SAFETY

$

$

Not available

38

Toro 98-3269

DECAL

$43.99

$

Usually ships in 3-6 days

0

39

Toro 66-1340

DECAL-DANGER, THROWN OBJECT

$10.99

$

In Stock, only 3 left!

0
