7-1321 - Toro 42" Sickle Bar Attachment (1972) PARTS LIST FOR ROTARY MOWER MODEL 5-1421 Parts Diagram

42" Sickle Bar Attachment

PARTS LIST FOR ROTARY MOWER MODEL 5-1421 Parts Diagram

  • Title

1

Toro 6690

Ass-y. Deck 42" Mower

$

$

Not available

2

Toro 4299

Housing

$

$

Not available

3

Toro 1508

NEEDLE BEARING
(Superseded to 252-6)

$13.99

$

In Stock, Qty 13

0

4

Toro 1303

Seal
(Superseded to 100441)

$9.99

$

In Stock, only 1 left!

0

5

Toro 4566

Fitting-Grease

$

$

Not available

6

Toro 900063-4

Bolt 3/8-16 x 1

$

$

Currently unavailable

7

Toro 915663-4

3/8-16 E.S.

$

$

Currently unavailable

8

Toro 5875

Shaft Spindle
(Superseded to 101686)

$

$

Not available

9

Toro 5951

WASHER

$

$

Not available

10

Toro 1515

Ball
(Superseded to 101480)

$56.99

$

In Stock, only 3 left!

0

11

Toro 936029

INT SNAP RING

$3.49

$

Usually ships in 3-6 days

0

12

Toro 6692

Center Pulley
(Superseded to 106847)

$

$

Not available

13

Toro 5877

End Pulley
(Superseded to 106846)

$

$

Not available

14

Toro 2844

WASHER

$2.99

$

In Stock, Qty 17

0

15

Toro 908033-6

Bolt 3/8-16 x 7/8

$

$

Currently unavailable

16

Toro 3716

SPINDLE CUP

$

$

Not available

17

Toro 933211

SPIROL ROLL PIN

$2.49

$

Usually ships in 3-6 days

0

18

Toro 6693

Blade 14"
(Superseded to 100200)

$

$

Not available

19

Toro 1336

WASHER

$

$

Not available

20

Toro 908033-5

Bolt 3/8-16 x 7/8

$

$

Currently unavailable

21

Toro 5240

Roller
(Superseded to 94-1599)

$13.99

$

In Stock, Qty 16

0

22

Toro 5241

Shaft
(Superseded to 101881)

$16.99

$

Usually ships in 3-6 days

0

23

Toro 932017-4

Cotter Pin

$

$

Currently unavailable

24

Toro 6694

Washer
(Superseded to 700852)

$

$

Not available

25

Toro 6699

ROD LIFT

$

$

Not available

26

Toro 933504-4

Hairpin

$

$

Currently unavailable

27

Toro 6739

TRUNNION-LIFT

$24.99

$

In Stock, Qty 5

0

28

Toro 6702

Bracket Deck R.H.

$

$

Not available

29

Toro 6703

Bracket Deck L.H.

$

$

Not available

30

Toro 900062.4

Bolt Carriage 3/8-16 x 3/4

$

$

Currently unavailable

31

Toro 2138

SPACER

$

$

Not available

32

Toro 908035-4

Bolt 3/8-16 x 1

$

$

Currently unavailable

33

Toro 920009-4

Washer

$

$

Currently unavailable

34

Toro 6705

Leveler
(Superseded to 100087)

$

$

Not available

35

Toro 915112-4

Nut, 5/16-18

$

$

Currently unavailable

36

Toro 6701

Quadrant

$

$

Not available

37

Toro 900062-4

Bolt-3/8-16 x 3/4

$

$

Currently unavailable

38

Toro 6706

Ass-y. Gage Wheel Support

$

$

Not available

39

Toro 5701

E Ring
(Superseded to 32120-47)

$1.49

$

In Stock, Qty 8

0

40

Toro 4480

Wheel
(Superseded to 110506)

$42.99

$

In Stock, only 2 left!

0

41

Toro 5188

BOLT-SHOULDER

$6.49

$

In Stock, Qty 6

0

42

Toro 915236-4

3/8-16 Jam Nut

$

$

Currently unavailable

43

Toro 933188

Roll Pin
(Superseded to 32121-93)

$

$

Not available

44

Toro 920011-4

Washer

$

$

Currently unavailable

45

Toro 6710

ASSY LATCH & SHAF R

$

$

Not available

46

Toro 933512-4

Hairpin

$

$

Currently unavailable

47

Toro 6704

Pin

$

$

Not available

48

Toro 6712

MOUNTING BRACKET R

$231.99

$

Usually ships in 3-6 days

0

49

Toro 4497

PLATE-MTG BRKT LH R (NS)

$

$

Not available

50

Toro 908034-4

Bolt 3/8-16 x 1

$

$

Currently unavailable

51

Toro 6713

SUPPORT MTG PLATE

$

$

Not available

52

Toro 6714

ROLLER

$

$

Not available

53

Toro MW-4564

Lock Rod

$

$

Currently unavailable

54

Toro 4974

PULLEY IDLER

$

$

Not available

55

Toro 4567

BEARING

$

$

Not available

56

Toro 936024

INTERNAL SNAPRING

$

$

Not available

57

Toro 6638

SPACER

$

$

Not available

58

Toro 908036-4

Bolt, 3/8-16 x 1/2

$

$

Currently unavailable

59

Toro 915113-6

Nut

$

$

Currently unavailable

60

Toro 6715

ASSY BAR IDLER SUPPO

$

$

Not available

61

Toro 6719

Idler Pulley
(Superseded to 92-7101)

$34.99

$

Usually ships in 3-6 days

0

62

Toro 6720

Side Block
(Superseded to 742659)

$

$

Not available

63

Toro 900039-4

Bolt-5/16-18 x 1/4

$

$

Currently unavailable

64

Toro 915662-4

Nut 5/16-18

$

$

Currently unavailable

65

Toro 920008-4

Washer

$

$

Currently unavailable

66

Toro 6651

SPRING R

$24.99

$

In Stock, only 1 left!

0

67

Toro 900040-4

Bolt-5/16-18 x 1 1/2

$

$

Currently unavailable

68

Toro 6748

SLIDE

$

$

Not available

69

Toro 6747

ANGLE

$

$

Not available

70

Toro 7677

Rod Height Control

$

$

Not available

71

Toro 6722

Grip Handle

$

$

Not available

72

Toro 933505-4

Hairpin

$

$

Currently unavailable

73

Toro 6723

Clip-Axle

$

$

Not available

74

Toro 6724

SUPPORT AXLE

$24.99

$

In Stock, only 1 left!

0

75

Toro 900066-4

Bolt-Carriage

$

$

Currently unavailable

76

Toro 900064-4

Bolt Carriage 3/8-16 x 1

$

$

Currently unavailable

77

Toro 920009-4

Washer

$

$

Currently unavailable

78

Toro 6725

ARM PIVOT R
(Superseded to 6725-01)

$

$

Not available

79

Toro 4736

RING LAM L 262

$

$

Not available

80

Toro MW-10391

Spring

$

$

Currently unavailable

81

Toro 6726

Cover
(Superseded to 106080-01)

$

$

Not available

82

Toro 5924

HEX NUT 10-32 E.S.

$

$

Not available

83

Toro 915112-6

Nut-Nylok

$

$

Currently unavailable

84

Toro 6727

Cam Arm

$

$

Not available

85

Toro 7068

ASSEMBLY CAM LEVE R

$

$

Not available

86

Toro 6733

Ass-y Idle Support

$

$

Not available

87

Toro 6736

Nut

$

$

Not available

88

Toro 6814

SPACER

$

$

Not available

89

Toro 920156

Lockwasher-3/8 Int.Tooth
(Superseded to 3254-6)

$0.99

$

Usually ships in 3-6 days

0

90

Toro 6740

PULLEY IDLER

$

$

Not available

91

Toro 908033-4

Bolt 3/8-16 x 7/8

$

$

Currently unavailable

92

Toro 2844

WASHER

$2.99

$

In Stock, Qty 17

0

93

Toro 920083-4

Lockwasher

$

$

Currently unavailable

94

Toro 6737

Screw
(Superseded to 9782)

$33.99

$

Usually ships in 3-6 days

0

95

Toro 6738

V BELT

$35.99

$

In Stock, only 1 left!

0

96

Toro 4580

Decal Belt Installation

$

$

Currently unavailable

97

Toro 4410

Decal
(Superseded to 102832)

$

$

Not available

98

Toro 4570

Decal
(Superseded to 93-1122)

$9.99

$

In Stock, Qty 12

0
