62933 - Toro Lawn Blower, 5hp (SN: 004000001 - 004999999) (1974) BLOWER ASSEMBLY Parts Diagram

Lawn Blower, 5hp

BLOWER ASSEMBLY Parts Diagram

  • Title

1

Toro 19-4050

KNOB

$17.99

$

In Stock, only 2 left!

0

2

Toro 20-5780

INTAKE-BLOWER

$125.99

$

Usually ships in 3-6 days

0

3

Toro 20-5450

Blower Cover
(Superseded to 20-5450-01)

$

$

Not available

4

Toro 32149-1

NUT-KEPS

$6.49

$

In Stock, Qty 9

0

5

Toro 20-5470

Fan
(Superseded to 37-9230-03)

$

$

Not available

6

Toro 20-5890

Blower Housing
(Superseded to 20-5890-01)

$1245.99

$

Usually ships in 3-6 days

0

7

Toro 7-0036

KEY-SQUARE

$

$

Not available

8

Toro 3230-3

SCREW-CARR

$1.49

$

In Stock, Qty 20+

0

9

Toro 20-7910

Decal, Caution
(Superseded to 37-9260)

$

$

Not available

10

Toro 20-5830

Mounting Bracket
(Superseded to 39-4660-03)

$

$

Not available

11

Toro 3296-29

NUT-LOCK, NI

$2.49

$

In Stock, Qty 20+

0

12

Toro 3230-19

SCREW-CARR

$6.49

$

In Stock, only 3 left!

0

13

Toro 20-7900

EXHAUST DECAL

$

$

Not available

14

Toro 32103-19

WING NUT

$1.99

$

In Stock, only 2 left!

0

15

Toro 20-6570

EXHAUST BLOWR WA/DECAL

$

$

Not available

16

Toro 3290-361

ADJ SCREW 1/4-20X 3/4

$

$

Not available

17

Toro 3230-15

SCREW-CARR

$1.99

$

In Stock, only 4 left!

0

18

Toro 3256-3

WASHER-FLAT

$0.99

$

In Stock, Qty 20+

0

19

Toro 3253-4

WASHER-LOCK

$0.99

$

In Stock, Qty 20+

0

20

Toro 3210-7

SCREW-HH

$0.99

$

Usually ships in 3-6 days

0

Blower Bagging Kit (Model 59084)

Note: Not illustrated

$

$

Not available

Toro 20-6640

Loose Parts Bag

Note: Not illustrated

$

$

Currently unavailable
