618 (618112) - Cub Cadet Walk-Behind Mower (1982) Throttle Control, Height Adjuster & Adapter Plate Assemblies Parts Diagram

Walk-Behind Mower

Throttle Control, Height Adjuster & Adapter Plate Assemblies Parts Diagram

  • Title

1

Cub Cadet 718-0145

Grip

$

$

Currently unavailable

2

Cub Cadet 712-0287

Hex Nut 1/4-20 Thd.
(Superseded to 912-0287)

$4.99

$

In Stock, only 1 left!

0

3

Cub Cadet 736-0329

L-Wash. 1/4" I.D.
(Superseded to 936-0329)

$4.49

$

In Stock, Qty 11

0

4

Cub Cadet 746-0426

Throttle Control Ass'y. Comp.

$

$

Currently unavailable

5

Cub Cadet 710-0606

Hex Bolt 1/4-20 x 1.50" Lg.

$5.49

$

In Stock, Qty 10

0

6

Cub Cadet 726-0153

Cable Tie
(Superseded to 726-0230)

$27.99

$

In Stock, only 1 left!

0

7

Cub Cadet 723-0155

Fuel Gauge

$

$

Not available

8

Cub Cadet 751-0225

Fuel Tank

$

$

Not available

9

Cub Cadet 735-0149

Bushing
(Superseded to 935-0149)

$2.99

$

In Stock, Qty 20+

0

10

Cub Cadet 712-0158

Hex Cent. L-Nut 5/16-18 Thd.
(Superseded to 912-0158)

$3.49

$

In Stock, Qty 18

0

11

Cub Cadet 736-0119

L-Wash. 5/16" I.D.
(Superseded to 936-0119)

$4.99

$

In Stock, Qty 20+

0

12

Cub Cadet 710-0176

Hex Bolt 5/16-24 x 2.75" Lg.

$4.49

$

In Stock, only 2 left!

0

13

Engine

$

$

Not available

14

Cub Cadet 11207

Spacer Ass'y.

$

$

Currently unavailable

15

Cub Cadet 710-0442

Hex Bolt 5/16-18 x 1.50" Lg.
(Superseded to 710-0805A)

$4.49

$

In Stock, Qty 20+

0

16

Cub Cadet 749-0514

Strut

$

$

Currently unavailable

17

Cub Cadet 751-0173

Fuel Line - 12" Long
(Superseded to 751-10349-16)

$19.99

$

In Stock, Qty 11

0

18

Cub Cadet 726-0183

Hose Clamp 3/8" I.D.

$

$

Not available

19

Cub Cadet 751-0171

Fuel Shutoff Valve
(Superseded to 951-0171)

$20.99

$

In Stock, Qty 20+

0

20

Cub Cadet 12946

Handle Mount Bracket

$

$

Not available

21

Cub Cadet 710-0603

Hex Wash. Hd. Self-Tap Scr. 5/16-18 x .50" Lg.

$4.99

$

Usually ships in 3-6 days

0

22

Cub Cadet 12321

Height Adjuster Ass'y. - L.H.

$

$

Not available

Cub Cadet 12323

Index Plate

$

$

Not available

23

Cub Cadet 710-0253

Hex Bolt 3/8-16 x 1.00" Lg.
(Superseded to 710-0514)

$4.49

$

In Stock, Qty 20+

0

24

Cub Cadet 14425

Strut Mount Bracket

$

$

Currently unavailable

25

Cub Cadet 14336

20" Deck

Note: Color Code - 499

$

$

Currently unavailable

26

Cub Cadet 751-0297

Fuel Control Valve

$

$

Not available

27

Cub Cadet 712-0123

Hex Nut 5/16-24 Thd.
(Superseded to 912-3057)

$6.99

$

In Stock, only 3 left!

0

28

Cub Cadet 712-0798

Hex Nut 3/8-16 Thd.

$4.49

$

In Stock, Qty 12

0

29

Cub Cadet 736-0169

L-Wash. 3/8" I.D.

$3.99

$

In Stock, Qty 20+

0

30

Cub Cadet 714-0365

#6 Hi-Pro Key 5/32 x 5/8" Dia.

$5.49

$

Usually ships in 3-6 days

0

31

Cub Cadet 10769

Blade Adapter Kit

$

$

Not available

32

Cub Cadet 742-0123

20" Blade

$

$

Not available

33

Cub Cadet 736-0217

L-Wash. 3/8" I.D. Heavy Duty

$4.49

$

In Stock, Qty 8

0

34

Cub Cadet 710-0459

Hex Bolt 3/8-24 x 1.50" Lg. (Grade 5)
(Superseded to 710-0459A)

$6.99

$

In Stock, Qty 8

0

35

Cub Cadet 710-0117

Hex Bolt 5/16-24 x 1.00" Lg. (Grade 5)
(Superseded to 710-0888)

$4.49

$

In Stock, Qty 20+

0

36

Cub Cadet 07919

Scalp Plate
(Superseded to 07919B-0637)

$

$

Not available

37

Cub Cadet 712-0123

Hex Nut 5/16-24 Thd.
(Superseded to 912-3057)

$6.99

$

In Stock, only 3 left!

0

38

Cub Cadet 12266

Adapter Plate Ass'y.

$

$

Currently unavailable

39

Cub Cadet 711-0555

Pivot Pin

$

$

Not available

40

Cub Cadet 736-0329

L-Wash. 1/4" I.D.
(Superseded to 936-0329)

$4.49

$

In Stock, Qty 11

0

41

Cub Cadet 712-0117

Hex Nut 1/4-28 Thd.
(Superseded to 912-0117)

$2.49

$

In Stock, only 2 left!

0

42

Cub Cadet 710-0118

Hex Bolt 5/16-18 x .75" Lg.
(Superseded to 710-3008)

$4.49

$

In Stock, Qty 20+

0

43

Cub Cadet 12322

Height Adjuster Ass'y. - R.H.

$

$

Not available

Cub Cadet 12323

Index Plate

$

$

Not available

44

Cub Cadet 10531

Spring Lever Ass'y. w/Knob

$

$

Not available

45

Cub Cadet 736-0105

Belleville Wash. 3/8" I.D.

$4.49

$

In Stock, Qty 20+

0

46

Cub Cadet 734-1062

Wheel Ass'y. Comp.

$

$

Currently unavailable

47

Cub Cadet 710-0347

Hex Bolt 3/8-16 x 1.75" Lg.

$5.49

$

In Stock, Qty 20+

0

49

Cub Cadet 741-0332

Flanged Ball Brg.

$

$

Not available

50

Cub Cadet 712-0375

Hex Cent. L-Nut 3/8-16 Thd.

$4.49

$

In Stock, Qty 6

0

51

Cub Cadet 736-0255

Belleville Wash.

$4.99

$

In Stock, only 3 left!

0

52

Cub Cadet 738-0269

Shoulder Bolt 3/8-16 Thd.

$

$

Not available

53

Cub Cadet 712-0158

Hex Cent. L-Nut 5/16-18 Thd.
(Superseded to 912-0158)

$3.49

$

In Stock, Qty 18

0

54

Cub Cadet 736-0119

L-Wash. 5/16" I.D.
(Superseded to 936-0119)

$4.99

$

In Stock, Qty 20+

0

55

Cub Cadet 732-0253

Torsion Spring

$

$

Not available

56

Cub Cadet 710-0567

Hex Bolt 1/4-28 x .62" Lg.
(Superseded to 910-0195)

$3.99

$

In Stock, only 1 left!

0

57

Cub Cadet 748-0195

Shoulder Spacer

$

$

Not available

58

Cub Cadet 736-0219

Belleville Wash.
(Superseded to 936-0219)

$4.49

$

Usually ships in 3-6 days

0

59

Cub Cadet 710-0459

Hex Bolt 3/8-24 x 1.50" Lg. H.T.
(Superseded to 710-0459A)

$6.99

$

In Stock, Qty 8

0

60

Cub Cadet 12245

Chute Deflector Ass'y. - Comp.

Note: Color Code - 499

$

$

Currently unavailable

61

Cub Cadet 741-0332

Flanged Ball Bearing

$

$

Not available

62

Cub Cadet 10937

Pivot Bar

$

$

Not available

63

Cub Cadet 14082

Spring Lever Ass'y. w/Knob

$

$

Not available

64

Cub Cadet 710-0380

Hex Bolt 5/16-18 x 1.75" Lg.
(Superseded to 710-3180)

$5.49

$

In Stock, Qty 11

0

65

Cub Cadet 12945

Handle Mount Brkt.

$

$

Not available

66

Cub Cadet 11199

Rear Shield Ass'y.

Note: Color Code - 499

$

$

Currently unavailable

67

Cub Cadet 714-0104

Hairpin Cotter

$4.49

$

In Stock, Qty 20+

0

68

Cub Cadet 14426

Fuel Tank Mounting Brkt.

$

$

Not available

69

Cub Cadet 749-0448

Lower Handle
(Superseded to 749-0928A)

$33.99

$

In Stock, only 2 left!

0

70

Cub Cadet 736-0119

L-Wash. 5/16" I.D.
(Superseded to 936-0119)

$4.99

$

In Stock, Qty 20+

0

71

Cub Cadet 712-0158

Hex Cent. L-Nut 5/16-18 Thd.
(Superseded to 912-0158)

$3.49

$

In Stock, Qty 18

0

72

Cub Cadet 749-0383

Upper Handle

$

$

Currently unavailable

73

Cub Cadet 11156

Internal Bar

$

$

Currently unavailable

74

Cub Cadet 710-0252

Hex Bolt 1/4-20 x .75" Lg.
(Superseded to 710-3015)

$3.99

$

In Stock, Qty 20+

0

Cub Cadet 712-0107

Hex Cent. L-Nut 1/4-20 Thd.
(Superseded to 912-0107)

Note: (For Ref. 73)

$4.99

$

In Stock, only 1 left!

0

75

Cub Cadet 10619

Pivot Bar

$

$

Not available

76

Cub Cadet 13773

Engine Mount Cover Plate

$

$

Currently unavailable

77

Cub Cadet 749-0364

Upper Frame

$

$

Currently unavailable

78

Cub Cadet 750-0473

Tubing Connector

$

$

Not available

79

Cub Cadet 14525

Lower Frame Ass'y.

$

$

Currently unavailable

80

Cub Cadet 11629

Lower Frame Bracket

$

$

Currently unavailable

81

Cub Cadet 710-0192

Truss Hd. Mach. Scr. #10-24 x .38" Lg.

$3.99

$

In Stock, Qty 12

0

82

Cub Cadet 712-0425

Sq. Nut #10 I.D.
(Superseded to 912-0121)

$4.49

$

In Stock, Qty 20+

0

83

Cub Cadet 736-0147

Ext. L-Wash. #10 I.D.
(Superseded to 936-0147)

$3.49

$

Usually ships in 3-6 days

0

84

Cub Cadet 710-0467

Truss Hd. Mach. Scr. #10-24 x 1.00" Lg.

$

$

Not available

85

Cub Cadet 764-0176

Grass Bag
(Superseded to 764-0176B)

$

$

Not available

Grass Catcher Comp.

Note: Model 005

$

$

Not available
