5900762 - Simplicity Citation 52" Zero-Turn Mower, 25hp Kawasaki Motion Control Group - 5900820 Only Parts Diagram

Citation 52" Zero-Turn Mower, 25hp Kawasaki

Motion Control Group - 5900820 Only Parts Diagram

  • Title

1

Simplicity 5100947

ROD, NEUTRAL RETURN, CZ
(Superseded to 5100947SM)

$7.99

$

Usually ships in 2-12 days

0

2

Simplicity 5022645

SPRING, REVERSE RETURN
(Superseded to 5022645SM)

$9.49

$

In Stock, only 1 left!

0

3

Simplicity 5023260

BUSHING, FLANGE 3/8ID X 7/8 LONG
(Superseded to 5023260SM)

$6.49

$

In Stock, only 2 left!

0

4

Simplicity 5104375YP

FLANGED BUSHING, 3/8IDX.63ODX.8125FL

$5.99

$

Usually ships in 2-12 days

0

5

Simplicity 5010546

COLLAR, 3/8" Set
(Superseded to 5010546SM)

$5.99

$

Usually ships in 2-12 days

0

6

Simplicity 5025156

WASHER, 3/8 SAE
(Superseded to 5025156FS)

$3.49

$

Usually ships in 2-12 days

0

7

Simplicity 5025210

3/32 X 1-5/8 HAIR PIN CLIP
(Superseded to 5025210YP)

$3.99

$

In Stock, Qty 20+

0

8

Simplicity 5100941

BALL STUD, 5/16 X .50,# PC-477-2)
(Superseded to 5100941SM)

$4.49

$

In Stock, Qty 12

0

9

Simplicity 5100940

DAMPENER, CONTROL,#(P6709/P3610)
(Superseded to 5100940SM)

$55.99

$

In Stock, only 2 left!

0

10

Simplicity 5025392

NUT, 5/16-18 HEX NYLOCK FLANGE NUT
(Superseded to 5025392FS)

$3.49

$

Usually ships in 2-12 days

0

11

Simplicity 5100946

ROD, HYDRO LINKAGE
(Superseded to 5100946SM)

$4.99

$

Usually ships in 2-12 days

0

12

Simplicity 5023212

NUT, 5/16-24 HEX, LH
(Superseded to 5023212SM)

$3.49

$

Usually ships in 2-12 days

0

13

Simplicity 5104579YP

BALL JOINT 5/16-24 LH FEMALE STAMPED STL

$

$

Not available

14

Simplicity 5402589AYP

SHAFT MTN CNTRL RH

$112.99

$

Usually ships in 2-12 days

0

15

Simplicity 5025011X8

BOLT, 5/16-18 X 1" GRD5 YZ
(Superseded to 5025011X8FS)

$3.49

$

In Stock, Qty 17

0

16

Simplicity 5025155

WASHER, 5/16" SAE

$

$

Currently unavailable

17

Simplicity 5025011X10

BOLT, 5/16-18 X 1-1/4" GD5 YZ
(Superseded to 5025055X10YP)

$3.49

$

Usually ships in 2-12 days

0

18

Simplicity 5104578YP

BALL JOINT 5/16-24 RH FEMALE STAMPED STL

$11.99

$

Usually ships in 2-12 days

0

19

Simplicity 5025033

NUT, Hex, 5/16-24
(Superseded to 5025033FS)

$3.49

$

Usually ships in 2-12 days

0

20

Simplicity 5021098

BEARING, BRONZE FLANGE, 3/4"
(Superseded to 5021098SM)

$13.99

$

In Stock, Qty 5

0

21

Simplicity 5025013X8

BOLT, 3/8-16 X 1" GD5 YZ
(Superseded to 5025013X8SM)

$3.99

$

In Stock, Qty 6

0

22

Simplicity 5025394

NUT, 3/8 - 16 HEX NYLOCK FLANGE
(Superseded to 5025394SM)

$4.49

$

In Stock, Qty 20+

0

23

Simplicity 5021499

BEARING, FLANGE
(Superseded to 5021499SM)

$55.99

$

In Stock, only 2 left!

0

24

Simplicity 5025013X10

BOLT, 3/8-16 X 1-1/4" GD5 YZ
(Superseded to 5025013X10SM)

$3.99

$

In Stock, Qty 12

0

25

Simplicity 5025096

NUT, Hex, Nylon Locking, 3/8-16
(Superseded to 5025096SM)

$3.49

$

In Stock, Qty 20+

0

26

Simplicity 5025013X14

BOLT, 3/8-16 X 1-3/4" GD5 YZ
(Superseded to 5025013X14SM)

$3.99

$

In Stock, only 2 left!

0

27

Simplicity 5047004A

MOUNT, CONTROL ARM - BLK
(Superseded to 5047004SM)

$62.99

$

Usually ships in 2-12 days

0

28

Simplicity 5402595A

WELD, NEUTRAL LOCK - RH - IS500Z - BLK
(Superseded to 5402595AYP)

$63.99

$

Usually ships in 2-12 days

0

29

Simplicity 5402594A

WELD, NEUTRAL LOCK - LH - IS500Z - BLK
(Superseded to 5402594AYP)

$63.99

$

Usually ships in 2-12 days

0

30

Simplicity 1717050SM

SWITCH, Push Button, N.O . N.C, Double Pole, Grey

$17.99

$

In Stock, Qty 20+

0

31

Simplicity 5025179X4

SCREW, #10-24 X 1/2" ROUND PHILLIPS
(Superseded to 5025179X4SM)

$3.99

$

Usually ships in 2-12 days

0

32

Simplicity 5025029

NUT, HEX, #10-24
(Superseded to 5025029SM)

$2.99

$

Usually ships in 2-12 days

0

33

Simplicity 5025011X9

BOLT, 5/16-18 X 1-1/8 GD5 CZ
(Superseded to 5025011X9SM)

$3.99

$

In Stock, only 1 left!

0

34

Simplicity 5025127

NUT, 5/16-18 HEX SERRATED FLANGE (SMALL)
(Superseded to 5025127SM)

$3.49

$

In Stock, only 4 left!

0

35

Simplicity 5025013X20

BOLT, 3/8-16 X 2-1/2" GD5 YZ
(Superseded to 84007037)

$2.99

$

In Stock, only 3 left!

0

36

Simplicity 5048264

SPACER, .39 X .63 X 1.50, CZ
(Superseded to 5048264SM)

$5.99

$

Usually ships in 2-12 days

0

37

Simplicity 5025013X24

BOLT, 3/8-16 X 3" GD5 YZ
(Superseded to 5025013X24SM)

$3.99

$

In Stock, only 1 left!

0

38

Simplicity 5047055A

WELD, HANDLE MOTION CONTROL, LH - BLK
(Superseded to 5047055AYP)

$61.99

$

In Stock, only 1 left!

0

39

Simplicity 5047056A

WELD, HANDLE MOTION CONTROL, RH - BLK
(Superseded to 5047056AYP)

$61.99

$

Usually ships in 2-12 days

0

40

Simplicity 5025170

WASHER, 5/16 LOCK YZ
(Superseded to 5025170SM)

$3.99

$

Usually ships in 2-12 days

0

41

Simplicity 5022068

GRIP, FOAM, 3/4" ID, 16"" LONG
(Superseded to 5022068SM)

$11.99

$

Usually ships in 2-12 days

0

42

Simplicity 5100948

GUARD, RUBBER MOT CTRS - IS500Z
(Superseded to 5100948SM)

$8.49

$

Usually ships in 2-12 days

0

43

Simplicity 5025431

PUSH RIVET (TREE TYPE), BLACK
(Superseded to 5025431SM)

$4.49

$

Usually ships in 2-12 days

0

44

Simplicity 5020639

SPRING-EXT, .500 OD X 3.50 LG X .058 WR
(Superseded to 5020639SM)

$31.99

$

Usually ships in 2-12 days

0

45

Simplicity 5402588AYP

SHAFT MTN CNTRL LH

$

$

Not available
