580.328160 (8759-0) - Craftsman 750 Watt Portable Generator Carburetor For 1.6 Horsepower Kawasaki Engine FA76D-3MP Parts Diagram

750 Watt Portable Generator

Carburetor For 1.6 Horsepower Kawasaki Engine FA76D-3MP Parts Diagram

  • Title

Briggs & Stratton 17161892

CARBURETOR ASSEMBLY

Note: (Includes Items 1 thru 15) Contact Generac for quantity required

$

$

Currently unavailable

1

Briggs & Stratton 21661892

SHAFT, Throttle

Note: Contact Generac for quantity required

$

$

Currently unavailable

2

Briggs & Stratton 21761892

SCREW, Adjustment

Note: Contact Generac for quantity required

$

$

Currently unavailable

3

Briggs & Stratton 21861892

SPRING

Note: Contact Generac for quantity required

$

$

Currently unavailable

4

Briggs & Stratton 21961892

SCREW, Idle Speed Stop

Note: Contact Generac for quantity required

$

$

Currently unavailable

5

Briggs & Stratton 22061892

SPRING

Note: Contact Generac for quantity required

$

$

Currently unavailable

6

Briggs & Stratton 22161892

SHAFT, Choke

Note: Contact Generac for quantity required

$

$

Currently unavailable

7

Briggs & Stratton 22261892

O-RING

Note: Contact Generac for quantity required

$

$

Currently unavailable

8

Briggs & Stratton 22361892

SPRING

Note: Contact Generac for quantity required

$

$

Currently unavailable

9

Briggs & Stratton 22461892

CAP, Spring

Note: Contact Generac for quantity required

$

$

Currently unavailable

10

Briggs & Stratton 22561892

DIAPHRAGM

Note: Contact Generac for quantity required

$

$

Not available

11

Briggs & Stratton 22661892

GASKET

Note: Contact Generac for quantity required

$

$

Currently unavailable

12

Briggs & Stratton 22761892

SCREW

Note: Contact Generac for quantity required

$

$

Currently unavailable

13

Briggs & Stratton 22861892

WASHER

Note: Contact Generac for quantity required

$

$

Currently unavailable

14

Briggs & Stratton 22961892

JET, Main - No. 54

Note: Contact Generac for quantity required

$

$

Currently unavailable

15

Briggs & Stratton 23061892

STRAINER

Note: Contact Generac for quantity required

$

$

Currently unavailable
