56A35D4K750 - Cub Cadet Tank Ride-On Sprayer Spreader Sprayer Tank Assembly Parts Diagram

Tank Ride-On Sprayer Spreader

Sprayer Tank Assembly Parts Diagram

  • Title

1

Cub Cadet 00006145

Hose Barb, 1/2 NPT, 1/2 Nylon

$5.49

$

Usually ships in 3-6 days

0

2

Cub Cadet 01005223

Coupling, 1/2" (F) NPT

$

$

Not available

3

Cub Cadet 01010073

Gasket

$19.99

$

In Stock, only 1 left!

0

4

Cub Cadet 00006430

Adapter, 1/4 NPT, 1/2 NPT

$11.99

$

Usually ships in 3-6 days

0

5

Cub Cadet 00008295

Hose, 1/2" sold by the ft.

$

$

Not available

6

Cub Cadet 00008382

Foam, Adhesive Backed, 4'' x 1/4'' by ft.

$

$

Not available

7

Cub Cadet 00022284-1

Hose, 3/8 by the ft.

$5.99

$

In Stock, only 2 left!

0

8

Cub Cadet 00031601P

Hose, 3/4 by the ft.

$

$

Not available

9

Cub Cadet 00032715

Nipple, 1/4 NPT x 2"

$

$

Not available

10

Cub Cadet 01000216

Hose Clamp, 1/2, 7/8

$

$

Not available

11

Cub Cadet 936-0160

Flat Washer, .536 ID x .93 OD x .050

$4.49

$

In Stock, only 1 left!

0

12

Cub Cadet 01010072

Lid

$42.99

$

Usually ships in 3-6 days

0

13

Cub Cadet 01008804

Nut, 1/2-20

$

$

Not available

14

Cub Cadet 01008818

Tank, 40 Gallon

$475.99

$

Usually ships in 3-6 days

0

15

Cub Cadet 01008822

Hose barb, 1/2 NPT, 3/4 Elbow

$

$

Not available

16

Cub Cadet 01008988-0637

Tank Skid Plate

$180.99

$

Usually ships in 3-6 days

0

17

Cub Cadet 01009282

Fitting, 1/2 Double Threaded

$

$

Not available

18

Cub Cadet 01009287

Hex Head Cap Screw, 1/2-20 x 9.00

$

$

Not available

19

Cub Cadet 01009288

Hex Head Cap Screw, 1/2-20 x 9.50

$

$

Not available

20

Cub Cadet 01009338

Pipe Plug, 1/2 NPT

$

$

Not available

21

Cub Cadet 01009339

Jet Agitator

$

$

Not available

22

Cub Cadet 01010074

Nipple, 1/2"-14 x 2.00

$

$

Not available

23

Cub Cadet 01010071

Fitting, Tank

$

$

Not available
