53AB5B8J195 - White Outdoor Zero-Turn Mower Hydro Pump Assembly With Oil Cooler (April 2000) Parts Diagram

Zero-Turn Mower

Hydro Pump Assembly With Oil Cooler (April 2000) Parts Diagram

  • Title

1

MTD 00017665P

Filter Head 3/4 w/Filter

$

$

Not available

1

MTD 01004166

Filter, .33 Micron

$50.99

$

In Stock, only 4 left!

0

2

MTD 00022560

Hex Nut, 3/8-16, Flange Lock
(Superseded to 712-05007)

$4.49

$

In Stock, Qty 20+

0

3

MTD 00030261

Cap, Hydro Oil Tank

$36.99

$

Usually ships in 3-6 days

0

4

MTD 00083192

Idler Washer
(Superseded to 736-0258)

$4.49

$

Usually ships in 3-6 days

0

5

MTD 710-0751

HHCS, 1/4-20, .620

$3.99

$

In Stock, Qty 20+

0

6

MTD 710-3178

Carriage Bolt, 3/8-16 x .75 LG.

$4.49

$

In Stock, Qty 20+

0

7

MTD 936-0463

Flat Washer 1/4 x .630 x .0515
(Superseded to 736-0463)

$4.49

$

In Stock, Qty 12

0

8

MTD 927-3081

Straight Connector, 1/2 x 3/4

$

$

Not available

9

MTD 00006144

HHCS, 3/8-16, 1.00

$6.99

$

Usually ships in 3-6 days

0

10

MTD 01004160

Hose, Hydraulic, Cooler to Filter

$

$

Not available

11

MTD 01001740

Hose, Hydraulic, Filter to LHPU

$

$

Not available

12

MTD 01001741

Hose, Hydraulic, Filter to RHPU

Note: NLA

$

$

Not available

13

MTD 01001742

Hose, Hydraulic, Pump to Tank

$

$

Not available

14

MTD 01001743

Tee Fitting, 1/2 x 1/2 x 3/4

Note: NLA

$

$

Not available

15

MTD 01001974

Adapter, 1/2 x 3/4

$

$

Not available

16

MTD 01001650

Mounting Plate, Oil Filter

$

$

Not available

17

MTD 912-3027

Nut, 1/4-20, Hex Flange Lock

$4.49

$

In Stock, Qty 17

0

18

MTD 00031994

Decal, Oil Only 20W50

$

$

Not available

19

MTD 01001659

Tank Assembly, Hydraulic

$

$

Not available

20

MTD 01002968

Heat Exchanger, 1.5 x 11 x 2.77

Note: NLA

$

$

Currently unavailable

21

MTD 01002971

Elbow Fitting, 1/2 NTPF x 1/2

$

$

Not available

22

MTD 01001661

Mounting Bracket, RH Heat Exchanger

Note: NLA

$

$

Not available

23

MTD 01001663

Mounting Bracket, LH Heat Exchanger

Note: NLA

$

$

Not available

24

MTD 01002974

Fitting Connector, 1/2 NPTF x 1/2 Swivel

$

$

Not available

25

MTD 738-0940

Plug, Oil Pan Drain

$8.49

$

Usually ships in 3-6 days

0

26

MTD 01003820

Spacer, 2.0 Hex x .41 Long

Note: NLA

$

$

Not available

27

MTD 725-0157

Cable, Tie, 3/16 x .05 x 7.4

$3.99

$

In Stock, Qty 20+

0

MTD 737-3120

Drive System Fluid Plus, Quart
(Superseded to 490-000-C051)

$21.99

$

In Stock, Qty 20+

0

MTD 737-3121

Drive System Fluid Plus, Gallon

$77.99

$

In Stock, only 2 left!

0
