52066 - Troy-Bilt Walk-Behind Trimmer Lower Steering Assembly Parts Diagram

Walk-Behind Trimmer

Lower Steering Assembly Parts Diagram

  • Title
1

MTD 1917778

Wheel - 6 spoke

$

$

Not available

2

MTD 1915823

Wheel Stud

$

$

Not available

3

Troy-Bilt 1915824

Wheel Mounting Bracket

$

$

Currently unavailable

5

Troy-Bilt 1733398

Top Lock Nut, 3/8-16
(Superseded to 912-3000)

$4.49

$

In Stock, Qty 9

0

13

Troy-Bilt 1744708

Hex Lock Nut, 5/16-18

$

$

Not available

14

MTD 1111606

Hex Head Bolt, 5/16-18 x 2

$

$

Not available

15

Troy-Bilt 1186331

Hex Flange Screw, 5/16-18 x 1
(Superseded to 710-04048)

$4.99

$

In Stock, Qty 7

0

17

MTD 9901

Washer, 5/16 ID

$

$

Not available
