51987 - Toro Powervac Blower Vacuum (SN: 313000001 - 999999999) ENGINE ASSEMBLY Parts Diagram

Powervac Blower Vacuum

ENGINE ASSEMBLY Parts Diagram

  • Title

1

Homelite 660347001

Screw (M5 x 50 mm)

$1.99

$

In Stock, only 1 left!

0

2

Homelite 638027001

Muffler Heat Shield

$4.49

$

Usually ships in 3-7 days

0

3

Homelite 300748034

Muffler Assembly

$

$

Not available

4

Homelite 900955002

Heat Shield Tape

$

$

Not available

5

Homelite 638183001

Muffler Gasket

$8.99

$

In Stock, only 3 left!

0

6

Homelite 870174001

Spark Plug (Champion RC6Y)

$4.49

$

In Stock, Qty 20+

0

7

Homelite 290178008

Ignition Coil Assembly

$

$

Not available

8

Homelite 290702001

Ignition Lead Assembly

$1.49

$

Usually ships in 3-7 days

0

9

Homelite 640574002

Rotor

$18.99

$

Usually ships in 3-7 days

0

10

Homelite 660349001

Screw (M4 x 22 mm)

$1.99

$

In Stock, Qty 5

0

11

Homelite 900711008

Heat Dam Gasket
(Superseded to 903279002)

$

$

Not available

12

Homelite 518329001

Heat Dam

$7.99

$

Usually ships in 3-7 days

0

13

Homelite 660344003

Screw w/Washer (M5 x 31 mm)

$1.49

$

Usually ships in 3-7 days

0

14

Homelite 900711003

Carburetor Gasket
(Superseded to 9071103)

$

$

Not available

15

Homelite 308480001

Carburetor Assembly

$

$

Not available

16

Homelite 308004001

Pulley Assembly

$17.99

$

Usually ships in 3-7 days

0

17

Homelite 308430001

Recoil Starter Assembly
(Superseded to 308430016)

$

$

Not available

18

Homelite 660351001

Screw w/Washer (M5 x 16 mm)
(Superseded to 6635101)

$1.99

$

In Stock, only 3 left!

0

19

Homelite 590458001

Choke Lever
(Superseded to 5945801)

$

$

Not available

20

Homelite 690700001

Hose Clip
(Superseded to 6970001)

$1.99

$

In Stock, Qty 6

0

21

Homelite 570373003

Hose (51mm)

$

$

Not available

22

Homelite 690699001

Hose Clip
(Superseded to 6969901)

$1.99

$

Usually ships in 3-7 days

0

23

Homelite 660734001

Screw (M4 x 16 mm)

$1.99

$

In Stock, only 3 left!

0

24

Homelite 638133003

Retaining Clip

$1.49

$

Usually ships in 3-7 days

0

25

Homelite 518130001

Air Box Case

$3.99

$

In Stock, only 1 left!

0

26

Homelite 300780002

Primer Bulb Assembly
(Superseded to 01183)

$

$

Not available

27

Homelite 590946001

Choke Plate
(Superseded to 5994601)

$1.99

$

In Stock, only 1 left!

0

28

Homelite 660345001

Screw (M4 x 12 mm)
(Superseded to 983645005)

$1.99

$

In Stock, only 4 left!

0

29

Homelite 631049003

Washer

$1.49

$

Usually ships in 3-7 days

0

30

Homelite 660346001

Bolt (M5 x 60 mm)

$2.49

$

Usually ships in 3-7 days

0

31

Homelite 560873001

Air Filter
(Superseded to 5687301)

$

$

Not available

32

Homelite 518253001

Air Box Cover

$

$

Not available

33

Homelite 590461001

Knob
(Superseded to 5946101)

$1.99

$

In Stock, only 2 left!

0

34

Homelite 690688001

Woodruff Key
(Superseded to 983784006)

$

$

Not available

35

Homelite 900709005

Gasket

$1.49

$

In Stock, only 4 left!

0

36

Homelite 640570023

Cylinder

$35.99

$

In Stock, only 1 left!

0

37

Homelite 630002021

Cylinder Plate

$1.49

$

In Stock, only 3 left!

0

38

Homelite 660342001

Bolt (M5 x 22 mm)

$1.99

$

Usually ships in 3-7 days

0

39

Homelite 660351002

Bolt (M5 x 20.3 mm, Pan Hd.)
(Superseded to 983660005)

$1.49

$

Usually ships in 3-7 days

0

40

Homelite 590462001

Spacer

$2.99

$

In Stock, only 1 left!

0

41

Homelite 690969001

Washer (ID4.2 x OD10 x 1t)

$1.99

$

In Stock, Qty 5

0

42

Homelite 300749009

Crankcase Assembly

$76.99

$

Usually ships in 3-7 days

0

Homelite 120900107

High Altitude Kit

Note: NOT SHOWN

$15.99

$

Usually ships in 3-7 days

0
