51975 - Toro String Trimmer (SN: 311000001 - 999999999) Figure A Parts Diagram

String Trimmer

Figure A Parts Diagram

  • Title

1

Homelite 308035013

Straight Shaft Assembly

$

$

Not available

2

Homelite 940230132

Warning Label
(Superseded to 984032001)

$2.49

$

Usually ships in 3-7 days

0

3

Homelite 638125003

Grass Deflector Clamp

$2.99

$

Usually ships in 3-7 days

0

4

Homelite 660736001

Screw (#10-24 x 5/8 in. Hex Washer Hd.)
(Superseded to 983774003)

$2.49

$

In Stock, Qty 5

0

5

Homelite 660642001

Screw (1/4-20 x 1-1/4 in.)
(Superseded to 983381007)

$2.49

$

In Stock, Qty 5

0

6

Homelite 518367001

Spacer

$1.99

$

In Stock, only 3 left!

0

7

Homelite 308210001

Gear Case Assembly
(Superseded to 308210008)

$

$

Not available

8

Homelite 678011001

Flanged Washer
(Superseded to 099078001005)

$10.99

$

Usually ships in 3-7 days

0

9

Homelite 678019003

Trimmer Head Shaft Adaptor
(Superseded to 678019001)

$4.49

$

In Stock, only 1 left!

0

10

Homelite 308827003

Stringhead Housing
(Superseded to 308827002)

$15.99

$

Usually ships in 3-7 days

0

11

Homelite 678749001

Compression Spring

$1.99

$

In Stock, Qty 20+

0

12

Homelite 308924002

Spool w/ Line (.095)
(Superseded to 308924001)

$

$

Not available

13

Homelite 660649001

Bolt (5/16-18 x 1/2 in., L.H.)

$1.99

$

In Stock, only 1 left!

0

14

Homelite 518803003

Bump Knob

$

$

Not available

15

Homelite 308923014

Trimmer Head Assembly

Note: (Inc. Key Nos. 10-14) (.095)

$91.99

$

In Stock, only 2 left!

0

16

Homelite 660738002

Screw (#1/4-20 x 1-1/4 in. Hex Washer Hd.)
(Superseded to 983379078)

$

$

Not available

17

Homelite 940627020

Grass Deflector Label

$1.49

$

Usually ships in 3-7 days

0

18

Homelite 308473001

Grass Deflector Assembly

Note: (Inc. Key No. 16)

$

$

Not available

19

Homelite 518019002

Hanger Cap
(Superseded to 518019004)

$1.99

$

In Stock, Qty 6

0
