491 (590-491-100) - Cub Cadet Suspension Seat Bracket att Suspension Seat Assembly Parts Diagram

Suspension Seat Bracket

Suspension Seat Assembly Parts Diagram

  • Title

1

Cub Cadet 603-0695-0637

Link, Front Suspension

$

$

Currently unavailable

2

Cub Cadet 603-0696-0637

Link, Rear Suspension

$

$

Currently unavailable

3

Cub Cadet 703-3435-0637

Bracket, Seat Pivot, LH

$

$

Currently unavailable

4

Cub Cadet 703-3436-0637

Bracket, Seat Pivot, RH

$

$

Currently unavailable

5

Cub Cadet 703-3437-0637

Base, Lower Suspension

$

$

Currently unavailable

6

Cub Cadet 703-3438-0637

Support, Upper Seat

$

$

Currently unavailable

7

Cub Cadet 703-3562-0637

Bracket, Seat Belt Mounting

$

$

Currently unavailable

8

Cub Cadet 710-0216

Screw, Hex Cap 3/8-16 x .75 GR5

$4.49

$

In Stock, Qty 12

0

9

Cub Cadet 710-0513

Screw, Hex Cap Lock 1/4-28 x .625 GR5
(Superseded to 710-0513A)

$4.99

$

In Stock, Qty 7

0

10

Cub Cadet 710-1803

Screw, Hex Washer Hd. Mach. 3/8-24 x 5.5 GR5

$

$

Not available

11

Cub Cadet 712-3004A

Nut, Hex Flange Lock, 5/16-18 GR5

$3.99

$

In Stock, Qty 20+

0

12

Cub Cadet 712-3005

Nut,Hx.Flnge. Lock, 3/8-16 GR5

$6.99

$

Usually ships in 3-6 days

0

13

Cub Cadet 726-0154

Tie, Push Mount Cable
(Superseded to 926-0154)

$6.49

$

Usually ships in 3-6 days

0

14

Cub Cadet 732-0972

Spring, Extension

$

$

Not available

15

Cub Cadet 735-0271

Bumper, Rubber
(Superseded to 735-0271A)

$8.99

$

In Stock, only 1 left!

0

16

Cub Cadet 736-0173

Washer, Flat, .28 x .74 x .063

$4.49

$

In Stock, Qty 20+

0

17

Cub Cadet 736-0262

Washer, Flat, .385 x .870 x .092

$3.99

$

In Stock, Qty 20+

0

18

Cub Cadet 738-0296

Screw, Shoulder, .437 x .286

$4.49

$

In Stock, Qty 20+

0

19

Cub Cadet 741-04005

Bearing, Nyliner Flange, .5 ID

$

$

Not available

20

Cub Cadet 747-3410

Rod, Lower Pivot

$

$

Not available

21

Cub Cadet 747-3411

Rod, Upper Pivot

$

$

Not available

22

Cub Cadet 747-3412

Rod, Spring Adjustment

$

$

Not available
