482 (590-482-100) - Cub Cadet Sub-Frame att Hoses & Fittings (7360 Models Only) Parts Diagram

Sub-Frame

Hoses & Fittings (7360 Models Only) Parts Diagram

  • Title

1

Cub Cadet WM-52382

Backhoe sub-frame

$

$

Not available

2

Cub Cadet WM-52416

Lock Pin

$

$

Not available

3

Cub Cadet WM-52380

Left Rear Mount

$

$

Not available

4

Cub Cadet WM-52381

Right Rear Mount

$

$

Not available

5

Cub Cadet WM-64954

Outer link assembly, 19.5

$

$

Not available

6

Cub Cadet WM-64956

Inner top link assembly

$

$

Not available

15

Cub Cadet WM-2688

Hairpin cotter

$

$

Currently unavailable

16

Cub Cadet WM-62043

1/4 x 1-3/4 Klik pin

$

$

Not available

17

Cub Cadet WM-855

1/2 Lockwasher
(Superseded to 936-0921)

$4.49

$

In Stock, only 2 left!

0

18

Cub Cadet WM-52418

12mm x 1.75P x 110mm Hex head cap screw, CL 8.8

$

$

Not available

19

Cub Cadet WM-62580

9/16 Standard lockwasher

$

$

Not available

20

Cub Cadet WM-307360

14mm x 2.0P x 45mm Hex head cap screw, CL 8.8

$

$

Not available

21

Cub Cadet WM-62540

3/4 x 2.76 Clevis pin

$

$

Not available

22

Cub Cadet WM-735

3/4 NC x 2 Hex head cap screw GR5

$

$

Currently unavailable

23

Cub Cadet WM-2522

3/4 Lockwasher
(Superseded to 936-0364)

$

$

Not available

24

Cub Cadet WM-1450

3/4 Nut
(Superseded to 712-3107)

$11.99

$

Usually ships in 3-6 days

0

25

Cub Cadet WM-3132

1" NC Hex nut

$

$

Not available
