481-2368 (136G765N054) - Coast to Coast Lawn Tractor (1996) Shift Lever Assembly Parts Diagram

Lawn Tractor

Shift Lever Assembly Parts Diagram

  • Title
1

MTD 647-0017

Shift Lever Ass'y.

$

$

Not available

2

MTD 656-0011

"V"-Pulley

$

$

Not available

3

MTD 683-0076

Speed Brkt. Ass'y.

$

$

Not available

4

MTD 683-0077

Idler Brkt. Ass'y.

$

$

Not available

5

MTD 683-0090

Torque Brkt. Ass'y.

$

$

Not available

6

MTD 683-0100

Variable Speed Brkt. Ass'y.

$

$

Not available

7

MTD 710-0331

Hex Bolt 3/8-24 x 2.25" (Gr. 5)

$6.99

$

In Stock, Qty 7

0

8

MTD 710-0395

Hex Bolt 5/6-18 x 2.25" Leg.

$4.99

$

In Stock, only 1 left!

0

9

MTD 710-0599

Hex Tap Scr. 1/4-20 x .5" Lg.

$4.49

$

In Stock, Qty 20+

0

10

MTD 710-1035

Hex TT-Tap Scr. 3/8-16 x 2.5"

$10.99

$

Usually ships in 3-6 days

0

11

MTD 710-1135

Hex Tap Scr. 5/16-18 x 2.5" Lg.

$

$

Not available

?12

MTD 710-1194

Hex Bolt #10-24 x .88" Lg.

$3.99

$

Usually ships in 3-6 days

0

13

MTD 710-0607

Hex SF-Tap Scr. 5/16 x .5" Lg

$6.99

$

In Stock, Qty 11

0

14

MTD 712-0158

Hex Ctr. L-Nut 5/16-18 Thd.
(Superseded to 912-0158)

$3.49

$

In Stock, Qty 18

0

?15

MTD 712-0241

Hex Nut 3/8-24 Thd. (Gr. 8)

$4.49

$

In Stock, Qty 13

0

16

MTD 712-0446

Hex Jam L-Nut 3/8-24 Thd.
(Superseded to 912-0446)

$6.99

$

In Stock, only 1 left!

0

17

MTD 712-3035

Hex Jam Nut 9/16-18 Thd. (Gr. 5)

$6.99

$

Usually ships in 3-6 days

0

18

MTD 712-0998

Hex Sems L-Nut #10-24 Thd.

$3.99

$

Usually ships in 3-6 days

0

19

MTD 712-3017

Hex Nut 3/8-16 Thd. (Gr. 8)

$4.49

$

In Stock, Qty 20+

0

20

MTD 714-0111

Cotter Pin 3/32" Dia. x 1" Lg.

$4.99

$

In Stock, Qty 13

0

21

MTD 714-0147

Hairpin Clip

$4.99

$

In Stock, Qty 6

0

22

MTD 714-0149B

Hairpin Clip

$4.49

$

In Stock, Qty 18

0

23

UNKNOWN

$

$

Not available

24

MTD 732-0413

Ext. Spring 7.08" Lg.
(Superseded to 932-0413)

$12.99

$

In Stock, only 4 left!

0

25

MTD 732-0470A

Ext. Spring 4.74" Lg.
(Superseded to 932-0470A)

$9.99

$

In Stock, only 4 left!

0

26

MTD 732-0499

Comp. Spring 1.5" Lg.

$9.49

$

In Stock, only 1 left!

0

27

MTD 732-0556

Ext. Spring 7.57" Lg.
(Superseded to 932-0556)

$21.99

$

Usually ships in 3-6 days

0

28

MTD 732-0568

Ext. Spring 2.54" Lg.
(Superseded to 932-0568)

$

$

Not available

29

MTD 732-0735

Comp. SPring 2.3" Lg.
(Superseded to 732-0735A)

$29.99

$

In Stock, Qty 5

0

30

MTD 736-0169

L-Wash. 3/8" I.D.

$3.99

$

In Stock, Qty 20+

0

31

MTD 736-0275

FL-Wash. 5/16" I.D.

$6.99

$

Usually ships in 3-6 days

0

32

MTD 736-0331

Bell-Wash. .39" I.D. x 1.13" O.D.

$3.99

$

In Stock, Qty 20+

0

33

MTD 736-0355

FL-Wash. .56" I.D. x 1" O.D.

$4.49

$

In Stock, Qty 20+

0

34

MTD 736-0414

FL-Wash. .565" I.D. x 1.12" O.D.

$4.49

$

In Stock, Qty 13

0

35

MTD 736-0427

Bell-Wash. .567" I.D. x 1-1/8"
(Superseded to 936-0427)

$

$

Not available

36

MTD 736-3010

FL-Wash. .411" I.D. x .812" O.D.

$4.99

$

In Stock, Qty 20+

0

37

MTD 738-0509

Shld. Bolt .5" Dia. x .433"

$

$

Not available

38

MTD 738-0900

Shaft 6.92" Lg.

$

$

Not available

39

MTD 738-0901

Shaft 8.62" Lg.

$

$

Not available

40

MTD 741-0405

Thrust Brg. .56" I.D.
(Superseded to 941-0405)

$

$

Not available

41

MTD 741-0419

Nyliner Flange Brg.

$

$

Not available

42

MTD 741-0495

Flange Brg. .63" I.D.

$4.99

$

In Stock, Qty 20+

0

43

MTD 747-0609

Brake Rod

$

$

Not available

44

MTD 747-0611

Speed Control Link

$

$

Not available

45

MTD 747-0915

Shift Lever

$

$

Not available

?46

MTD 750-0983

Step Spacer

$

$

Not available

47

MTD 754-0370

"V"-Belt
(Superseded to 954-0370)

$41.99

$

Usually ships in 3-6 days

0

48

MTD 754-0444

"V"-Belt
(Superseded to 954-0444)

$63.99

$

Usually ships in 3-6 days

0

49

MTD 756-0610

Variable Speed Pulley

$

$

Not available

50

MTD 756-0643

Flat Idler Pulley
(Superseded to 756-0643A)

$40.99

$

In Stock, Qty 15

0

51

MTD 783-0189

Retainer Spring

$

$

Not available

52

MTD 783-0205

Support Brkt.-Upper

$

$

Not available

53

MTD 783-0207

Retainer-Shift Lever

$

$

Not available

54

MTD 783-0215

Support Brkt.-Lower

$

$

Not available
