45149 - Gravely 36" Snow Blower for 1100 & 1200 Series Tractor CONTROLS Parts Diagram

36" Snow Blower for 1100 & 1200 Series Tractor

CONTROLS Parts Diagram

  • Title
1

Gravely 049105

Crank, Chute Control
(Superseded to 03081900)

$154.99

$

Usually ships in 4-12 days

0

2

Gravely 049106

Knob
(Superseded to 07509600)

$

$

Not available

4

Gravely 180122

Bolt, Hex 3/8-16x1.00
(Superseded to 05901711)

$1.49

$

In Stock, Qty 20+

0

5

Gravely 036901

Bracket, Control
(Superseded to 03531300)

$

$

Not available

6

Gravely 413534

Nut, Lock 3/8-16
(Superseded to 06500825)

$1.49

$

In Stock, Qty 20+

0

7

Gravely 036900

Support, Chute Crank
(Superseded to 03531200)

$20.99

$

Usually ships in 4-12 days

0

8

Gravely 413447

Nut, Lock 5/16-18
(Superseded to 06500826)

$1.49

$

In Stock, Qty 20+

0

9

Gravely 036075

Hairpin, Internal
(Superseded to 06701000)

$2.49

$

Usually ships in 4-12 days

0

10

Gravely 120375

Nut, Hex 1/4-20
(Superseded to 06500916)

$0.99

$

In Stock, Qty 13

0

11

Gravely 120214

Washer, Lock 5/16 Reg.
(Superseded to 06300119)

$0.99

$

In Stock, Qty 20+

0

12

Gravely 422845

Washer, Flat .281x.625x.065
(Superseded to 06401001)

$0.99

$

In Stock, Qty 20+

0

13

Gravely 126203

Bolt, 1/4-20x.625 Rd Hd Sq Nk
(Superseded to 06213800)

$

$

Not available

14

Gravely 036884

Spool
(Superseded to 03028643)

$34.99

$

Usually ships in 4-12 days

0

15

Gravely 036891

Spring, Comp. 1.6 Free Length
(Superseded to 08316900)

$

$

Not available

16

Gravely 036886

Nut, Lock #10-24 Twin Whiz
(Superseded to 06530600)

$0.99

$

In Stock, Qty 8

0

17

Gravely 036885

Screw, #10-24x.375 Cap
(Superseded to 05915600)

$1.99

$

Usually ships in 4-12 days

0

18

Gravely 036890

Assembly, Disc.
(Superseded to 03028700)

$54.99

$

Usually ships in 4-12 days

0

19

Gravely 421202

Pin, Spring .187x1.00
(Superseded to 05808800)

$2.99

$

Usually ships in 4-12 days

0

20

Gravely 038821

Washer, Flat .640x1.005x.06
(Superseded to 06401117)

$0.99

$

In Stock, Qty 20+

0

21

Gravely 036888

Cable
(Superseded to 03187100)

$142.99

$

Usually ships in 4-12 days

0

22

Gravely 049103

Clamp, Chute
(Superseded to 02463500)

$

$

Not available

23

Gravely 448423

Screw, Tapping 10-24x.50 HHD
(Superseded to 07410700)

$

$

Not available

24

Gravely 036897

Clamp, Cable
(Superseded to 06900300)

$

$

Not available

25

Gravely 446143

Washer, Flat .188x.375x.049
(Superseded to 06409200)

$

$

Not available

26

Gravely 036896

Taptite, #10-24x.75 PHD
(Superseded to 07406800)

$

$

Not available

27

Gravely 159658

Screw, Mach. 8-32x.75 PHD
(Superseded to 21057100)

$

$

Not available

28

Gravely 049108

Knob, Black
(Superseded to 07530800)

$9.49

$

In Stock, only 1 left!

0

29

Gravely 049107

Cable, Control
(Superseded to 06943400)

$168.99

$

In Stock, only 1 left!

0

30

Gravely 121222

Pin, Cotter .09x.75
(Superseded to 06706900)

$0.99

$

In Stock, Qty 10

0

31

Gravely 049104

Deflector, Chute
(Superseded to 53301800)

$

$

Not available

33

Gravely 036892

Chute, Discharge
(Superseded to 03028353)

$

$

Not available

34

Gravely 049102

Housing, 36" Snowblower
(Superseded to 53504500)

$

$

Not available

35

Gravely 126216

Bolt, Carriage 5/16-18x.75

$

$

Not available

36

Gravely 120915

Bolt, 3/8-16x1.00 Rd Hd Sq Nk

$

$

Not available

37

Gravely 126227

Bolt, 3/8-16x.75 Rd Hd Sq Nk
(Superseded to 06200312)

$1.49

$

In Stock, only 4 left!

0

38

Gravely 036881

Blade, Scraper

$

$

Not available

40

Gravely 036882

Brace, Blade
(Superseded to 03519343)

$

$

Not available

41

Gravely 180120

Bolt, Hex 3/8-16x.75
(Superseded to 05901702)

$1.49

$

In Stock, Qty 20+

0

42

Gravely 120394

Washer, Flat .406x.812x.065
(Superseded to 06401013)

$0.99

$

In Stock, Qty 20+

0

43

Gravely 040825

Skid
(Superseded to 03075553)

$39.99

$

Usually ships in 4-12 days

0

Gravely 033926

Decal, Danger Hand
(Superseded to 05350300)

$31.99

$

Usually ships in 4-12 days

0

Gravely 033927

Decal, Danger Foot
(Superseded to 05350100)

$

$

Not available

Gravely 036906

Decal, Chute Crank
(Superseded to 07878800)

$

$

Not available

Gravely 044077

Decal, Gravely Logo
(Superseded to 03573000)

$

$

Not available
