421823BVE (84880) - Snapper 42" Rear-Engine Riding Mower, 18hp MAIN CASE PT.2 Parts Diagram

42" Rear-Engine Riding Mower, 18hp

MAIN CASE PT.2 Parts Diagram

  • Title
5

Snapper 7028990

COVER, Battery
(Superseded to 7028990YP)

$34.99

$

In Stock, only 1 left!

0

6

Snapper 7073268

COVER, Solenoid (Kohler)
(Superseded to 7073268YP)

$20.99

$

In Stock, only 2 left!

0

14

Snapper 7091511

NUT, 5/16-18 Hex, GR 5 or B
(Superseded to 7091511SM)

Note: Was 90196

$3.49

$

In Stock, Qty 20+

0

15

Snapper 7040598

ARM, Shift Handle (weldment)
(Superseded to 7043201BMYP)

$51.99

$

In Stock, only 2 left!

0

16

Snapper 7010754

SPRING, Shift Detent
(Superseded to 7010754YP)

$6.99

$

Usually ships in 2-12 days

0

17

Snapper 7058763

ASSEMBLY, Speed Adjustment Latch
(Superseded to 7600139YP)

Note: Includes Spring, Part Number 26292

$140.99

$

Usually ships in 2-12 days

0

18

Snapper 7059212

HANDLE, Shift (weldment)
(Superseded to 7059212DYP)

$56.99

$

In Stock, Qty 20+

0

19

Snapper 7015761

SHOULDER BOLT, 5/16-18
(Superseded to 703839)

$5.49

$

In Stock, only 3 left!

0

20

Snapper 7023656

GRIP, Shift Handle
(Superseded to 7023656YP)

$5.99

$

In Stock, Qty 6

0

21

Snapper 7073289

LEVER, Over-Ride
(Superseded to 7073289YP)

$7.49

$

Usually ships in 2-12 days

0

24

Snapper 7091597

COTTER PIN, 3/32 x 3/4"
(Superseded to 703312)

Note: Was 90037

$3.99

$

In Stock, Qty 20+

0

25

Snapper 7023914

PIN, 1/4 x 1-3/4" Tapered Clevis
(Superseded to 7023914YP)

$

$

Not available

26

Snapper 7019245

BUSHING, 3/4 x 1.62 Flange (Nylon)
(Superseded to 7019245YP)

$4.49

$

In Stock, Qty 8

0

27

Snapper 7031036

WASHER, Thrust
(Superseded to 7031036YP)

$3.99

$

Usually ships in 2-12 days

0

28

Snapper 7019246

BUSHING, 3/4 x I.O. Flange (Nylon)
(Superseded to 7019246YP)

$4.49

$

Usually ships in 2-12 days

0

29

Snapper 7090361

SCREW, 5/16-18 x 5/8" Hex Washer Self-Tap
(Superseded to 703949)

$3.99

$

In Stock, Qty 5

0

38

Snapper 7091315

WASHER, .32 x .58 x .08 Split Lock
(Superseded to 703116)

$3.49

$

In Stock, Qty 20+

0

39

Snapper 7091297

NUT, 5/16-24 Hex, GR5
(Superseded to 703331)

$3.99

$

In Stock, Qty 20+

0

46

Snapper 7091595

WASHER, .47 x .92 x .065 Flat
(Superseded to 703183)

$3.99

$

In Stock, only 2 left!

0

47

Snapper 7091298

NUT, 5/16-18 Hex Nyloc
(Superseded to 703902)

$3.99

$

In Stock, Qty 20+

0
