41906 - Gravely Walk-Behind 2-Wheel Tractor, 12hp, 4-Speed, Electric Start Wheels Parts Diagram

Walk-Behind 2-Wheel Tractor, 12hp, 4-Speed, Electric Start

Wheels Parts Diagram

  • Title
1

Gravely 012674

Disc, Inner Wheel
(Superseded to 07133000)

$58.99

$

In Stock, only 2 left!

0

2

Gravely 011645

Tube, 500 x 8
(Superseded to 20075300)

$

$

Not available

2

Gravely 013573

Tube, Tractor Tire
(Superseded to 20124600)

$

$

Not available

3

Gravely 013836

Tire, Tractor Diamond Thread 4.80 x 4.00 - 8
(Superseded to 07132700)

$

$

Not available

3

Gravely 013835

Tire, Tractor Ground Grip 4.00-8
(Superseded to 20140100)

$

$

Not available

3

Gravely 018762

Tire, Semi-Pneumatic 16 x 5W x 3
(Superseded to 07127100)

$387.99

$

Usually ships in 4-12 days

0

3

Gravely 019562

Tire, 18 x 6.50 - 8
(Superseded to 21373000)

$

$

Not available

4

Gravely 012673

Disc, Wheel
(Superseded to 07132900)

$68.99

$

In Stock, only 2 left!

0

5

Gravely 010141

Assembly, Super Grip Wheel 4.00-8
(Superseded to 07132600)

$

$

Not available

5

Gravely 010142

Assembly, Diamond Tread Wheel 4.80x4.00-8
(Superseded to 07132700)

$

$

Not available

5

Gravely 019563

Tire, Wheel Assembly 18x6.50-8
(Superseded to 07127300)

$

$

Not available

5

Gravely 021221

Wheel, Semi-Pneumatic Assembly 16x5Wx3
(Superseded to 07149800)

$

$

Not available

5

Gravely 032260

Assembly, Wheel Semi-Pneumatc 19x5

$

$

Not available

6

Gravely 124829

Nut, Jam 3/8-16 Hex
(Superseded to 06500910)

$0.99

$

In Stock, Qty 20+

0

7

Gravely 120382

Washer, Lock 3/8 Reg.
(Superseded to 06300116)

$0.99

$

In Stock, Qty 20+

0

8

Gravely 428638

Bolt, Hex 3/8-16 x .625
(Superseded to 05940100)

$

$

Not available

8

Gravely 180120

Bolt, Hex 3/8-16 x .750
(Superseded to 05901702)

$1.49

$

In Stock, Qty 20+

0

9

Gravely 023267

Rim, 18x8.50-8
(Superseded to 07127800)

$

$

Not available

10

Gravely 015222

Tire, 18x8.50-8
(Superseded to 07127000)

$

$

Not available

11

Gravely 011191

Assembly, Valve Stem
(Superseded to 07520000)

$2.49

$

In Stock, Qty 5

0

12

Gravely 023268

Assembly, Wheel 18x8.50x8
(Superseded to 07130200)

$170.99

$

Usually ships in 4-12 days

0

13

Gravely 180177

Bolt, Hex 1/2-13 x 1.50
(Superseded to 05901631)

$3.99

$

In Stock, only 1 left!

0

14

Gravely 435507

Nut, Lock 1/2-13
(Superseded to 06500830)

$2.49

$

In Stock, only 3 left!

0

15

Gravely 022551

Hub, For 18x8.50x8 Wheel Assembly
(Superseded to 08526400)

$391.99

$

Usually ships in 4-12 days

0
