41 - Husqvarna Chainsaw (SN: 19941800001 & Above) CLUTCH & OIL PUMP Parts Diagram

Chainsaw

CLUTCH & OIL PUMP Parts Diagram

  • Title

530 03 21-19

Husqvarna 530032119

NEEDLE BEARINGS 36/41

$10.99

$

In Stock, Qty 5

0

530 01 91-74

Husqvarna 530019174

PRESSURE SEAL,OILER 36/41
(Superseded to 545037101)

$10.99

$

In Stock, Qty 7

0

530 01 49-49

Husqvarna 530014949

CLUTCH ASSEMBLY

$22.99

$

In Stock, only 2 left!

0

530 01 56-11

Husqvarna 530015611

FRICTION DISC,CLUTCH 36/41

$6.49

$

In Stock, Qty 6

0

530 01 47-76

Husqvarna 530014776

OIL PICKUP
(Superseded to 545037101)

$10.99

$

In Stock, Qty 7

0

530 06 93-15

Husqvarna 530069315

SPUR SPROCKET
(Superseded to 530047061)

Note: 3/8X6

$17.99

$

In Stock, Qty 5

0

530 01 58-96

Husqvarna 530015896

SCREW

$6.49

$

In Stock, Qty 13

0

530 06 93-16

Husqvarna 530069316

CLUTCH DRUM 325 X 7T

Note: .325X7

$

$

Not available

501 45 74-02

Husqvarna 501457402

RIM SPROCKET 7T .325
(Superseded to 640200010)

$8.49

$

In Stock, Qty 6

0

530 01 59-07

Husqvarna 530015907

THRUST WASHER

$

$

Not available

530 09 41-88

Husqvarna 530094188

CLUTCH SPRING 36/41
(Superseded to 530014949)

$22.99

$

In Stock, only 2 left!

0

530 06 93-42

Husqvarna 530069342

SPUR SPRKT .325 7T 36/41

Note: .325X7

$40.99

$

In Stock, Qty 6

0

530 02 98-33

Husqvarna 530029833

OILER GEAR 36/41

$8.99

$

In Stock, Qty 11

0

530 03 70-47

Husqvarna 530037047

BAR PLATE
(Superseded to 530047855)

$

$

Not available

530 01 44-10

Husqvarna 530014410

OILER ASS'Y 36/41
(Superseded to 545036801)

$20.99

$

In Stock, Qty 6

0
