405 (190-405-100) - Cub Cadet Adapter for 400 with 3-Point Hitch 3 Point Hitch Adapter Parts Diagram

Adapter for 400 with 3-Point Hitch

3 Point Hitch Adapter Parts Diagram

  • Title
1

Cub Cadet 750-0449

Spacer, .688 ID X .88 OD X .88 L

$

$

Not available

2

Cub Cadet 714-0147

Pin, Hitch Clip

$4.99

$

In Stock, Qty 6

0

3

Cub Cadet 738-3040

Shaft, Tiller Mtg

$

$

Not available

4

Cub Cadet 703-0822

Bracket, Tiller Mtg

$

$

Not available

5

Cub Cadet 710-0118

Screw, Hex Cap, 5/16-18 X .75 Lg
(Superseded to 710-3008)

$4.49

$

In Stock, Qty 20+

0

6

Cub Cadet 710-0206

Screw, Hex Cap, 1/4-20 X .88 Lg

$4.49

$

Usually ships in 3-6 days

0

7

Cub Cadet 736-0119

Washer, Lock, 5/16
(Superseded to 936-0119)

$4.99

$

In Stock, Qty 20+

0

8

Cub Cadet 712-0267

Nut, Hex, 5/16-18
(Superseded to 912-3010)

$4.49

$

In Stock, Qty 20+

0

9

Cub Cadet 738-0322

Bolt, Shoulder
(Superseded to 738-0322A)

$6.99

$

In Stock, only 3 left!

0

10

Cub Cadet 703-0820

Link, Short, 1.5 X 5.0 Lg
(Superseded to 703-0820-0637)

Variations

Cub Cadet 703-0820-0637

LINK-SHORT 1.5 X 5 - POWDER BLACK (0637)

$

$

Not available

$

$

11

Cub Cadet 738-0149

Bolt, Shoulder

$

$

Not available

12

Cub Cadet 703-0821

Link, Long, 1.5 X 8.0 Lg

Variations

Cub Cadet 703-0821-0637

LINK-LONG 1.5 x 8. - POWDER BLACK (0637)

$

$

Not available

$

$

13

Cub Cadet 736-0133

Washer, Flat, .406 X 1.25 X .100 Thk

$5.49

$

In Stock, Qty 7

0

14

Cub Cadet 736-0169

Washer, Lock, 3/8

$3.99

$

In Stock, Qty 20+

0

15

Cub Cadet 712-0798

Nut, Hex, 3/8-16

$4.49

$

In Stock, Qty 12

0

16

Cub Cadet 725-1287

Switch Assy, NC Beam Seat

$

$

Not available

Cub Cadet 725-0157

Tie, Cable

$3.99

$

In Stock, Qty 20+

0

17

Cub Cadet 710-0224

Screw, Hex Wash Hd AB Tapp, #10 X .50 Lg
(Superseded to 910-0224)

$3.99

$

In Stock, Qty 20+

0

18

Cub Cadet 726-3004

Nut, Spring, #10 X 1.88 Lg

$

$

Not available

19

Cub Cadet 732-3004

Spring, Compression

$

$

Not available

20

Cub Cadet 720-3001

Cap, Spring

$

$

Not available

21

Cub Cadet 784-0117

Bracket, Seat Switch

$

$

Currently unavailable

22

Cub Cadet 710-0289

Screw, Hex Cap, 1/4-20 X .50 Lg
(Superseded to 910-0289)

$3.99

$

In Stock, only 3 left!

0

23

Cub Cadet 712-0107

Nut, Hex Patch Lock, 1/4-20
(Superseded to 912-0107)

$4.99

$

In Stock, only 1 left!

0

24

Cub Cadet 725-0277

Switch, Safety

$

$

Not available

25

Cub Cadet 725-1296

Plug, Adapter

$

$

Not available

Cub Cadet 725-0157

Tie, Cable

$3.99

$

In Stock, Qty 20+

0
