404437-1209-XX - Briggs & Stratton Horizontal Engine Air Cleaner Grp Parts Diagram

Horizontal Engine

Air Cleaner Grp Parts Diagram

  • Title

84

Briggs & Stratton 91488

Plug, Pipe (1/8")
(Superseded to 794903)

$5.49

$

Usually ships in 2-12 days

0

243

Briggs & Stratton 491289

Screen-Oil Pump
(Superseded to 690761)

$41.99

$

Usually ships in 2-12 days

0

437

Briggs & Stratton 94386

Screw-Sem
(Superseded to 691003)

$3.49

$

In Stock, Qty 9

0

474A

Briggs & Stratton 392595

Stator, Alternator (Tri Circuit, 9Amp Regulated)
(Superseded to 592829)

$102.99

$

Usually ships in 2-12 days

0

474B

Briggs & Stratton 393295

Stator, Alternator
(Superseded to 592830)

Note: (10, 13, or 16 Amp-Depending on Size of Flywheel Magnets) (Regulated)

$101.99

$

In Stock, Qty 20+

0

474

Briggs & Stratton 393474

Stator, Alternator (Dual-Circuit)
(Superseded to 592831)

$101.99

$

In Stock, Qty 8

0

482

Briggs & Stratton 93621

Screw, Tapping Hex
(Superseded to 691183)

$3.49

$

Usually ships in 2-12 days

0

501

Briggs & Stratton 394890

Regulator
(Superseded to 845907)

Note: (10, 13, or 16 Amp, Depending on Size of Flywheel Magnets)

$61.99

$

In Stock, Qty 20+

0

526

Briggs & Stratton 93559

Screw-Tank To Bracket
(Superseded to 690810)

$3.49

$

In Stock, only 3 left!

0

615A

Briggs & Stratton 94412

Ring-Retaining
(Superseded to 690337)

$5.99

$

In Stock, only 1 left!

0

743

Briggs & Stratton 491801

Gear-Drive (Oil Pump)

$16.99

$

Usually ships in 2-12 days

0

814

Briggs & Stratton 392606

Harness Assy (Tri-Circuit)
(Superseded to 691955)

$69.99

$

Usually ships in 2-12 days

0

819

Briggs & Stratton 94366

Screw-Socket
(Superseded to 690333)

$3.99

$

Usually ships in 2-12 days

0

877A

Briggs & Stratton 393537

Alternator Connecto (Tri Circuit & 9amp)

$

$

Not available

877

Briggs & Stratton 393456

WIRE/CONNECTOR, Alternator

$20.99

$

In Stock, only 1 left!

0

878A

Briggs & Stratton 393422

Socket/Wire Assy (Dc Only)
(Superseded to 692306)

$17.99

$

Usually ships in 2-12 days

0

878

Briggs & Stratton 393362

Harness, Alternator (Dual Circuit)
(Superseded to 398661)

$34.99

$

Usually ships in 2-12 days

0

978

Briggs & Stratton 272060

Gasket-Oil Adapter
(Superseded to 691313)

Note: Included in Gasket Set-Part No. 491856

$

$

Not available

1024

Briggs & Stratton 491708

Pump-Oil

$55.99

$

Usually ships in 2-12 days

0

1027

Briggs & Stratton 491056

Filter-Oil (3-1/4" Long)

$9.99

$

In Stock, only 1 left!

0

1028

Briggs & Stratton 491721

Adapter-Oil Filter

$106.99

$

Usually ships in 2-12 days

0

1028

Briggs & Stratton 492675

Adapter-Filter (Remote)

Note: Uses: 492061 Filter Kit (Remote) (18" Hose) or 492062 Filter Kit (Remote) (30" Hose)

$78.99

$

Usually ships in 2-12 days

0

1032

Briggs & Stratton 491710

Spring-Compression

$4.99

$

Usually ships in 2-12 days

0
