40378x11B - Murray 40" Lawn Tractor (2000) Rear Chassis Assembly (part 2) Parts Diagram

40" Lawn Tractor

Rear Chassis Assembly (part 2) Parts Diagram

  • Title
2

Murray MU95190-853

Plate, Lift Detent

$

$

Currently unavailable

3

Murray MU711741

SCREW, #12x.50

$

$

Currently unavailable

33

Murray MU711606

SCREW, 5/16-18 x 0.75

$

$

Currently unavailable

34

Murray MU710136-853

SPRING, Compression

$

$

Currently unavailable

35

Murray MU711610

BOLT, Shoulder 1/4-20

$

$

Currently unavailable

36

Murray MU95293

Zinc Washer Cup

$

$

Currently unavailable

37

Murray MU302635

NUT, 1/4-20 Centerlock

$

$

Currently unavailable

38

Murray MU94200

Cover, Battery

$

$

Currently unavailable

39

Murray MU94154-848

SUPPORT, Seat

$

$

Currently unavailable

40

Murray MU94057

SPRING - Leaf

$

$

Currently unavailable

41

Murray MU711592

SCREW, 1/4-20x.50

$

$

Currently unavailable

42

Murray MU710109-853

SPRING, Compression

$

$

Currently unavailable

43

Murray MU711606

SCREW, 5/16-18 x .75

$

$

Currently unavailable

44

Murray MU95294

Hinge Seat Pivot

$

$

Currently unavailable

45

Murray MU711627

NUT, Push Cap

$

$

Currently unavailable

46

Murray MU95393-853

Battery Bracket, LH

$

$

Currently unavailable

47

Murray MU95394-853

Battery Bracket, RH

$

$

Currently unavailable

48

Murray MU711680

BOLT, Carriage 1/4-20x.63

$

$

Currently unavailable

49

Murray MU711636

NUT, Wing 1/4-20

$

$

Currently unavailable

52

Murray MU711644

WASHER, Flat

$

$

Currently unavailable

53

Murray MU711747

BOLT, Wing 5/16-18x.50

$

$

Currently unavailable

74

Murray MU710026

NUT, 5/16-18

$

$

Currently unavailable

75

Murray MU711891

BOLT, Carriage 5/16-18x.75

$

$

Currently unavailable

82

Murray MU94311-848

Seat Deck Pedal

$

$

Currently unavailable

83

Murray MU94153-848

BRACKET, Pivot Seat

$

$

Currently unavailable

84

Murray MU711606

SCREW, 5/16-18 x .75

$

$

Currently unavailable

85

Murray MU711634

NUT, 5/16-18

$

$

Currently unavailable

100

Murray MU55021

Trim 41.00 Inches

$

$

Currently unavailable
