40320x88 - Murray 40" Lawn Tractor (2000) Fuel Tank & Muffler Assembly Parts Diagram

40" Lawn Tractor

Fuel Tank & Muffler Assembly Parts Diagram

  • Title

1

ENGINE

Note: (See Engine Manual)

$

$

Not available

2

Murray 710199

SCREW, 3/8-16 x 1.25

$66.99

$

Usually ships in 2-12 days

0

5

Murray 692236

GASKET, Exhaust

$5.49

$

In Stock, Qty 20+

0

6

Murray 712064

SCREW, LOCK

$

$

Currently unavailable

7

Murray 712065

SCREW, 5/16-18 x 4.125

$14.99

$

Usually ships in 2-12 days

0

9

Murray 711606MA

SCREW, 5/16-18 x 0.75

$7.99

$

In Stock, only 2 left!

0

10

Murray 95383

STACK PULLEY ASSY.
(Superseded to 95383GS)

$4.99

$

Usually ships in 2-12 days

0

12

Murray 120383

WASHER, SPLITLOCK

$

$

Not available

13

Murray 710248

SCREW, 7/16-20

$3.99

$

Usually ships in 2-12 days

0

14

Murray 092342

FUEL TANK

$

$

Currently unavailable

16

Murray 092317MA

FUEL CAP

$10.99

$

In Stock, Qty 7

0

17

Murray 41007

TUBING, 25 X.50
(Superseded to 7041007YP)

$31.99

$

Usually ships in 2-12 days

0

18

Murray 47345

CLAMP, FUEL LINE
(Superseded to 47345MA)

$9.49

$

Usually ships in 2-12 days

0

19

Murray 325547MA

OIL DRAIN VALVE ASSEMBLY

$

$

Not available

20

Murray 327422

CAP, OIL DRAIN VALVE

$

$

Not available

21

Murray 94361

THROTTLE CONTROL

$8.99

$

Usually ships in 2-12 days

0

22

Murray 711637

SCREW, #8-16 X.38

$

$

Currently unavailable

25

Murray 711592

SCREW, 1/4-20 X.50

$335.99

$

Usually ships in 2-12 days

0

26

Murray 710249

WASHER (18X32)

$

$

Currently unavailable

30

Murray 094951

SPEED CLIP

$

$

Currently unavailable

31

Murray 091271

MUFFLER

$52.99

$

Usually ships in 2-12 days

0

32

Murray 23740

DEFLECTOR EXHAUST

$

$

Currently unavailable

33

Murray 712070

SCREW, #8-32X .38

$10.99

$

Usually ships in 2-12 days

0

34

Murray 95031

HEAT SHIELD

$

$

Currently unavailable

35

Murray 94359

L-BRACKET

$

$

Currently unavailable

36

Murray 94360

L-BRACKET

$

$

Not available

37

Murray 712066

POP-RIVET

$10.99

$

Usually ships in 2-12 days

0

46

Murray 711601

NUT, 1/4-20 REGHEXJAM

$1.99

$

Usually ships in 2-12 days

0

56

Murray 710247

WASHER, FLAT .480X1.00X.25

$8.49

$

Usually ships in 2-12 days

0
