402 s - Shindaiwa Chainsaw (SN: C69915001001 - C69915999999) FUEL SYSTEM Parts Diagram

Chainsaw

FUEL SYSTEM Parts Diagram

  • Title

1

Echo V475003970

TUBE 8×9×16

$0.99

$

In Stock, Qty 6

0

2

Echo V471003840

PIPE, FUEL - 3×5×182 - BLACK
(Superseded to V471003841)

$4.99

$

In Stock, only 1 left!

0

3

Echo V490001271

CLIP 5

$0.99

$

In Stock, Qty 10

0

4

Echo 13211544330

GROMMET, FUEL
(Superseded to 13211544331)

$1.99

$

In Stock, Qty 20+

0

5

Echo V186000520

CONNECTOR, PIPE 5×3.5

$0.99

$

In Stock, Qty 20+

0

6

Echo V490001240

CLIP 6

$0.99

$

Usually ships in 2-4 days

0

7

Echo V471003850

PIPE, FUEL - 3×5×68 - BLACK

$1.49

$

In Stock, only 2 left!

0

8

Echo A369000470

FILTER, FUEL

$8.99

$

In Stock, Qty 20+

0

9

Echo V471001600

PIPE, PULSE 2.4×6×105
(Superseded to V471001601)

$2.49

$

In Stock, only 2 left!

0

10

Echo V490001240

CLIP 6

$0.99

$

Usually ships in 2-4 days

0

11

Echo V471001280

PIPE 2.4×5×105 BLACK
(Superseded to V471001281)

$3.99

$

In Stock, only 1 left!

0

12

Echo V471001470

PIPE, FUEL 2.4×5×200 BLACK
(Superseded to V471001471)

$3.99

$

In Stock, only 1 left!

0

13

Echo A356000031

VENT ASSY

$7.99

$

In Stock, Qty 20+

0

14

Echo 13132840630

HOLDER, VENT

$6.49

$

In Stock, Qty 13

0

15

Echo V490001230

CLIP 6.5 MM

$0.99

$

In Stock, Qty 20+

0

16

Echo 13201239931

PIPE, VENT 3×6×65
(Superseded to 13201239932)

$12.99

$

In Stock, only 1 left!

0

17

Echo P021004562

CAP ASSY, FUEL

Note: Includes Items 18-19

$10.99

$

Usually ships in 2-4 days

0

18

Echo V581000610

O-RING 22

$0.99

$

In Stock, Qty 9

0

19

Echo A365000050

CONNECTOR, CAP L= 60 MM

$2.49

$

In Stock, Qty 20+

0
