38855 (1028 OHXE) - Toro 28" Power Max Heavy-Duty Snow Thrower (SN: 405897400 - 406309999) Engine Assembly No. 1 Parts Diagram

28" Power Max Heavy-Duty Snow Thrower

Engine Assembly No. 1 Parts Diagram

  • Title

1

Toro 133-9823

CAP-FUEL

$19.99

$

In Stock, Qty 13

0

2

Toro 136-7802

FUEL TANK AND CAP KIT

$119.99

$

Usually ships in 3-6 days

0

3

Toro 121-0349

FUEL TANK COVER KIT

$71.99

$

Usually ships in 3-6 days

0

4

Toro 121-0347

REAR PANEL AND HARDWARE KIT

$71.99

$

Usually ships in 3-6 days

0

5

Toro 121-0351

TANK MOUNT BRACKET KIT

$37.99

$

Usually ships in 3-6 days

0

6

Toro 136-7800

ELECTRIC STARTER KIT

$371.99

$

Usually ships in 3-6 days

0

6:2

Toro 121-0298

SCREW-HHF

$1.99

$

Usually ships in 3-6 days

0

6:3

Toro 121-0306

SCREW-BHP

$1.49

$

In Stock, Qty 7

0

6:4

Toro 121-0312

WASHER-PLAIN

$1.49

$

In Stock, only 3 left!

0

7

Toro 121-4103

SWITCH BOX BRACKET KIT

$21.99

$

Usually ships in 3-6 days

0

8

Toro 121-4109

FUEL SHUT-OFF VALVE KIT

$19.99

$

Usually ships in 3-6 days

0

9

Toro 136-7801

FUEL LINE KIT
(Superseded to 139-0598)

$31.99

$

In Stock, only 1 left!

0

9:1

Toro 121-0087

CLAMP-HOSE

$1.49

$

In Stock, only 3 left!

0

10

Toro 121-4105

FRONT PANEL KIT

$59.99

$

Usually ships in 3-6 days

0

11

Toro 121-0274

RECOIL SHROUD KIT

$93.99

$

Usually ships in 3-6 days

0

12

Toro 121-0342

RECOIL KIT

$95.99

$

In Stock, only 1 left!

0

13

Toro 121-0287

HANDLE-RECOIL

$13.99

$

In Stock, only 1 left!

0
