38590 (1232) - Toro 32" Power Shift Snow Thrower (SN: 079000001 - 079999999) (1997) ENGINE ASSEMBLIES OHSK 120-222023F AND 120-222024F Parts Diagram

32" Power Shift Snow Thrower

ENGINE ASSEMBLIES OHSK 120-222023F AND 120-222024F Parts Diagram

  • Title

1

Tecumseh 35677A

Cylinder (Incl. Ref.# 2, 20, 72 & 80)

$165.99

$

Usually ships in 3-12 days

0

2

Tecumseh 27652

Pin-Dowel

$2.49

$

Usually ships in 3-12 days

0

3

Tecumseh 650820

Screw (1/4-20x1/2)

$3.99

$

In Stock, Qty 15

0

5

Tecumseh 30969

Cap-Pipe

$5.49

$

In Stock, only 1 left!

0

14

Tecumseh 28277

Washer-Flat

$1.99

$

In Stock, only 4 left!

0

14A

Tecumseh 28558

Washer

$1.99

$

Usually ships in 3-12 days

0

15

Tecumseh 35685

Governor Rod (Incl. Ref.#14 & 38)

$7.49

$

Usually ships in 3-12 days

0

16

Tecumseh 35686

Governor Lever
(Superseded to 35686A)

$1.99

$

In Stock, only 1 left!

0

17

Tecumseh 29916

Clamp-Lever, Governor

$1.99

$

In Stock, only 2 left!

0

18

Tecumseh 650548

Screw
(Superseded to 651018)

$1.99

$

In Stock, Qty 8

0

19

Tecumseh 35688

Throttle Spring

$3.99

$

In Stock, only 1 left!

0

20

Tecumseh 35319

Seal-Oil

$4.99

$

In Stock, only 2 left!

0

25

Tecumseh 36460

Baffle-Housing, Blower
(Superseded to 37853)

$11.99

$

In Stock, only 1 left!

0

26

Tecumseh 650561

Screw (1/4-20x19/32)

$1.99

$

In Stock, only 2 left!

0

28

Tecumseh 30322

Nut-Lock

$1.99

$

Usually ships in 3-12 days

0

30

Tecumseh 36706

Crankshaft

$

$

Not available

31

Tecumseh 35327

Counterbalance Gear

$18.99

$

Usually ships in 3-12 days

0

35

Tecumseh 29826

Screw

$1.99

$

In Stock, only 4 left!

0

36

Tecumseh 29918

Washer-Lock

$1.99

$

In Stock, Qty 5

0

37

Tecumseh 29216

Nut-Lock

$1.99

$

In Stock, only 3 left!

0

38

Tecumseh 29642

Ring-Retaining

$100.99

$

In Stock, only 2 left!

0

40

Tecumseh 35776

Set-Piston, Pin & Ring (Std.
(Superseded to 35776B)

$54.99

$

Usually ships in 3-12 days

0

40

Tecumseh 35777

Piston, Pin & Ring Set (.010)
(Superseded to 35777A)

$

$

Not available

40

Tecumseh 35778

55079/55080 PLYMOUT
(Superseded to 35778A)

$158.99

$

Usually ships in 3-12 days

0

41

Tecumseh 35773

Piston & Pin Ass-y (Std.)(Incl. Ref.#43)
(Superseded to 35776B)

$54.99

$

Usually ships in 3-12 days

0

41

Tecumseh 35774

Piston & Pin Ass-y (.010)(Incl. Ref.#43)
(Superseded to 35777A)

$

$

Not available

41

Tecumseh 35775

Piston & Pin Asm. (.020)(Incl. Ref.# 43)
(Superseded to 35778A)

$158.99

$

Usually ships in 3-12 days

0

42

Tecumseh 35779

Ring Set (STD)

$44.99

$

In Stock, only 1 left!

0

42

Tecumseh 35780

Ring Set (.010)

$

$

Not available

42

Tecumseh 35781

Ring Set (.020)

$

$

Not available

43

Tecumseh 35772

Retaining Ring-Piston Pin

$1.99

$

In Stock, only 4 left!

0

45

Tecumseh 35681

Connecting Rod Asm. (Incl. Ref.# 46 & 47)
(Superseded to 36898A)

$52.99

$

In Stock, only 1 left!

0

46

Tecumseh 650908

Bolt-Rod
(Superseded to 651063)

$1.99

$

In Stock, only 3 left!

0

47

Tecumseh 650882

Bolt-Rod
(Superseded to 651033A)

$

$

Not available

48

Tecumseh 35313

Lifter-Valve
(Superseded to 35313A)

$

$

Not available

50

Tecumseh 35682A

Camshaft

$105.99

$

Usually ships in 3-12 days

0

51

Tecumseh 35315A

Counterbalance Weight

$95.99

$

Usually ships in 3-12 days

0

60

Tecumseh 35316A

Extension-Housing, Blower

$3.99

$

Usually ships in 3-12 days

0

61

Tecumseh 34126

Bracket

$1.99

$

Usually ships in 3-12 days

0

62

Tecumseh 650760

Screw (8-32 x 3/8)

$1.99

$

In Stock, only 2 left!

0

63

Tecumseh 28545

Grommet

$1.99

$

In Stock, only 4 left!

0

65

Tecumseh 650128

Screw

$5.49

$

Usually ships in 3-12 days

0

66

Tecumseh 650561

Screw (1/4-20x19/32)

$1.99

$

In Stock, only 2 left!

0

69

Tecumseh 35683

55072/75/86/89 TWO

$3.99

$

Usually ships in 3-12 days

0

70

Tecumseh 35684A

Cylinder Cover (Incl. Ref.#14,15,38,71,75)
(Superseded to 35684B)

$

$

Not available

71

Tecumseh 35377

Bushing-Crankshaft

$11.99

$

In Stock, only 3 left!

0

75

Tecumseh 35319

Seal-Oil

$4.99

$

In Stock, only 2 left!

0

80

Tecumseh 35751

Governor Shaft

$

$

Not available

81

Tecumseh 35479

Washer
(Superseded to 651080)

$1.99

$

In Stock, Qty 8

0

82

Tecumseh 35321

Gear-Asm Governor

$9.49

$

In Stock, only 1 left!

0

83

Tecumseh 35322

Governor Spool

$1.99

$

In Stock, Qty 5

0

84

Tecumseh 29193

Ring-Retaining

$1.99

$

In Stock, only 4 left!

0

86

Tecumseh 650833

Screw (1/4-20x1-3/16)

$1.99

$

Usually ships in 3-12 days

0

87

Tecumseh 650832

Screw (1/4-20x1-11/16)

$

$

Not available

89

Tecumseh 32589

Key-Flywheel

$1.49

$

In Stock, only 4 left!

0

90

Tecumseh 611094

Flywheel (W/Ring Gear)

$

$

Not available

90

Tecumseh 611093

Flywheel ASM

$

$

Not available

92

Tecumseh 650880

Washer-Belleville

$1.99

$

In Stock, only 3 left!

0

93

Tecumseh 650881

Nut-Flywheel

$1.99

$

Usually ships in 3-12 days

0

100

Tecumseh 35135

Solid State ASM
(Superseded to 35135B)

$62.99

$

Usually ships in 3-12 days

0

101

Tecumseh 610118

Cover-Spark Plug

$6.49

$

In Stock, only 2 left!

0

102

Tecumseh 650872

Stud
(Superseded to 651024)

$3.99

$

In Stock, only 2 left!

0

103

Tecumseh 651007

Screw (T-15, 10-24 x 15/16)

$1.99

$

In Stock, only 4 left!

0

110

Tecumseh 35253

Ground Wire

$6.49

$

In Stock, only 2 left!

0

119

Tecumseh 35306A

Cylinder Head Gasket

$11.99

$

In Stock, only 1 left!

0

125

Tecumseh 35308

Exhaust Valve (Std.)

$70.99

$

Usually ships in 3-12 days

0

125

Tecumseh 35433

Exhaust Valve (1/32)

$119.99

$

Usually ships in 3-12 days

0

126

Tecumseh 35309

Intake Valve (Std.)

$33.99

$

Usually ships in 3-12 days

0

126

Tecumseh 35432

Intake Valve (1/32)

$96.99

$

Usually ships in 3-12 days

0

158

Tecumseh 35466

Rod-Push

$14.99

$

In Stock, only 2 left!

0

169

Tecumseh 27896A

Gasket-Cover, Valve

$1.49

$

In Stock, Qty 10

0

170

Tecumseh 28423

Body-Breather

$13.99

$

In Stock, only 1 left!

0

171

Tecumseh 28424

Element-Breather

$3.99

$

In Stock, only 3 left!

0

172

Tecumseh 28425

Cover-Valve

$7.49

$

In Stock, only 1 left!

0

173

Tecumseh 35350

Tube-Breather

$6.49

$

Usually ships in 3-12 days

0

174

Tecumseh 650128

Screw

$5.49

$

Usually ships in 3-12 days

0

179

Tecumseh 30593

Retainer Clip

$1.99

$

In Stock, only 1 left!

0

182

Tecumseh 650517

Screw (T-30, 1/4-20 X 27-32)

$1.99

$

In Stock, only 1 left!

0

183

Tecumseh 34583A

Bracket-Choke

$12.99

$

In Stock, Qty 6

0

184

Tecumseh 33263

Gasket-Carburetor To Intake Pipe

$1.49

$

In Stock, Qty 20+

0

186

Tecumseh 35691

Governor Link

$2.49

$

In Stock, only 1 left!

0

186B

Tecumseh 36653

Spring-Choke

$1.99

$

In Stock, only 2 left!

0

200

Tecumseh 35702

Control Bracket (Incl. Ref.#203, 204 & 206)

$38.99

$

In Stock, only 1 left!

0

202

Tecumseh 36482

Compression Spring

$3.99

$

In Stock, only 1 left!

0

203

Tecumseh 31342

Spring-Compression

$5.99

$

In Stock, only 1 left!

0

204

Tecumseh 650549

Screw
(Superseded to 651029)

$1.99

$

In Stock, only 2 left!

0

205

Tecumseh 650777

Screw
(Superseded to 651019)

$1.99

$

In Stock, Qty 5

0

206

Tecumseh 610973

Terminal

$3.99

$

In Stock, Qty 5

0

207

Tecumseh 35692

Choke Link

$3.49

$

Usually ships in 3-12 days

0

209

Tecumseh 650821

Screw (10-32 x 1/2)

$1.99

$

In Stock, only 3 left!

0

212

Tecumseh 30773A

Bushing

$

$

Not available

213

Tecumseh 650930

Screw

$

$

Not available

215

Tecumseh 35440

Knob-Control

$3.99

$

Usually ships in 3-12 days

0

216

Tecumseh 35679

Lever-Adjusting

$6.49

$

Usually ships in 3-12 days

0

219

Tecumseh 35689

Rod-Choke

$

$

Not available

220

Tecumseh 35438

Knob-Control

$3.99

$

In Stock, only 1 left!

0

222

Tecumseh 28820

Screw (10-32 x 1/2)
(Superseded to 651081)

$4.49

$

In Stock, only 3 left!

0

260

Tecumseh 35694

Blower Housing
(Superseded to 35694A)

$74.99

$

Usually ships in 3-12 days

0

261

Tecumseh 30063

Screw

$1.99

$

In Stock, Qty 20+

0

262

Tecumseh 29747B

Screw

$1.99

$

In Stock, Qty 9

0

281

Tecumseh 33013

Screw

$3.99

$

Usually ships in 3-12 days

0

282

Tecumseh 650760

Screw (8-32 x 3/8)

$1.99

$

In Stock, only 2 left!

0

285

Tecumseh 35985B

Cup-Starter
(Superseded to 35985C)

$13.99

$

In Stock, only 1 left!

0

287

Tecumseh 29752

Nut and Lock Washer (1/4-28)

$1.99

$

In Stock, only 3 left!

0

305

Tecumseh 35574

Tube-Fill, Oil

$5.49

$

In Stock, only 1 left!

0

307

Tecumseh 35499

O-Ring

$1.49

$

In Stock, only 3 left!

0

308

Tecumseh 35539

Clip-Tube, Fill

$1.99

$

Usually ships in 3-12 days

0

310

Tecumseh 35700

Dipstick

$7.49

$

Usually ships in 3-12 days

0

314

Tecumseh 650873

Screw (1/4-20 x 3/4)

$1.99

$

Usually ships in 3-12 days

0

315

Tecumseh 611104

Alternator Coil (3/5 Split)(Incl. Ref.#321-323)(Model 38591 Only)

$146.99

$

Usually ships in 3-12 days

0

315

Tecumseh 611111

Coil-Alternator, 18 Watt

$68.99

$

Usually ships in 3-12 days

0

321

Tecumseh 611161

Diode

$17.99

$

Usually ships in 3-12 days

0

322

Tecumseh 611142

Body-Connector

$3.99

$

Usually ships in 3-12 days

0

323

Tecumseh 611118

Terminal

$1.99

$

Usually ships in 3-12 days

0

334

Tecumseh 650257

Screw (8-32 X 5/16)

$1.49

$

In Stock, Qty 17

0

335

Tecumseh 35698

Carburetor Cover

$

$

Not available

335A

Tecumseh 35693

Carburetor Cover

$

$

Not available

336

Tecumseh 650765

Screw (10-32x1/2)

$1.49

$

In Stock, only 4 left!

0

338

Tecumseh 650821

Screw (10-32 x 1/2)

$1.99

$

In Stock, only 3 left!

0

341

Tecumseh 35697

Bracket-Fuel Tank

$

$

Not available

350

Tecumseh 570682

Primer-Asm
(Superseded to 570682A)

$10.99

$

In Stock, only 4 left!

0

351

Tecumseh 32180C

Line-Primer

$6.99

$

In Stock, only 4 left!

0

355

Tecumseh 590574

Handle-Starter, Mitten Grip

$5.49

$

Usually ships in 3-12 days

0

370

Tecumseh 36261

Decal-Lubrication

$

$

Not available

370K

Tecumseh 36695

Decal-Tecumseh Logo for Top of Recoil Starter

$2.49

$

In Stock, only 4 left!

0

380

Tecumseh 632536

Carburetor (Incl. Ref.# 184)
(Superseded to 640105)

$106.99

$

In Stock, only 1 left!

0

390

Tecumseh 590733

Starter-Rewind
(Superseded to 590789)

$87.99

$

In Stock, only 1 left!

0

396

Tecumseh 33329D

Starter-Electric (110 Volt)
(Superseded to 33329E)

$

$

Not available

420

Tecumseh 730226

Oil-Engine (SAE 5W30)
(Superseded to 730226B)

$13.99

$

In Stock, Qty 9

0
