38430 (CCR 3000) - Toro Snow Thrower (SN: 089000001 - 089999999) (1998) ENGINE ASSEMBLY (MODEL NO. 38435 & 38436) Parts Diagram

Snow Thrower

ENGINE ASSEMBLY (MODEL NO. 38435 & 38436) Parts Diagram

  • Title
1

$

$

Not available

2

Toro 81-2700

SPIT CUP

$21.99

$

Usually ships in 3-6 days

0

3

Toro 81-2710

Screw
(Superseded to 81-2160)

$4.99

$

Usually ships in 3-6 days

0

4

Toro 81-2720

VALVE

$

$

Not available

5

Toro 81-2910

SHAFT

$

$

Not available

6

Toro 81-5530

LOWER CHOKE RING

$15.99

$

Usually ships in 3-6 days

0

7

Toro 81-5520

UPPER CHOKE RING

$15.99

$

Usually ships in 3-6 days

0

8

Toro 81-5510

SHAFT
(Superseded to 81-4270)

$

$

Not available

9

Toro 81-2920

SHAFT

$

$

Not available

10

Toro 95-7941

JET - PILOT
(Superseded to 81-2930)

$28.99

$

Usually ships in 3-6 days

0

11

Toro 81-2940

VALVE

$

$

Not available

13

Toro 81-0460

CARB INSULATOR

$31.99

$

Usually ships in 3-6 days

0

14

$

$

Not available

15

Toro 81-0470

MANIFOLD

$

$

Not available

16

Toro 81-2570

Gasket-Carburetor
(Superseded to 81-0780)

$6.99

$

In Stock, Qty 7

0

17

Toro 95-7937

ADJUSTER

$

$

Not available

18

Toro 95-7938

CAP - ADJUSTER

$

$

Not available

19

Toro 81-2580

SPRING-PILOT SCREW

$

$

Not available

20

Toro 81-2590

SPRING

$

$

Not available

21

Toro 95-7936

NOZZLE - MAIN

$

$

Not available

22

Toro 81-1040

MAIN JET

$29.99

$

Usually ships in 3-6 days

0

23

Toro 95-7940

JET - MAIN

$48.99

$

In Stock, only 1 left!

0

24

Toro 81-2600

PIN-HINGE

$8.49

$

Usually ships in 3-6 days

0

25

Toro 95-7939

SPRING

$

$

Not available

26

Toro 81-4920

FLOAT

$54.99

$

Usually ships in 3-6 days

0

27

Toro 81-2630

FLOAT BOWL GASKET

$12.99

$

Usually ships in 3-6 days

0

28

$109.99

$

Usually ships in 3-6 days

0

29

Toro 81-2650

GASKET

$6.99

$

Usually ships in 3-6 days

0

30

Toro 81-2660

SCREW

$29.99

$

In Stock, only 2 left!

0

31

Toro 81-4930

SPACER

$9.49

$

Usually ships in 3-6 days

0

32

Toro 81-4700

NEEDLE
(Superseded to 81-5820)

$45.99

$

In Stock, only 2 left!

0

33

Toro 81-5820

SEAT KIT

$45.99

$

In Stock, only 2 left!

0

34

Toro 81-2670

SCREW

$11.99

$

Usually ships in 3-6 days

0

35

Toro 81-2680

GASKET

$6.49

$

In Stock, only 3 left!

0

Toro 95-7935

ASM - CARBURETOR

$

$

Not available
