38310 - Lawn-Boy Power Shovel Snow Thrower (SN: 005000001 - 005999999) (1985) ROTOR HOUSING ASSEMBLY Parts Diagram

Power Shovel Snow Thrower

ROTOR HOUSING ASSEMBLY Parts Diagram

  • Title
1

Lawn-Boy 218-517

Pin Housing

$

$

Not available

2

Lawn-Boy 41-9920

Motor
(Superseded to 43-2590)

$

$

Not available

3

Lawn-Boy 42-0050

Filter-Foam

$7.49

$

Usually ships in 3-6 days

0

4

Lawn-Boy 42-2910

Retainer-Filters

$

$

Not available

5

Lawn-Boy 41-9840

Decal-Handle Support

$

$

Not available

6

Lawn-Boy 42-2850

Handle Support-Front

$

$

Not available

7

Lawn-Boy 32104-118

Screw-Pan Head

$

$

Not available

8

Lawn-Boy 42-2860

Handle Support-Back
(Superseded to 16-9389)

$

$

Not available

9

Lawn-Boy 3250-20

Screw-Pan Head

$6.99

$

In Stock, only 3 left!

0

10

Lawn-Boy 32144-36

Screw-Pan Head

$1.49

$

In Stock, Qty 6

0

11

Lawn-Boy 32144-65

Screw-Phillips Truss

$

$

Not available

$37.99

$

In Stock, only 1 left!

0

13

Lawn-Boy 53-9390

Block-Mounting

$

$

Not available

14

Lawn-Boy 38-8570

Coupling-Drive

$51.99

$

Usually ships in 3-6 days

0

15

Lawn-Boy 424240

Drive Gear (Incl. Ref. #16)

$

$

Currently unavailable

16

Lawn-Boy 424010

Bushing-Drive Gear

$

$

Currently unavailable

17

Lawn-Boy 53-9300

Gear Carrier
(Superseded to 53-9300-03)

$89.99

$

Usually ships in 3-6 days

0

18

Lawn-Boy 32104-121

Screw-Pan Head
(Superseded to 94-4496)

$1.49

$

In Stock, Qty 20+

0

19

Lawn-Boy 53-9320

Idler Gear Assembly

$

$

Not available

20

Lawn-Boy 42-0230

Rotor Gear Assembly (Incl. Ref. #21)

$

$

Not available

21

Lawn-Boy 41-9890

Bushing-Rotor

$

$

Not available

22

Lawn-Boy 41-9830

Scraper
(Superseded to 99-5386)

$32.99

$

In Stock, Qty 5

0

23

Lawn-Boy 53-9380

Housing
(Superseded to 16-3379)

$

$

Not available

24

Lawn-Boy 38-8580

Washer-Felt

$9.99

$

Usually ships in 3-6 days

0

25

Lawn-Boy 42-0070

Washer-Rotor

$

$

Not available

26

Lawn-Boy 3296-13

Locknut-Thin

$4.49

$

In Stock, Qty 20+

0

27

Lawn-Boy 3296-54

Locknut-Thin

$5.49

$

In Stock, only 2 left!

0

28

Lawn-Boy 3250-19

Screw-Pan Head

$2.49

$

Usually ships in 3-6 days

0

29

Lawn-Boy 3296-5

Nut-Lock

$3.49

$

In Stock, Qty 8

0

30

Lawn-Boy 3256-24

Flat Washer

$0.99

$

In Stock, Qty 14

0

31

$117.99

$

Usually ships in 3-6 days

0

32

Lawn-Boy 41-9960

Cover, Right Side

$31.99

$

Usually ships in 3-6 days

0

33

Lawn-Boy 38-8210

Pin-Rotor

$

$

Not available
