38025 (1800) - Toro Power Curve Snow Thrower (SN: 000000001 - 000999999) (1990) HOUSING & ROTOR ASSEMBLY Parts Diagram

Power Curve Snow Thrower

HOUSING & ROTOR ASSEMBLY Parts Diagram

  • Title
1

Toro 73-0220

PLATE - SIDE, PAINTED

$

$

Not available

2

Toro 32104-121

Screw
(Superseded to 94-4496)

$1.49

$

In Stock, Qty 20+

0

3

Toro 32112-1

PUSHNUT-CAP, WASHER

$6.49

$

Usually ships in 3-6 days

0

4

Toro 73-0440

Wheel

$

$

Not available

5

Toro 249-42

U-CLIP

$

$

Not available

6

Toro 73-0250

SLEEVE, AXLE

$

$

Not available

7

Toro 73-0370

Shaft-Axle

$12.99

$

Usually ships in 3-6 days

0

8

Toro 73-0450

Decal-Danger
(Superseded to 104-9382)

$

$

Not available

9

Toro 249-44

CORD CLIP

$

$

Not available

10

Toro 218-511

Connector

$

$

Not available

11

Toro 73-0300

Shroud-Housing
(Superseded to 73-0301)

$

$

Not available

12

Toro 256-307

BUSHING

$

$

Not available

13

Toro 73-0280

Tube-Lower Handle
(Superseded to 104-9365-03)

$85.99

$

Usually ships in 3-6 days

0

14

Toro 73-0270

WIRE HARNESS-TORO 1800

$

$

Not available

15

Toro 73-0460

DECAL - WARNING

$

$

Not available

16

Toro 73-1800

Filter-Foam

$

$

Not available

17

Toro 32144-88

Screw-Pan Head

$1.99

$

In Stock, only 2 left!

0

18

Toro 73-0120

Strap-Motor

$

$

Not available

19

Toro 32104-97

SCREW-HH

$6.99

$

Usually ships in 3-6 days

0

20

Toro 73-0080

Motor

$

$

Not available

21

Toro 73-1540

IDLER BRACKET ASSEMBLY

$

$

Not available

22

Toro 3256-49

WASHER-PLAIN

$0.99

$

In Stock, Qty 8

0

23

Toro 32144-34

SCREW-HWHTF

$4.99

$

In Stock, Qty 7

0

24

Toro 73-0110

PULLEY - DRIVER

$14.99

$

Usually ships in 3-6 days

0

25

Toro 73-0160

BELT-PULLEY, IDLER/DRIVER

$33.99

$

In Stock, only 3 left!

0

26

Toro 73-0210

BELT-DRIVE

$

$

Not available

27

Toro 32120-46

RING-RETAINING

$2.49

$

Usually ships in 3-6 days

0

28

Toro 73-1910

Pulley-Idler (Incl. Ref. #29)

$

$

Not available

29

Bearing-Needle

$

$

Not available

30

Toro 73-0041

WASHER-THRUST

$1.99

$

In Stock, only 1 left!

0

31

Toro 73-0070

PULLEY, DRIVEN

$

$

Not available

32

Toro 73-0090

Clamp-Motor Bracket

$

$

Not available

33

Toro 73-0200

HOUSING, ROTOR, 1800

$

$

Not available

34

Toro 73-0990

Shaft-Driver, Rotor

$47.99

$

Usually ships in 3-6 days

0

35

Toro 73-0860

Coupler-Rotor

$18.99

$

Usually ships in 3-6 days

0

36

Toro 73-0400

Rotor
(Superseded to 73-8590)

$40.99

$

In Stock, Qty 8

0

37

Toro 73-1610

Scraper
(Superseded to 99-5390)

$

$

Not available

38

Toro 73-0040

WASHER-THRUST

$1.99

$

Usually ships in 3-6 days

0

39

Toro 73-1900

Bracket-Wheel (Incl. Ref. #41)

$

$

Not available

40

Toro 3290-271

RIVET-POP

$0.99

$

Usually ships in 3-6 days

0

41

Bearing-Ball

$

$

Not available

42

Toro 73-0020

Shaft-Rotor
(Superseded to 107-3341)

$73.99

$

Usually ships in 3-6 days

0

43

Toro 73-1570

Skid-Housing

$34.99

$

In Stock, Qty 7

0

44

Toro 64-5820

Relief-Strain

$

$

Not available
