3660 (53AB5B8J100) - Cub Cadet 60" Zero-Turn Mower 23HP Kawasaki Engine Assembly Parts Diagram

60" Zero-Turn Mower

23HP Kawasaki Engine Assembly Parts Diagram

  • Title

1

Cub Cadet 00005763

Hex Nut, 7/16-14
(Superseded to 912-3019)

$6.99

$

In Stock, only 1 left!

0

2

Cub Cadet 00006129

HHCS, 5/16-18, 1-3/4

$6.99

$

Usually ships in 3-6 days

0

3

Cub Cadet 00013406

Hex Cap Screw, 5/16-18 x 3/4
(Superseded to 710-3008)

$4.49

$

In Stock, Qty 20+

0

4

Cub Cadet 00014602

Round Hd. Machine Screw, 10-32 x 3/4

$

$

Not available

5

Cub Cadet 00014608

Lock Nut, Nylon Insert, 10-32
(Superseded to 712-05003)

$3.49

$

In Stock, only 3 left!

0

6

Cub Cadet 01005856

Key, 1/4 x 1/4 x 3

$11.99

$

In Stock, only 1 left!

0

7

Cub Cadet 00022560

Flange Lock, Hex Nut, 3/8-16
(Superseded to 712-05007)

$4.49

$

In Stock, Qty 20+

0

8

Cub Cadet 00060056

Nut Washer, W/Star, 8-32

$6.99

$

In Stock, only 1 left!

0

9

Cub Cadet 00060078

Grease Fitting, 1/4-28 x 3/16
(Superseded to 737-04345)

$4.99

$

In Stock, Qty 6

0

10

Cub Cadet 01000199

Extension Spring, 1.0 OD x 5.125

$17.99

$

In Stock, only 4 left!

0

11

Cub Cadet 01000302

Shoulder Screw, 7/16-14
(Superseded to 738-3102)

$21.99

$

In Stock, only 1 left!

0

12

Cub Cadet 01000364

Hex Carriage Screw, 3/8-16, 1.75
(Superseded to 710-0560)

$6.99

$

In Stock, Qty 11

0

13

Cub Cadet 01000389

Lock Washer, 7/16
(Superseded to 936-0171)

$4.49

$

In Stock, only 4 left!

0

14

Cub Cadet 01000635

Hexflange Lock Nut, 5/16-18
(Superseded to 712-3004A)

$3.99

$

In Stock, Qty 20+

0

15

Cub Cadet 01000721

Machine Screw, 8-32, .375
(Superseded to 710-3217)

$6.99

$

In Stock, Qty 7

0

16

Cub Cadet 01000728

Clip, Heat Shield Cable
(Superseded to 726-04124)

$3.99

$

Usually ships in 3-6 days

0

18

Cub Cadet 01001395

Capscrew, 7/16-20 x 2.50

$4.99

$

In Stock, only 2 left!

0

19

Cub Cadet 01001979

Clutch Brake, 1.125 ID
(Superseded to 01001979P)

$988.99

$

Usually ships in 3-6 days

0

20

Cub Cadet 01002601

Hex Cap Screw, 3/8-16, .750
(Superseded to 710-0216)

$4.49

$

In Stock, Qty 15

0

21

Cub Cadet 01006456

Retainer Clutch Assembly, Ogura

$

$

Not available

22

Cub Cadet 01003269

Flat Washer, 7/16 ID x 1.75 OD x .25
(Superseded to 736-3082A)

$9.99

$

In Stock, Qty 16

0

23

Cub Cadet 01003271

Choke, Control Cable, 43.0
(Superseded to 01003271P)

$

$

Not available

24

Cub Cadet 01003272

Throttle, Control Cable, 39.0
(Superseded to 01003272P)

$43.99

$

In Stock, only 1 left!

0

25

Cub Cadet 01003283

Oil Drain Hose

$84.99

$

Usually ships in 3-6 days

0

25

Cub Cadet 737-0103

Oil Drain Plug
(Superseded to 737-04202)

Note: not shown

$6.99

$

Usually ships in 3-6 days

0

26

Cub Cadet 01003615

23HP Kawasaki Engine

$

$

Not available

27

Cub Cadet 01004004

Control Throttle Knob
(Superseded to 731-04914)

$13.99

$

Usually ships in 3-6 days

0

28

Cub Cadet 01004081

Flat Pulley with Flanges
(Superseded to 02005077)

$35.99

$

In Stock, Qty 20+

0

29

Cub Cadet 01004991

Muffler Accessory, Kawasaki
(Superseded to 01009299P)

$

$

Not available

30

Cub Cadet 01005006

Engine Idler Arm Assembly includes:

$120.99

$

Usually ships in 3-6 days

0

30

Cub Cadet 01000308

Bearing
(Superseded to 741-04555)

Note: not shown

$16.99

$

In Stock, Qty 18

0

31

Cub Cadet 01005010

V Belt, A Section x .47.3
(Superseded to 01005010P)

$66.99

$

In Stock, only 2 left!

0

32

Cub Cadet 01005084

Tube Clamp, 1.375

$

$

Not available

33

Cub Cadet 01005085

Muffler Accessory Exhaust Tube

$

$

Not available

34

Cub Cadet 01005104

Pump Drive Pulley
(Superseded to 756-06263)

$92.99

$

In Stock, only 1 left!

0

35

Cub Cadet 01005314

Flat Washer, 7/16 ID x 1.75 OD x .25
(Superseded to 736-04131)

$15.99

$

In Stock, only 1 left!

0
