324 RX - Husqvarna String Trimmer (Original) HANDLE & CONTROLS Parts Diagram

String Trimmer

HANDLE & CONTROLS Parts Diagram

  • Title

537 16 02-09

Husqvarna 537160209

HANDLE HALF LEFT

Note: Without hole for Steering wheel assy

$20.99

$

Usually ships in 3-10 days

0

537 16 12-01

Husqvarna 537161201

SCREW

Note: Does not fit with HANDLE HALF 537 16 02-09

$3.49

$

Usually ships in 3-10 days

0

506 49 77-01

Husqvarna 506497701

THROTTLE CONTROL

$12.99

$

In Stock, only 1 left!

0

537 17 42-01

Husqvarna 537174201

SPRING

$6.49

$

In Stock, Qty 7

0

537 17 44-01

Husqvarna 537174401

PLATE

Note: Does not fit with HANDLE HALF 537 16 02-09

$43.99

$

Usually ships in 3-10 days

0

503 22 10-13

Husqvarna 503221013

NUT

$7.49

$

In Stock, only 1 left!

0

537 16 07-01

Husqvarna 537160701

LOCKOUT STARTER THROTTLE
(Superseded to 537160703)

$5.99

$

Usually ships in 3-10 days

0

503 20 07-35

Husqvarna 503200735

SCREW
(Superseded to 503200782)

$4.99

$

In Stock, only 1 left!

0

537 16 03-02

Husqvarna 537160302

HANDLE

$20.99

$

Usually ships in 3-10 days

0

537 16 09-01

Husqvarna 537160901

STEERING WHEEL

Note: Does not fit with HANDLE HALF 537 16 02-09

$3.49

$

Usually ships in 3-10 days

0

537 17 43-01

Husqvarna 537174301

SPRING

$7.49

$

Usually ships in 3-10 days

0

537 18 35-07

Husqvarna 537183507

HANDLE

$79.99

$

Usually ships in 3-10 days

0

537 16 10-01

Husqvarna 537161001

HUB

Note: Does not fit with HANDLE HALF 537 16 02-09

$

$

Not available

537 16 08-01

Husqvarna 537160801

THROTTLE TRIGGER
(Superseded to 506497701)

$12.99

$

In Stock, only 1 left!

0

503 21 66-16

Husqvarna 503216616

SCREW
(Superseded to 503216618)

$7.49

$

In Stock, Qty 5

0

537 16 02-02

Husqvarna 537160202

HANDLE
(Superseded to 537160209)

Note: Replaced by 537 18 35-07 HANDLE SYSTEM cpl

$20.99

$

Usually ships in 3-10 days

0

503 71 82-01

Husqvarna 503718201

START/STOP SWITCH

$13.99

$

In Stock, Qty 9

0

537 33 57-01

Husqvarna 537335701

CABLE ASSY

$

$

Not available

537 18 36-01

Husqvarna 537183601

SPRING

Note: Does not fit with HANDLE HALF 537 16 02-09

$

$

Not available
