316.745400 (41ACETBC799) - Craftsman String Trimmer, Electric (Sears) General Assembly Parts Diagram

String Trimmer, Electric

General Assembly Parts Diagram

  • Title
1

MTD 791-180300

Screw, Housing Set (Qty. 11)

$10.99

$

Usually ships in 3-6 days

0

2

MTD 791-145569

Anti-Rotation Screw

$9.99

$

In Stock, Qty 7

0

3

MTD 753-05341

Motor Housing Assembly

$

$

Not available

4

MTD 791-180302

Two-Speed Switch Assembly

$

$

Not available

5

MTD 791-180559

Lead Wires

$

$

Not available

6

$

$

Not available

7

MTD 791-182318

Trigger

$

$

Not available

8

MTD 791-180305

Terminal Block

$

$

Not available

9

MTD 753-05342

Motor Assembly (includes 10 & 11)

$

$

Not available

10

$

$

Not available

11

MTD 791-180155

Cooling Fan

$19.99

$

Usually ships in 3-6 days

0

12

MTD 791-181645

Recessed Plug Assembly

$

$

Not available
