30775 (52) - Toro Groundsmaster Rear-Engine Riding Mower (SN: 002000001 - 002999999) (1982) CUTTING UNIT MODEL NO. 30560 Parts Diagram

Groundsmaster Rear-Engine Riding Mower

CUTTING UNIT MODEL NO. 30560 Parts Diagram

  • Title

1

Toro 323-5

SCREW-HH

$1.49

$

Usually ships in 3-6 days

0

2

Toro 41-8940

Rubber Side Shield
(Superseded to 47-4910)

$

$

Not available

3

Toro 3217-7

NUT-HEX

$0.99

$

In Stock, Qty 20+

0

4

Toro 41-8970

Flap Rubber Drive Coupling

$

$

Not available

5

Toro 41-9020

SEAL TRIM-GM 52 DD

$

$

Not available

6

Toro 41-8980

Grass Shield-Engine

$

$

Not available

7

Toro 41-9030

Seal-Rubber Extrusion

$

$

Not available

8

Toro 3214040

Screw Self Tapping

$

$

Currently unavailable

9

Toro 41-9050

Shield-Rear (Incl. Ref. #10 & 11)

$

$

Not available

10

Toro 3290-55

RIVET-POP

$0.99

$

Usually ships in 3-6 days

0

11

Toro 41-9060

SNAP STUD

$

$

Not available

12

Toro 32104-91

Self Tapping Screw

$

$

Not available

13

Toro 3253-29

WASHER-LOCK/SP

$0.99

$

Usually ships in 3-6 days

0

14

Toro 41-8920

GRASS SCREEN BAG

$

$

Not available

15

Toro 41-8950

LH PTO RUBBER FLAP

$

$

Not available

16

Toro 41-8960

Flap-Rubber P.T.O. R.H.

$

$

Not available

17

Toro 5-1254

WASHER

$

$

Not available

18

Toro 41-9010

Seal-Rubber Extrusion

$

$

Not available

19

Toro 41-9040

Shield Front (Incl. Ref. #4-5, 7, 10-11 & 15-18)

$

$

Not available

20

Toro 41-9070

Shield Side (Incl. Ref. #2 & 10 & 17)
(Superseded to 46-8130)

$

$

Not available
