3063354 - Bobcat 52" Z-VAC Twin Bag Catcher 2 BAG CATCHER MOUNT GROUP Parts Diagram

52" Z-VAC Twin Bag Catcher

2 BAG CATCHER MOUNT GROUP Parts Diagram

  • Title
1

Giant-Vac 3046687

WELDMENT, Bagger Mount Frame

$

$

Not available

2

Giant-Vac 7091086

SCREW, 3/8-16 x 3/4" Hex Head Cap, GR5
(Superseded to 703237)

$4.99

$

Usually ships in 2-12 days

0

3

Giant-Vac 7091619

NUT, 3/8-16 Hex Flange Lock
(Superseded to 703333)

$4.99

$

In Stock, Qty 20+

0

4

Giant-Vac 3046831

ARM, Cover Latch

$

$

Currently unavailable

5

Giant-Vac 7091318

SCREW, 5/16-18 x 3/4" Hex Head Cap, GR5
(Superseded to 704287)

$3.99

$

In Stock, Qty 8

0

6

Giant-Vac 7091601

NUT, 5/16-18 Hex Flange Lock
(Superseded to 703409)

$5.49

$

In Stock, Qty 20+

0

7

Giant-Vac 3046995

WELDMENT, Bumper Mounting Plate

$

$

Not available

8

Giant-Vac 3046992

BAR, Clamp
(Superseded to 3046992YP)

$7.99

$

Usually ships in 2-12 days

0

9

Giant-Vac 3047507

SHIM, Catcher Mount

$

$

Currently unavailable

10

Giant-Vac 7091328

SCREW, 3/8-16 x 1-1/4" Hex Head Cap
(Superseded to 703871)

$4.99

$

Usually ships in 2-12 days

0

11

Giant-Vac 7091619

NUT, 3/8-16 Hex Flange Lock
(Superseded to 703333)

$4.99

$

In Stock, Qty 20+

0

12

Giant-Vac 3046693

ROD, Support

$

$

Not available

13

Giant-Vac 1960033

HAIRPIN, Clip
(Superseded to 1960033SM)

$3.49

$

In Stock, Qty 20+

0

14

Giant-Vac 3027491

WELDMENT, Bagger Brace, RH Side

$

$

Not available

15

Giant-Vac 3027492

WELDMENT, Bagger Brace, LH Side

$

$

Not available

16

Giant-Vac 7091508

BOLT, 5/16-18 x 3/4" Short Neck Carriage, GR5
(Superseded to 703185)

$3.49

$

In Stock, Qty 12

0

17

Giant-Vac 7091601

NUT, 5/16-18 Hex Flange Lock
(Superseded to 703409)

$5.49

$

In Stock, Qty 20+

0

18

Giant-Vac 3027493

CATCHER BRACE, Center, 2 Bag Bobcat

$

$

Not available

19

Giant-Vac 7091328

SCREW, 3/8-16 x 1-1/4" Hex Head Cap
(Superseded to 703871)

$4.99

$

Usually ships in 2-12 days

0

20

Giant-Vac 7091528

WASHER, 3/8" Flat
(Superseded to 703302)

$4.49

$

In Stock, Qty 20+

0

21

Giant-Vac 7091619

NUT, 3/8-16 Hex Flange Lock
(Superseded to 703333)

$4.99

$

In Stock, Qty 20+

0

22

Giant-Vac 3032119

ROD, Bagger Brace Locking

$

$

Not available

23

Giant-Vac 7076988

HAIRPIN, Cotter
(Superseded to 7076988YP)

$3.49

$

In Stock, only 2 left!

0
